24 SLC 500 BASIC and BASIC-T Modules

Specifications

BASIC and BASIC-T Modules Specifications
Specification
Power Supply Loading at 5V dc
Power Supply Loading at 24V dc
Noise Immunity
Vibration
Shock (operating)
(1)
Port Isolation
Port PRT1
Port PRT2
Port PRT1 to Port PRT2
Ambient Temperature Rating
Humidity
Clock/Calendar Accuracy
(1) Port DH485 is not isolated.
(2) If a Hand-Held Terminal, Data Table Access Module, or interface converter is connected to the link coupler, the additional
backplane power draw of these components (listed on page 25) must be added to the 0.125 listed in the table above. This
only applies when the module is connected to the network via the link coupler and 1747-C10 cable or 1747-C11 cable. This
does not apply when the 1747-C13 cable is used.
Certifications
Certification
Agency Certification
Publication 1746-IN009B-EN-P - August 2005
Value
0.150 A (module only)
0.150 A (module with link coupler)
0.070 A (module only)
0.125 A (module with link coupler)
NEMA Standard ICS 2-230
Displacement: 0.015 in, peak-to-peak at 5...57 Hz
Acceleration: 2.5 G at 57...2000 Hz
30 G
710V dc for 1 minute (backplane to port)
710V dc for 1 minute (backplane to port)
710V dc for 1 minute (port PRT1 to port PRT2)
Operating: 0...+60 ° C (+32...+140 °F)
Storage: -40...+85 °C (-40...+185 °F)
5...95% without condensation
±1 minute/month at 25 °C (77 °F)
+0, -6 minute/month at 60 °C (140 °F)
Value
c-UL-us listed
Class I, Groups A, B, C or D, Division 2
CE compliant for all applicable directives
C-Tick marked for all applicable acts
(2)
