  • Page 1 ProCurve Network Access Controller 800 Hardware Installation Guide...
  • Page 2 March 2012 performance, or use of this material. The only warranties for HP products and services are set forth in the express warranty statements accompanying Applicable Products such products and services. Nothing herein should be •...

  • Page 3: Table Of Contents

    Contents 1 Introduction ProCurve Network Access Controller 800 ......1-1 The ProCurve NAC 800 Endpoint Integrity Solution ....1-2 802.1X .
  • Page 4 Informations concernant la sécurité ......A-2 Hinweise zur Sicherheit ......... A-3 Considerazioni sulla sicurezza .

  • Page 5: Introduction

    Introduction ProCurve Network Access Controller 800 Introduction ProCurve Network Access Controller The ProCurve Network Access Controller 800 (ProCurve NAC 800) provides a complete solution for managing network access at the network edge. When used with the ProCurve Manager (PCM) and ProCurve Identity Driven Manager (IDM) products, you get a single, centralized network management tool, that lets you secure your network from unauthorized access.

  • Page 6: The Procurve Nac 800 Endpoint Integrity Solution

    ProCurve NAC 800 Endpoint Integrity (EI) solution, ProCurve requires an implementation service to ensure successful deployment. Please contact your Authorized ProCurve reseller, or HP ProCurve Support for information on ordering the ProCurve NAC 800 Endpoint Integrity Implementation service. The following section provides a brief overview of the options available for deployment of the endpoint integrity solution.

  • Page 7: 802.1X

    Introduction ProCurve Network Access Controller 800 You can deploy each ProCurve NAC endpoint integrity cluster in one of the following configurations. 802.1X When deploying ProCurve NAC in an 802.1X environment, you must install it where it can communicate with the Remote Authentication Dial-In User Service (RADIUS) server (or, use the built-in RADIUS server on the ProCurve NAC 800).
  • Page 8 (This page intentionally left blank)

  • Page 9: Quick Install

    Quick Install The ProCurve Network Access Controller 800 appliance is easy to install. It comes with an accessory kit that includes the brackets for mounting the box in a standard 19-inch telco rack or in an equipment cabinet, and with rubber feet that can be attached so the appliance can be securely located on a horizontal surface.

  • Page 10: Included Parts

    C o r d W a r n i n g For additional configuration information and user instructions, PDF versions of the documentation for the ProCurve Network Access Controller 800 appli- ance, including the Users’ Guide, and this Installation Guide are available on the Web at: http://www.hp.com/rnd/support/manuals...

  • Page 11: Installation Precautions

    Quick Install Quick Install Summary Installation Precautions: Follow these precautions when installing the ProCurve NAC 800 appliance. Wa r n i n g ■ The rack or cabinet should be adequately secured to prevent it from becoming unstable and/or falling over. Units installed in a rack or cabinet should be mounted as low as possible, with the heaviest devices at the bottom and progressively lighter devices installed above.

  • Page 12: Hardware Specifications

    Quick Install Quick Install Summary Hardware Specifications System specifications for ProCurve Network Access Controller 800 (J9065A). Physical Width: 44.3 cm (17.42 in) Depth: 39 cm (15.4 in) Height: 4.2 cm (1.64 in) Weight: 6.1 kg (13.45 lbs) Electrical The appliance automatically adjusts to any voltage between 100-127 and 200- 240 volts and either 50 or 60 Hz.

  • Page 13: Installing The Appliance

    Quick Install Installing the Appliance Installing the Appliance 1. Prepare the Installation Site ■ Cabling Infrastructure - Ensure the cabling infrastructure meets the necessary network specifications. See the following table for cable types and lengths, and see appendix B, “Cables and Connectors” for more information: Table 1.

  • Page 14: Mount The Unit

    Quick Install Installing the Appliance 2. Mount the Unit After determining the configuration and preparing the site, you are ready to mount the ProCurve NAC 800 appliance in a stable location. The ProCurve NAC 800 unit can be mounted in a rack or cabinet Wa r n i n g For safe operation, please read the mounting precautions on page...
  • Page 15 Quick Install Installing the Appliance N o t e The mounting brackets have multiple mounting holes and can be rotated, allowing for a variety of mounting options. Hold the unit with attached brackets up to the rack and move it vertically until rack holes line up with the bracket holes, then insert and tighten the four number 12-24 screws holding the brackets to the rack.

  • Page 16: Horizontal Surface Mounting

    Quick Install Installing the Appliance Horizontal Surface Mounting Place the ProCurve NAC 800 on a table or other horizontal surface. The unit comes with rubber feet in the accessory kit that can be used to help keep it from sliding on the surface. Attach the rubber feet to the four corners on the bottom of the box within the embossed angled lines.

  • Page 17: Connect The Network Cables

    Quick Install Installing the Appliance 4. Connect the Network Cables Connect the network cables, described under “Cabling Infrastructure” (page 5), from the network devices or your patch panels to the fixed RJ-45 ports on the front of the ProCurve NAC 800. For deployment as a standalone RADIUS sever, or for the RADIUS server with IDM agent, insert the network cable in the LAN port (LAN Port 1) on the front of the box.

  • Page 18: Terminal Configuration

    Quick Install Installing the Appliance Power Fault Locator Console Connect RJ-45 cable to Console port. Terminal Configuration To connect a console to the unit, configure the PC terminal emulator as a DEC VT-100 (ANSI) terminal or use a VT-100 terminal, and configure either one to operate with these settings: •...

  • Page 19: Initial Appliance Configuration

    Quick Install Installing the Appliance 6. Initial Appliance Configuration When you first power up the ProCurve NAC 800 appliance, you can use the LCD menu and buttons on the front panel to set the IP address for the unit. These same functions are available via the Console menu. To access the Console Menu, connect a console and login to the ProCurve NAC using the default administrator account: Login = admin...

  • Page 20: Configuring Via The Front Lcd Display

    Quick Install Installing the Appliance Configuring via the Front LCD Display Figure 7. Front Panel LCD and Buttons To select the menu, push the center button ( ). ■ ■ To scroll up or down through a menu list, push the top ( ) or bottom ( ) buttons, respectively.
  • Page 21 Quick Install Installing the Appliance b. To move to the next number in the entry, press the button to move right, or the button to move left. Press once for each number space you want to move. The underscore ( _ ) indicates the selected number. When the IP address is set correctly, press the button to apply the new IP address, and continue to the Subnet Mask configuration.
  • Page 22 Quick Install Installing the Appliance To set the server personality to Management or Enforcement Server for Endpoint Integrity: Press to display the LCD menu. When the menu displays, the Configuration option is selected. Press to continue. The Configuration menu appears with the Server Type option selected. Press to continue.
  • Page 23 Quick Install Installing the Appliance Press the center button to apply changes. When the server type has been set the display returns to the top of the Configuration menu. 2-15...
  • Page 24 (This page intentionally left blank)

  • Page 25: A Safety And Emc Regulatory Statements

    Safety and EMC Regulatory Statements Safety Information Documentation reference symbol. If the product is marked with this symbol, refer to the product documentation to get more information about the product. WARNING A WARNING in the manual denotes a hazard that can cause injury or death.

  • Page 26: Informations Concernant La Sécurité

    Safety and EMC Regulatory Statements Informations concernant la sécurité Informations concernant la sécurité Symbole de référence à la documentation. Si le produit est marqué de ce symbole, reportez-vous à la documentation du produit afin d'obtenir des informations plus détaillées. WARNING Dans la documentation, un WARNING indique un danger susceptible d'entraîner des dommages corporels ou la mort.

  • Page 27: Hinweise Zur Sicherheit

    Safety and EMC Regulatory Statements Hinweise zur Sicherheit Hinweise zur Sicherheit Symbol für Dokumentationsverweis. Wenn das Produkt mit diesem Symbol markiert ist, schlagen Sie bitte in der Produktdokumentation nach, um mehr Informationen über das Produkt zu erhalten. WARNING Eine WARNING in der Dokumentation symbolisiert eine Gefahr, die Verletzungen oder sogar Todesfälle verursachen kann.

  • Page 28: Considerazioni Sulla Sicurezza

    Safety and EMC Regulatory Statements Considerazioni sulla sicurezza Considerazioni sulla sicurezza Simbolo di riferimento alla documentazione. Se il prodotto è contras- segnato da questo simbolo, fare riferimento alla documentazione sul prodotto per ulteriori informazioni su di esso. WARNING La dicitura WARNINGdenota un pericolo che può causare lesioni o morte.

  • Page 29: Consideraciones Sobre Seguridad

    Safety and EMC Regulatory Statements Consideraciones sobre seguridad Consideraciones sobre seguridad Símbolo de referencia a la documentación. Si el producto va marcado con este símbolo, consultar la documentación del producto a fin de obtener mayor información sobre el producto. WARNING Una WARNING en la documentación señala un riesgo que podría resultar en lesiones o la muerte.

  • Page 30: Safety Information (Japan

    Safety and EMC Regulatory Statements Safety Information (Japan) Safety Information (Japan)

  • Page 31: Safety Information (China

    Safety and EMC Regulatory Statements Safety Information (China) Safety Information (China)

  • Page 32: Emc Regulatory Statements

    Safety and EMC Regulatory Statements EMC Regulatory Statements EMC Regulatory Statements U.S.A. FCC Class A This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against interference when the equipment is operated in a commercial environment.

  • Page 33: Korea

    Safety and EMC Regulatory Statements EMC Regulatory Statements Korea Taiwan...
  • Page 34 Safety and EMC Regulatory Statements EMC Regulatory Statements A-10...

  • Page 35: B Recycle Statements

    Recycle Statements Waste Electrical and Electronic Equipment (WEEE) Statements Disposal of Waste Equipment by Users in Private Household in the European Union This symbol on the product or on its packaging indicates that this product must not be disposed of with your other household waste.
  • Page 36 Recycle Statements Waste Electrical and Electronic Equipment (WEEE) Statements Laitteiden hävittäminen kotitalouksissa Euroopan unionin alueella Jos tuotteessa tai sen pakkauksessa on tämä merkki, tuotetta ei saa hävittää kotitalousjätteiden mukana. Tällöin hävitettävä laite on toimitettava sähkölaitteiden ja elektronisten laitteiden kierrätyspisteeseen. Hävitettävien laitteiden erillinen käsittely ja kierrätys auttavat säästämään luonnonvaroja ja varmistamaan, että...
  • Page 37 Recycle Statements Waste Electrical and Electronic Equipment (WEEE) Statements Smaltimento delle apparecchiature da parte di privati nel territorio dell'Unione Europea Questo simbolo presente sul prodotto o sulla sua confezione indica che il prodotto non può essere smaltito insieme ai rifiuti domestici. È responsabilità dell'utente smaltire le apparecchiature consegnan- dole presso un punto di raccolta designato al riciclo e allo smaltimento di apparecchiature elettriche ed elettroniche.
  • Page 38 Para obter mais informações sobre locais que reciclam esse tipo de material, entre em contato com o escritório da HP em sua cidade, com o serviço de coleta de lixo ou com a loja em que o produto foi adquirido.
  • Page 39 Index Numerics 1000Base-T electrical specifications, appliance … 2-4 connections, length limitations … 2-5 EMC regulatory statements … A-8 ports, cables used with … 2-5 environmental specifications, appliance … 2-4 802.1X … 1-3 deployment … 1-3 features console … 2-9 acoustic specifications … 2-4 appliance connecting to a power source …...
  • Page 40 summary of cables used with the appliance … 2-5 network cables 1000Base-T connections … 2-5 required types … 2-5 network devices terminal configuration … 2-10 connecting to the appliance … 2-9 network ports connecting to … 2-9 standards compliance … 2-4 warranty …...
  • Page 41 (This page intentionally left blank)
  • Page 42 (This page intentionally left blank)
  • Page 43 (This page intentionally left blank)
  • Page 44 © 2007, 2012 Hewlett-Packard Development Company, LP. The information contained herein is subject to change without notice. *5998-3237* Part Number 5998-3237 March 2012...
