Composite Input/Output Circuit Board; Control Circuit Board - Orban OPTIMOD 8400 Operating Manual

6-20
TECHNICAL DATA

Composite Input/Output Circuit Board

Control Circuit Board

PART # DESCRIPTION
20039.750.01 RESISTOR, MF, 1/8W, 1%, 75.0 ohm
20040.604.01 RESISTOR, MF, 1/8W, 1%, 604 ohm
20130.162.01 RESISTOR, 1/8W, 1%, 1.62K
20130.200.01 RESISTOR, 2.00K
20131.200.01 RESISTOR, 20.0K 1%
21139.000.01 CAPACITOR, X7R, 0.1UF, 10%
21143.000.01 CAPACITOR, NPO, 1500PF, 1%
21145.000.01 CAPACITOR, NPO, 5%, 100V, 33PF, 1206
24024.000.01 IC, OPA2134PA
24025.000.01 IC, BUF634P, DIP8
29508.210.01 FILTER, EMI SUPPRESSION, 50V-
29521.000.01 INDUCTOR, 3.9UH, JM391K
PART # DESCRIPTION
20080.301.01 RESISTOR, MF, 1/2W, 1%, 301 ohm
20121.100.01 RESISTOR, RF, 1/8W, 1%, 10 ohm
20121.750.01 RESISTOR, TF, 1/8W, 1%, 75 ohm
20123.499.01 RESISTOR, TF, 1/8W, 1%, 4.99K
20129.301.01 RESISTOR, 301 ohm
20130.100.01 RESISTOR, 1.00K 1%
20130.162.01 RESISTOR, 1/8W, 1%, 1.62K
20130.200.01 RESISTOR, 2.00K
20130.221.01 RESISTOR, 2.21K
20130.332.01 RESISTOR, 1% 3.32K
20130.365.01 RESISTOR, 1/8W, 1%, 3.65K
20130.475.01 RESISTOR, 4.75K
20130.562.01 RESISTOR, 1/8W, 1%, 5.62K
20131.140.01 RESISTOR, 14.0K
20131.200.01 RESISTOR, 20.0K 1%
20131.301.01 RESISTOR, 30.1K
20131.499.01 RESISTOR, 1/8W, 1%, 49.9K
20132.100.01 RESISTOR, 100K
20132.332.01 RESISTOR, 332K
21140.000.01 CAPACITOR, NPO, 470PF, 1%
21141.000.01 CAPACITOR, NPO, 1000PF, 1%
21145.000.01 CAPACITOR, NPO, 5%, 100V, 33PF, 1206
21146.310.01 CAPACITOR, 0.01uf, 10%
21147.022.01 CAPACITOR, 22pf, 1%
21149.015.01 CAPACITOR, 15pf, 1%
21150.133.01 CAPACITOR, 330pf, 1%
21154.433.01 CAPACITOR, 0.33uf, 20%
21209.710.01 CAPACITOR, RADIAL LEADS, 100uF, 63V, 20%
Orban Model 8400
COMPONENT IDENTIFIER
R13 R14
R5 R6 R7 R8
R9 R10
R11 R12
R1 R2 R3 R4
C11 C12 C3 C4 C5 C6
C7 C8 C9 C10
C1 C2
IC3
IC1 IC2
L1 L2 L3 L4
L5 L6 L7 L8
COMPONENT IDENTIFIER
R68
R20 R59 R96 R97
R30 R47 R78 R79 R80 R81 R83
R84 R85 R86 R94 R82
R89 R91
R130
R29 R36 R46 R49 R52 R55 R58
R61 R64 R117 R120 R92 R93
R69 R70
R124
R19
R76 R140
R90
R31 R32 R33 R34
R75
R126 R87
R88
R141
R23
R24 R28 R45 R48 R51 R54 R57
R60 R63 R66 R67 R116 R95
R105 R106 R107 R108 R109
R110 R111 R112
R21
C19 C36
C18 C23 C25 C28 C31 C34 C47
C58 C63 C70
C37
C17 C22 C24 C27 C30 C33 C45
C57 C62 C68 C94
C20 C89 C92 C93
C40
C39
C133, C134, C135
C100
