1
10/08/2001
1. Ride Height Switch
2. Air Lumbar Support Switch
Fig. 5.27, Air Controls, Sears Seat
Seat Cushion Tilt
To raise the seat cushion, lift upward on the front of
the seat cushion, and then push it rearwards. To
lower the seat cushion, pull forward on the front of
the seat cushion, and then push downwards.
Backrest Adjustment
To adjust the backrest, push downwards on the
backrest lever just below the bottom of the backrest
cushion. With the lever down, lean forward or
backward to the desired position. Release the lever
to lock the backrest in place.
Ride Height Adjustment
Push the ride height knob inwards to inflate the air
cylinder, raising the height of the seat. Pull the ride
height knob outwards to deflate the air cylinder,
lowering the height of the seat.
For seats with air support, use the forward rocker
switch on the control panel on the left-hand side of
the seat as shown in Fig.
seat; press down to lower the seat.
Ride Firmness Adjustment
For a softer ride, remove the snap ring and pin from
the shock absorber bracket (see inset). Relocate the
pin in the other set of holes in the bracket and
secure it with the snap ring.
2
f910488
5.27. Press up to raise the

Bench Seats

Bench Seats
A full width rear bench seat is optional on the
M2Plus. See Fig. 5.28.
1
10/05/2001
1. Full Width Rear Bench Seat
2. Seat Slide Lever
Fig. 5.28, Full Width Rear Bench Seat
The full bench seat accommodates up to three
passengers with lap belts and shoulder restraints.
The full bench seat has a seat slide adjustment to
adjust leg room. Release the seat slide lever and
push backwards or forwards to move the seat along
its track.
Also available is a two-person bench seat with a safe
or tool box located under the seat. No adjustments
are available on the two-person bench seat.

Seat Belts

General Information
Seat belt assemblies are designed to secure persons
in the vehicle to help reduce the chance of injury or
the amount of injury resulting from accidents or
sudden stops. For this reason, Daimler Truck North
America LLC urges that the driver and all
passengers, regardless of age or physical condition,
use seat belts when riding in the vehicle.
Cab Features
2
f910481
5.14
