1. Information before installation
1.1 General terms of delivery, storage and transport
Any equipment, even carriage and packing free, travels at the consignee's risk. The consignee shall make
reservations in writing on the carrier's bill of lading if damage is detected, caused during transport (confirmation
to be sent to the carrier within 48 hours by registered mail with acknowledgement of receipt).
1.2 Content
X1
1.3 Operating conditions
Operating range: water temperature of between 2 °C and 40 °C
1.4 Technical specifications
Red Line +
Power *
Single-phase 230V
Power supply
Three-phase 400V
* with a manufacturer tolerance of ±5%
 protection rating: IP 45
H03609-00.B1.EN - 2012/01
