Unit characteristics
2
Modular T units are produced in a standard version which includes an aluminium counter-current heat
exchanger, ePM1 50% (F7) class filter in supply and ePM10 75% (M5) class filter in return, 50 mm double
skin panel with insulation in mineral wool.
The accessories can be purchased separately as an option and installed on site.
Environmental conditions
Modular T heat recovery units are designed to be positioned on the floor, indoors.
The unit cannot operate in environments containing explosive material and with
a high concentration of dust.
Outside air temperature
Operating environment temperature
Temperature of the environment with the unit off
(e.g., storage, transport, etc.)
Thanks to its modularity, each unit is able to adapt to different needs in terms of air flow
and thermodynamic treatments.
Environmental contamination
Depending on the installation operating environment, specific regulations must be followed and all the
necessary precautions must be taken to avoid environmental issues (a system that operates in a hospital
or chemical environment can have problems different from those in other sectors, even from the point of
view of disposal of consumable parts, filters, etc.).
It is mandatory for the buyer to inform and train workers regarding proper procedures.
Noise
The units have been designed and manufactured in such a way as to produce sound emissions
> 80 dB(A)
below the threshold of
acoustic characteristics that can greatly affect the pressure values perceived during operation,
therefore it is necessary to consider the noise level data provided as a point of reference, while
it is up to the buyer to carry out the specific phonometric surveys on the installation site and
in the real conditions the unit will be used.
8
without heating coil:
• from -5 °C to 46 °C
with heating coil:
• from -25 °C to 46 °C
from -5 °C to 46 °C
from -40 °C to 60 °C
80
dB(A). It should be noted that every environment has its own
