A. Ride Height
Fig. 5.19, Ride Height Adjustment
reach and the driver should have a clear view of the
road and mirrors.
C
D
12/01/2021
A. Adjust the steering wheel and seat to achieve a 95°
to 135° angle at the elbow joints.
B. Adjust the bottom cushion to achieve a 100° to 115°
angle at the hip joints.
C. Adjust the seat height to achieve a 110° to 120°
angle at the knee joints.
D. Adjust the seat to achieve a 90° angle with the feet.
Fig. 5.20, Correct Seating Posture
A
A
B

ISRI Premium High Back Seat

NOTE: The seat should only be adjusted when the
vehicle is parked with the park brake on.
The seat is designed to hold a maximum driver's
weight of 330 lbs.
The ISRI Premium seat controls are shown in
Fig. 5.21.
f910485
8
7
12/02/2021
f910833
1. Backrest Tilt
2. Back Support
3. Height Adjustment
4. Isolator Adjustment
Fig. 5.21, ISRI Premium High Back Seat
1. Backrest Tilt: Pull the handle out completely
and lean back or forwards to adjust the backrest
tilt. Release the handle when the correct position
is achieved. The backrest has a 52 degree range
of movement.
Cab Features
3
6
4
5
5. Forward/Back Isolator
6. Seat Extension
7. Forward/Back Slide
8. Seat Tilt Lever
1
2
f910682f
