Low Power Consumption Infrared Scouting Camera
Ltl-6511-4G(EXT.LCD)
LTE Cellular Mobile Communication Series
1080P HD Video
Less Than 0.2S Trigger Time in Actual Application
USER'S MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Ltl-6511-4G and is the answer not in the manual?

Questions and answers

Related Manuals for Ltl Acorn Ltl-6511-4G

Summary of Contents for Ltl Acorn Ltl-6511-4G

  • Page 1 Low Power Consumption Infrared Scouting Camera Ltl-6511-4G(EXT.LCD) LTE Cellular Mobile Communication Series 1080P HD Video Less Than 0.2S Trigger Time in Actual Application USER’S MANUAL...

  • Page 2: Table Of Contents

    Setup FTP Parameters on Camera ............42 Set up FTP Parameters on PC ..............43 Ltl Acorn Camera Cloud System Settings ..........47 Set Parameters of Ltl Acorn Camera Cloud System on Camera..47 Set Parameters of Ltl Acorn Camera Cloud System on computer ..48...
  • Page 3 Use Camera Outdoors ................59 Introduction of 18650 Lithium Battery ............60 FIRMWARE UPGRADES ................60 Remote update program via Ltl Acorn Camera Cloud System ....62 LIMITED WARRANTY ..................65 Appendix I: TECHNICAL SPECIFICATION ..........66 Appendix II: PACKAGE CONTENTS ............70 Appendix III: Illustration of Battery Box Installation .........

  • Page 4: General Information

    Email/FTP server or upload directly to the Ltl Acorn Camera Cloud System. In order to save 4G traffic flow, users can the camera to send thumbnail. send back the full size picture which is valuable by SMS remote control function.

  • Page 5: Features

    50Mbps (Please refer to the section 2.11 4G sleep function Function for specific transmission speed.).  Send the captured file to E-mail, appointed FTP or Ltl Acorn Camera Cloud System via 4G wireless network.  You can plug the external environment data collection device with the...
  • Page 6 shooting, users can download the picture or video from FTP.  LBS update time, when the 4G sending status is in off mode and the workable SIM card is inserted, turn the camera to TEST mode, or when the LBS/ GPS positioning time is reached in ON mode, the camera will automatically search for LBS positioning, and update the camera time after LBS positioning successfully.

  • Page 7: Application

    automatically to make room for new records.  Security box is optional for purchase.  Support to fix by tripod.  Supports to operate with 2G GSM/3G CDWMA/4G LTE networks globally. 1.2 Application  Wildlife animal and plants observation  Security and surveillance 1.3 Illustration ...
  • Page 8 GPS Antenna Antenna Light Sensor Motion Indicator Lens IR LED Light Low Power Dual PIR Pyroelectric Lock Buckle Infrared Sensor Lock Hole Figure 1.1Font View of the Camera...
  • Page 9 Battery door TV out jack External DC Power/Mode Power in jack switch Type -C socket of SD card slot external control box Figure 1.2 Bottom View of the Camera The camera provides the following connections for external devices: Type -C port of external LCD display and keypad control box, SD card slot, SIM card slot, TV out jack, and external DC power in jack.2 positions of power mode switch: switch inward: OFF mode, switch outward: ON mode.

  • Page 10: Keypad

    Electrode contact Battery container Lock hole • Figure 1.4 shows the camera's battery compartment CAUTION: If you are not using the camera for an extended period of time, it is highly recommended that you remove the batteries from the camera to avoid possible acid leak that may damage the camera and void the warranty.
  • Page 11 Take photo (camera mode). Take video (video mode). Exit Right key enlargement of picture, play or stop recording video(replay mode) Enter video mode (TEST mode). Move upward (menu/replay Up arrow mode). Long press to move picture upward, short press to move picture leftward (when zoom in picture in replay mode).

  • Page 12: Getting Started

    Getting Started 2.1 Load Batteries Load 4xAA batteries in camera:  Push inward to open the battery door at the bottom of the main unit.  According to the positive and negative marker on the battery door to load the 4xAA batteries. ...

  • Page 13: Insert Sd Card

     Please note that the battery polarity should correspond to the mark on the battery box when loading.  Please follow the positive and negative labels on battery box to l oad the 6x18650 lithium batteries. Note: When using the battery box to power the camera, please be sure to install 6 fully charged 18650 lithium batteries in the battery box.

  • Page 14: Insert Sim Card

    2.3 Insert SIM Card The SIM card should be purchased from local mobile operator, it must be 4G LTE system and be able to provide SMS and data traffic services. Insert SIM Card At the left side of the camera back, you can see the SIM sign and the SIM card slot.

  • Page 15: Enter Test Mode

    2.5 Enter Test Mode After correctly connecting the external button control box with display screen, turn the switch outward to the preview test mode. external button control box with display screen with the keypad, in this case, you can use the camera as a normal digital camera to take picture and video by controlling the keypad.

  • Page 16: Connect The Environmental Data Acquisition Device And Necessary Settings

    Ltl Acorn Camera Cloud System every 6 hours. The data uploaded can be viewed in page of Ltl Acorn Camera Cloud System -> Environmental data analysis. Attention: The Environment Monitoring only works when the sending status is set to the Ltl Acorn Camera Cloud System and the Environment Monitoring menu is "ON".

  • Page 17: Gps Positioning And Lbs Update Time Of Camera

    2.7 GPS Positioning and LBS Update Time of camera With the built-in GPS module, when the 4G sending status is not set to off, it can automatically search for GPS satellite signals and update the coordinate and time to camera after positioning successfully. At outdoors, after the correct connection of the camera and external display, switch to the ON position to enter the TEST mode, the GPS module begins to automatically search the signals for position and will show prompt...

  • Page 18: Automatic Infrared Sensing Shooting

    In the ON mode, the 4G module will be activated to LBS positioning and update the time to camera when camera starts searching for GPS satellite signals per day. Attention: Both GSP and LBS has a function of updating the time of the camera(some areas do not support LBS), pls take the latest updated time as the criterion.
  • Page 19 The trigger time varies among different scouting camera brands on the market, generally from 1 to 5 plus seconds. Our LTL ACORN scouting camera has an impressive 0.8 seconds trigger time. The shorter of the trigger timer , the higher possibility to capture the animal.

  • Page 20: Brightness Adjustment Of Night Picture

    sensing area of the centre PIR, the system is designed to be powered off after 5 seconds. 3、 Enhanced the camera's anti-jamming capability. As the camera is placed in different environments, it may be subject to varying electromagnetic interference. The camera uses a dual-PIR design, only triggers to take picture when both sides of the PIR are detecting the game, to avoid false shooting caused by insufficient capability of anti-interference of single PIR.
  • Page 21 SMS to the phone number of the SIM card in the camera, the camera will shoot immediately and send to E-mail, FTP or Ltl Acorn Camera Cloud System (or follow the remote control command to respond corresponding functions.).

  • Page 22: Camera Photo Encryption Function

    Ltl Acorn. Attention: When the encrypted original pictures are uploaded to E-mail, FTP or Ltl Acorn Cloud System, they should be downloaded and decrypted before viewing but not viewed directly（When the 'Send Image Size' menu is set to 'Thumbnail', the unencrypted thumbnail will be received）.

  • Page 23: Advanced Settings

    ADVANCED SETTINGS 3.1 Set up Parameters on Camera The LTL ACORN trail camera comes with preset manufacturer settings. You can change the settings to meet your requirements. Please make sure the camera is in the TEST mode. After correctly inserting the external button...
  • Page 24 01 Photo, 02 Select the number of burst shooting Picture No. Photos, 03 Photos at per trigger. Set length of video as required, camera will start recording video as preset length after it is automatically triggered in ON mode and stop recording till preset...
  • Page 25 Select ON the camera or video will automatically mark the time stamp and the photo can show the camera ID, coordinates, temperature and moon phase. Notice: the temperature shown is On, Off Time Stamp the internal temperature of the camera, the camera will heat at work, it makes the difference between internal and external temperature and the difference...
  • Page 26 Select On to assign an ID for the camera with digits and/ Serial No. Off, On alphabets, 0~9 and A~Z, the ID will be imprinted on photo with time stamp On. Select On, you can set the time period of automatic cycle shooting, and the camera will automatically take pictures/videos...

  • Page 27: File Format

    3.2 File Format All photos are in JPEG format and video in AVI format of H.264. Ltl-6511-4G(EXT.LCD) saves files in folder DCIM\100IMA4G in the SD card, Picture would be named like IMAG0001.JPG and video like IMAG0001.AVI. You can retrieve the SD card from camera and connect with computer with a SD card reader, view the files on computer directly.
  • Page 28 Ltl Acorn Camera Status Cloud System for email. FTP: Set FTP parameters and save directory. Ltl Acorn Camera Cloud System: Set upload parameters of Ltl Acorn Camera Cloud System . Auto Settings: The camera with pre-load setting of main operators Operator...
  • Page 29 E-mail, FTP or Ltl Acorn Camera Cloud System after Send Image Full Image, shooting. Size Thumbnail Thumbnail: camera would send thumbnail to E-mail FTP or Ltl Acorn Camera Cloud System after shooting (Video cannot be sent in Thumbnail mode).

  • Page 30: Set Up Camera On Pc

    Obtain the CD from the gift box and insert into PC, the external disc drive may be needed if the PC without the disc drive. Then run the 4G-Setup.exe software from the CD. Or download the software from website of Ltl Acorn: http://www.ltlacorn.cn/?languageId=2 (Download→PC SETUP Download→ PC SETUP--4g setup.exe)
  • Page 31 Double click the 4G-Setup.exe icon, you will see below page : Click to choose the camera model as request. Click to choose the software language of the interface. Click to enter camera setting interface:...
  • Page 32 Set the camera as your requirements. Please refer to section 3.1 Set up Parameters on Camera for better operation. Click choose the save directory, SD card root directory is recommended (connect SD card to computer with SD card reader first).

  • Page 33: Sms Remote Control & Table Of Command Code

    Click and the below window will pop out: Then click to exit. A file named menu.dat has been created and saved in the selected directory, before inserting the SD card into camera, please copy the menu.dat file to the root directory of the SD card if you didn’t choose SD card to save the file before.
  • Page 34 number or a combination of number and letter), and lastly a pound/hash sign (#).  Both capitalized and non-capitalized letters can be used in a same command.  Do NOT leave any spaces between any of the letters and symbols. ...
  • Page 35 Table of Command Code Command Function of Example Meaning Code Command Code Mode: Camera (0), Video (1), Camera+ 01*1# set to video mode Video (2) Image Size: 12MP (0), 02*1# 5MP (1), 2MP (2) Video Size: 1080P (0), 03*1# 720P 720P (1), VGA (2) Picture Number: 01 Photo (0), 02 Photos...
  • Page 36 4G Send Status: Off (0) 11*0# Close 4G Recipient Phone 12*198888888 Phone Number: Number 1: Maximum 19888888888 48 types Recipient Phone 13*198888888 Phone Number: Number 2: Maximum 19888888888 48 types Recipient Email 1: 14*info1@ltlac Email Address: Maximum 48 types orn.cn# info1@ltlacorn.cn Recipient Email 2: 15*info2@ltlac...
  • Page 37 (E-mail, FTP or send it as the Ltl Acorn Camera send mode Cloud System). preset. Note: The camera will only respond the phone remote control command of ‘60,61,62’ when the module is in the sleep function status, or you can...

  • Page 38: View Local Mpno Name And Signal Strength On Tft Screen

    NO MDM: 4G module is not found or detected. Features and Working Condition of 4G Wireless Module Ltl-6511-4G camera can automatically take photo or video and back to E-mail, FTP or Ltl Acorn Camera Cloud System when it works with 4G wireless...
  • Page 39 If you have the Timer on, please make sure the specified time of timer is in the period will send picture.  Make sure the 4G Send Options is E-mail, FTP or Ltl Acorn Camera Cloud System.  The camera is stationary while working.

  • Page 40: E-Mail Uploading Function

    E-mail Uploading Function Ltl-6511-4G series cameras have a function of email uploading, which can send the files record by camera to the email set by the user. To use this function, first connect the external display, turn the switch to the ON to enter...

  • Page 41: Set Up E-Mail Parameters On Pc

    4.2 Set up E-mail Parameters on PC Double click the 4G-Setup.exe icon to enter Setup homepage: Click to choose the camera model as request. Click to enter camera setting interface:...
  • Page 43 4G parameter settings interface has two pages, click to turn to next page, click to turn to the previous page.
  • Page 44 In this interface you can set 4G Send Options “Email”, the network parameters of the SIM card operator (select the operator network parameters, or manually enter the URL, gateway, APN, port settings, etc. according to the prompt), sender E-mail parameter settings, etc. Click to set the receiver E-mail, 4G sending option, mobile number and E-mail for camera remote control, remote control interval, etc.

  • Page 45: Ftp Uploading Function

    FTP Uploading Function Ltl-6511-4G series cameras have a function of FTP uploading, which can upload the files record by camera to the appointed FTP server. To use this function, first connect the external display, turn the switch to the ON to...

  • Page 46: Set Up Ftp Parameters On Pc

    5.2 Set up FTP Parameters on PC After formatting the SD card on camera, retrieve the SD card and insert into PC. The SD card reader may be needed if your PC cannot read SD card directly. The software 4G-Setup.exe icon is as below: After double-click 4G-Setup.exe software, the window appears below: Click to choose the camera model as request.
  • Page 48 4G parameter settings interface has two pages, click to turn to next page, click to turn to the previous page. Select “4G Send Options” as “FTP” in ”4G Parameter Settings” window:...
  • Page 49 Set up “Server”, “Port”, “User name” and “Password” in “FTP Settings” and the FTP directory for uploading. Set up “Sending Image Size”, “Send Mode”, “Save Path” and remote control parameters in the window of “4G Send Settings”. After finishing setting, click , the below prompt window would be shown when generate the file successfully: Please click the close button...

  • Page 50: Ltl Acorn Camera Cloud System Settings

    “4G Send Status”, then press key to choose “Ltl Acorn Camera Cloud System”, the Ltl Acorn Camera Cloud System parameters can be set. The related menu items of the Ltl Acorn Camera Cloud System are as below: Parameter Settings Descriptions Registered email: user’s login...

  • Page 51: Set Parameters Of Ltl Acorn Camera Cloud System On Computer

    Set Parameters of Ltl Acorn Camera Cloud System on computer Double click to open the 4G-Setup.exe software to see below window: Click to choose the camera model as request. Click to enter camera setting interface:...
  • Page 53 There are two pages of 4G parameter setting interface, click to switch to the next page, at the next page, click switch to the previous page.
  • Page 54 In the "4G Parameter Settings" window, select "4G Send Options" as "Ltl Camera Cloud System": Select the operator parameters as required. Set "Registered mail", "Login Password" and "SIM card phone number" in the "Ltl Camera Cloud System Parameters" group box. In the "4G Send Settings"...

  • Page 55: Ltl Acorn Camera Cloud System Remotely Modifies Camera Parameters

    Ltl Acorn Camera Cloud System remotely modifies camera parameters Set the 4G send options as Ltl Acorn Camera Cloud System, log in Cloud System on computer or mobile APP, you can remotely modify camera parameters though the camera parameters setting function on the Ltl Acorn Camera Cloud System.

  • Page 56: Ltl Acorn Camera Cloud System Introduction

    Ltl Acorn Camera Cloud System Introduction Ltl Acorn Camera Cloud System is a comprehensive network camera management system integrating camera image reception, image management, camera management, environmental data analysis and...
  • Page 57 Click "Quick Registration", enter the account and password, click on the login button to login the Ltl Acorn Camera Cloud system. Click " Mobile LtlAcorn Cloud " to enter the download page of Ltl Acorn Camera Cloud System Mobile APP, download and install the mobile phone APP according to the prompts.

  • Page 58: Ltl-6511-4G Series Products

    Ltl Acorn Camera Cloud System. Note: Please refer to the detailed operation instructions of Ltl Acorn Cloud System, Ltl Acorn Cloud System mobile APP and WeChat official account in the Use help of Ltl Acorn Camera Cloud System website.

  • Page 59: Important Information

    IMPORTANT INFORMATION 8.1 Power Supply Ltl-6511-4G Series scouting camera works on electricity up to 12 voltages. The 4 AA batteries in the bottom of the camera, 6 cells of 18650 lithium batteries in the battery box, two paths power are isolated and do not charge or discharge others.

  • Page 60: Auto Adjustment On Video Length

    8.5 850nm and 940nm IR LED There are two types of IR LED for optional of Ltl-6511-4G series scouting camera, 850nm and 940nm. For Ltl-6511-4G series (standard angle lens), 850nm provides flash distance up to 115 feet/ 35m whereas 940nm up to 59 feet/ 18m.

  • Page 61: Low Battery Alert

     Set the camera to have burst shooting, but some pictures were not sent: The camera is able to send constantly, but if the signal is too weak, it may not work stably.  Receive partial image or some is incomplete: The camera was in motion when sending pictures.

  • Page 62: Use Camera Outdoors

     Do not mix and use with other different types of batteries.  Do not connect the battery electrode incorrectly in the charger or camera.  Please check the battery regularly and replace abnormal battery in time.  The battery should be placed in a cool, dry and well-ventilated area. ...

  • Page 63: Introduction Of 18650 Lithium Battery

    9.3 Introduction of 18650 Lithium Battery Ltl Acorn provides two types of 18650 Lithium battery for different working temperatures of -10℃ and -40℃. Users can choose battery according to the actual working temperature of the camera. 18650 Lithium battery 18650 Lithium battery...
  • Page 64 Attention: The upgrade program of Ltl-6511-4G is not compatible to other models. In other word, an upgrade for Ltl-6511-4G only applies to Ltl-6511-4G model. If a camera is accidently upgraded by running a non-compatible program, it will quit working and needs to be sent back for repair.

  • Page 65: Remote Update Program Via Ltl Acorn Camera Cloud System

    Remote update program via Ltl Acorn Camera Cloud System The Ltl-6511-4G series camera with newly added function of remote update camera program via Ltl Acorn Camera Cloud System.The function of remote update program allows you to remotely update camera FW, Loader and module software.
  • Page 66 2、 Find the camera that needs to be updated in the camera manage list, click the edit button in operation line at the right side to pop up the edit window.In the window you can see the camera's current program version and the file selection buttos.
  • Page 67 right side of FW upload, pop up the file selection box. Find the camera software program 'FW65114G' you want to update through the open file window that pops up in the browser , choose and click ‘Open’, you can see the FW65114G.bin appears at the right side of select file button;...

  • Page 68: Limited Warranty

    It does not cover normal wear of the product. Please contact our tech support department to determine the nature of the problem before you return a LTL ACORN product under this warranty for repair or exchange.

  • Page 69: Appendix I: Technical Specification

    Appendix I: TECHNICAL SPECIFICATION Model Parameters Image Sensor 5 Mega Pixels Color CMOS FOV=55° ; Auto IR-Cut Lens FOV=100° ; Auto IR-Cut 940nm (55 degrees standard lens flashes 18 meters/ 59 feet) 940nm (100 degrees wide angle lens flashes 13 meters/ 42 feet) IR Flash 850nm (55 degrees standard lens flashes 35...
  • Page 70 Time from trigger to 0.8 Seconds finish shooting Trigger Interval 0sec - 60min; Programmable Photo Burst 2~60sec ; Auto (3~30 seconds Automatic Video Length adjustment; Programmable; Camera + Video First take Picture then Video Playback Zoom In 9-step zoom + parallel move to view details On/Off;...
  • Page 71 as 1 hour, Send the text of command 60/61 or 62 on mobile, camera can receive SMS command and transmit the image file within 1 hour. The module normally cuts off the power and does not consume power, it will work after camera shooting and then transmit the image file.
  • Page 72 12V~24V (optional) (DC power supply standard of customized version is 6V~12V,1~2A) LTL ACORN weak light solar panel can be used Solar panel charging to charge the rechargeable battery in the (optional) camera, saving energy and the battery can work for long time without changing.

  • Page 73: Appendix Ii: Package Contents

    Appendix II: PACKAGE CONTENTS Part name Quantity (PCS) Digital Camera External button control box with display screen Environmental data acquisition device(optional) Strap Steel cable / lock (optional) External DC Power Cable (optional) Warranty Card Note: About the external button control box with display screen, users can choose to buy or not.

  • Page 74: Appendix Iii: Illustration Of Battery Box Installation

    Appendix III: Illustration of Battery Box Installation 1、Please follow the positive and negative labels on battery box to load the 6x18650 lithium batteries. 2、Close the camera with battery box. Align and close both sides...
  • Page 75 3、Hook camera body with two lock buckles on side of battery box. Hook up the camera catching groove 4、 Snap on lock buckles.

  • Page 76: Appendix Iv: Place And Install Camera

    Appendix IV: Place and Install Camera 1、 Mount on tripod There is a 1/4" nut hole on the back of the camera battery box, fix the camera to tripod by screw up the nut, and then adjust shooting angle. Nut hole 2、...
  • Page 77 Plastic Conical Plastic Pillar pillar hole Cable hole...
