freightliner M2 Plus 2023 Manual page 219

2
B
01/11/2012
A. Measure the distance from the ground to the center of each headlight bulb.
B. Mark where the center of each headlight projection should appear.
1. Screen or Wall
2. Center of Right-Hand Headlight Projection
1
01/11/2012
1. Low-Beam Angle Upper Limit
2. Ideal Low-Beam Projection
3
B
1
Fig. 18.2, Headlight Aiming Screen/Wall
A
2
3
Fig. 18.3, Vertical Low-Beam Headlight Variation Limits
Headlight Aiming
A
3. Center of Left-Hand Headlight Projection
3. Low-Beam Angle Lower Limit
A
f545850b
f545851b
18.2
