Attached List 1：Error Code Definition - Key-Disp KD51C-D User Manual

Warnings:
1. Use the display with caution. Don't attempt to disconnect or link the connector
when battery is on power.
2. Try to avoid hitting the display.
3. Don't modify system parameters to avoid parameter disorder.
4. Make the display repaired when an error code appears.
THIS MANUAL INSTRUCTION IS A GENERAL-PURPOSE VERSION.SOME
▉
OF THE VERSIONS FOR THE DISPLAY SOFTWARE WILL BE DIFFERENT FROM
SPECIFICATION TO SPECIFICATION. PLEASE ALWAYS REFER TO AN ACTUAL
VERSION
Attached list 1：Error code definition
Error code
21
22
23
24
25
30
Attached list 2：PAS ratio default value table
Level
PAS
level mode
0-3/1-3
0-5/ 1-5
0-7/ 1-7
0-9/ 1-9
Definition
Current Abnormality
Throttle Abnormality
Motor Phase Abnormality
Motor Hall Signal Abnormality
Brake Abnormality
Communication Abnormality
1 2 3
50% 74% 92%
50% 61% 73%
40% 50% 60%
25% 34% 43%
4 5 6
— — —
85% 96% —
70% 80% 90%
52% 61% 70%
17
7 8 9
— — —
— — —
96% — —
79% 88% 96%
