PROAIM Airwave Ultra Assembly Manual

Vibration isolator arm

Airwave Ultra Vibration Isolator Arm

(VI-ARWV-UT)

A s s e m b l y M a n u a l

What's In The Box

Please inspect the contents of your shipped package to ensure you have received everything that is listed

below.

Airwave Ultra

2x Hex Nut

1x Spanner (Size:21mm)

(Size:1/2")

Castle Wrench

No part of this document may be reproduced, stored in a retrieval system, or transmitted by any form or by any means,

electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permitted by the applicable copyright

statutes or in writing by the Publisher.

Table of Contents

Need help?

Do you have a question about the Airwave Ultra and is the answer not in the manual?

Page 1 Airwave Ultra Vibration Isolator Arm (VI-ARWV-UT) A s s e m b l y M a n u a l What’s In The Box Please inspect the contents of your shipped package to ensure you have received everything that is listed below.
Page 2 Loose both the knobs, as shown in the image. • Now open both the clamps. • Align the clamps of the Airwave to a scaffold pole, and then secure the clamp by properly tightening the clamp knobs. • Airwave Ultra has been properly attached to the scaffold pole.
Page 3 Loosen and remove the castle nut fixed on top of the Vibration Isolator. • Attach the Vibration Isolator at the bottom of the Airwave Ultra, and then tighten the castle nut to secure it. • Now secure the Vibration Isolator by attaching the castle nut with the Airwave Ultra.
Page 4 Air Filling Pump • Attach the air pressure pump with the washer fitted to the Airwave Ultra. • Now lock the blue locking knob after using Pressure Pump. Vibration Isolator with Damper • Open the lock lever at the bottom of the Vibration Isolator.
Page 5 YOUR PROAIM AIRWAVE ULTRA VIBRATION ISOLATOR ARM ALL DRESSED UP AND READY TO GO! (SHOWN WITH OPTIONAL ACCESSORIES) Warranty: We offer one year warranty for our products from date of purchase. Within this period of time, we will repair it without charge for labor or parts. Warranty doesn’t cover transportation costs nor does it cover a product subjected to misuse or accidental damage.
