Driver Controls
1
04/15/2020
1. Driver Facing Camera
2. Multipurpose Camera
2 (MPC2)
Fig. 4.4, MPC2 Cameras and Rain/Light Sensor
appear shiny when viewed through the
windshield because of the silicone gel between
the lens and the windshield. If no rain/light
sensor is installed, the plastic plug placed in the
bracket will appear as a flat black circle.
A vehicle equipped with automatic headlights
and an A option on the headlight switch shown
in Fig. 4.5, should be equipped with a rain/light
sensor.
Windshield Washers
The windshield washer button is located at the end
of the turn signal lever. Momentarily press the
windshield washer button to initiate a single wipe
without activating the washer pump. The wipers will
swipe one full cycle and return to the inactive
position.
To operate the windshield washers, press and hold
the button in. After a short delay, the washer will
pump windshield washer fluid onto the windshield for
as long as the washer button is pressed. The
windshield wipers turn on at low speed while the
washer button is pressed. After the button is
released, the wipers continue to operate for one to
several wipe cycles, depending on how long the
wash button was pressed initially.
4.3
3
2
f546894a
3. Rain/Light Sensor

Exterior Lighting Controls

Unless otherwise noted below, press the upper half
of the dash switch to turn the desired light(s) on or
off.
Turn Signals
The turn-signal lever is mounted on the left-hand
side of the steering column. Pulling the turn-signal
lever up activates the right-turn signal; pushing it
down activates the left-turn signal. The lever is
typically a non-canceling combination turn-signal,
windshield wiper/washer switch, and high beam
headlamp control unit. See
When a turn signal is activated, a green telltale lamp
flashes on the instrument panel.
On a self-canceling turn signal lever, the lever
automatically returns to the neutral position when the
steering wheel returns to the straight-ahead position
after a turn.
Headlamp Switch
The headlamp switch is a rotary switch located to the
left of the steering column, above the ignition switch.
See Fig. 4.5.
3
2
1
08/28/2018
1. Fog lamps (optional)—Activate by pulling the switch
out when the marker lamps or headlamps are on.
2. Automatic Headlamps
3. Off
4. Marker lamps
5. Headlamps
Fig. 4.5, Headlamp Switch
Fig. 4.3.
4
5
f611525
