Modified linear curve
A modified linear curve reduces the voltage change at low control levels for better performance in low-
wattage fixtures.
140
120
100
80
60
40
20
0
Modified linear curve
Square law curve
At low control levels, much of a traditional incandescent fixture's light output is in the invisible infrared
spectrum. This results in poor visible response to low control levels. A square law curve applies a
multiple derived from the square root of the control level (with full output equal to 1.00) to increase
voltage response at low control levels to compensate for the infrared loss.
140
120
100
74
1
10
20
80
60
40
20
0
1
10
20
Square law curve
Linear Curve
30
40
50
60
Console percentage setting
Linear curve
Square Law Curve
30
40
50
Console percentage setting
Linear curve
70
80
90
(for reference)
60
70
80
90
(for reference)
Sensor+ CEM+ User/Config Manual
100
100
