Switched
Switched mode defaults to full unregulated sine wave of the power through the dimmer. This is good
for inductive loads connected to a dimmer.
Change the firing mode to Switched and click Save Changes. After saving changes, the remaining
dimmer properties will change automatically or can now be set to your desired values.
Non-Dim
Non-dim mode is not offered in CEM+ as it was in classic CEM, but you can re-create it with the
settings listed below.
Non-dim is a voltage regulated version of switched mode. Switched mode delivers full sine wave power
through the dimmer, good for inductive loads. Non-dim regulates (dims) the output to a user specified
value, protecting on/off lamps from unregulated power in venues where mains exceed lamp ratings.
Non-dim operation may be accomplished using switched mode and enabling voltage regulation and
adjusting max scale voltage (see table below).
CEM+ Procedures
Property
Firing Mode
Curve
Threshold
Min. Scale Voltage
Max. Scale Voltage
Voltage Regulation
Preheat
Dynamic Preheat
DC Output Prevent
InRush Protect
Property
Firing Mode
Curve
Threshold
Min. Scale Voltage
Max. Scale Voltage
Voltage Regulation
Preheat
Dynamic Preheat
DC Output Prevent
InRush Protect
120V
Switched
Linear
50%
0V
140V
Unchecked
Unchecked
0 sec.
Unchecked
Unchecked
120V
Normal
Linear
1%
or desired setting or desired setting
115V
or desired setting or desired setting
115V
or desired setting or desired setting
Checked
Unchecked
0 sec.
Unchecked
Unchecked
230V
Switched
Linear
50%
0V
280V
Unchecked
Unchecked
0 sec.
Unchecked
Unchecked
230V
Normal
Linear
1%
230V
230V
Checked
Unchecked
0 sec.
Unchecked
Unchecked
