To The Installer
Pre-installation Considerations
Power Requirements
Initial Handling
AC (12-120V) Output Module
Cat. No. 1771-OAD Series B
Installation Instructions
This document provides information on:
important pre-installation considerations
power supply requirements
installing the module
using the indicators for troubleshooting
replacing the fuse
module specifications
The 1771-OAD Series B module is compatible with all chassis except
1771-A1, 1771-A2 and 1771-A4 chassis. Make sure no other output module
or single card block transfer module is placed in the same module group
when using 2-slot addressing. Any discrete input module may be used
within the same module group.
Your module receives its power through the 1771 I/O chassis backplane from
the chassis power supply. The module requires 295mA from the output of this
supply. Add this to the requirements of all other modules in the I/O chassis to
prevent overloading the chassis backplane and/or chassis power supply.
The ac output module is shipped in a static-shielded bag to guard against
electrostatic discharge damage. Observe the following precautions when
handling the module.
Electrostatic Discharge Damage
ATTENTION: Under some conditions, electrostatic discharge
can degrade performance or damage the module. Observe the
following precautions to guard against electrostatic damage.
Wear an approved wrist strap grounding device, or touch a grounded
object to discharge yourself before handling the module.
Do not touch the backplane connector or connector pins.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the B Series and is the answer not in the manual?

Questions and answers

Related Manuals for Allen-Bradley B Series

Summary of Contents for Allen-Bradley B Series

  • Page 1 AC (12-120V) Output Module Cat. No. 1771-OAD Series B Installation Instructions To The Installer This document provides information on: important pre-installation considerations power supply requirements installing the module using the indicators for troubleshooting replacing the fuse module specifications Pre-installation Considerations The 1771-OAD Series B module is compatible with all chassis except 1771-A1, 1771-A2 and 1771-A4 chassis.
