  • Page 1 Ltl Acorn Mobile Scouting Camera Ltl-5310 Series SMS remote control 720P video...
  • Page 2: Table Of Contents

    3.4 Set up MMS Function on PC............... 15 3.5 SMS remote control................17 3.6 Camera Working with MMS..............21 3.7 View Local MNOP Name and Signal Strength on TFT display... 22 Ltl-5310 Series Products................24 4.1 Parts....................24 4.2 Models for Purchase................24 Important Information..................24 5.1 Prevent From Short-Circuits..............
  • Page 3: General Information

    GENERAL INFORMATION Introduction The Ltl Acorn 5310 Series (Model Ltl-5310A/MC and Ltl-5310MM) is the third generation of our Ltl acorn scouting camera. Bundled with the MMS-module (Multimedia Messaging Service) battery box (Part # LTL-MM1)standard scouting camera (Part # Ltl-5310MC) can be upgraded to work as a remote cellular camera.
  • Page 4: Application

    Serial Number setting enables you to code locations in the photos. This helps multi-camera users identify the location when reviewing the photos Built-in 2 ¼” TFT color display to review images and videos Date, time, temperature and moon phase can be stamped in the pictures Lockable and password protected MMS image sizes: 640 x 480...
  • Page 5 LED IR Flash Light Sensor Motion Indicator Lens Prep Main Sensor Sensor Lock Hole Figure 1.1: Front View of Ltl-5310M Figure 1.2: Bottom View of Ltl-5310M...
  • Page 6 The camera provides the following connections for external devices: USB 2.0 port, SD card slot, TV out jack, and external DC power in jack. The 3-way Power/Mode Switch is used to select the main operation modes: OFF, ON and TEST. To power up the camera, install four NEW high-performance alkaline or lithium AA batteries in the camera.
  • Page 7: Quick Start

    QUICK START 2.1 Insert SIM Card (Only for Model Ltl-5310MM) You need to purchase the SIM card from your local Mobile Phone Network Operators(MPNO), making sure they provide Multimedia Messaging Service (MMS). Ask them for the relevant information to configure the MMS settings on your camera.(Please reference 3.4 Set up MMS Function on PC in the Advanced...
  • Page 8: Insert Sd Card

    When battery level gets low, the Motion Indicator in the LED array will flash blue. On Model Ltl-5310MM, a “Battery Low” text alert will be sent automatically to the user’s cell phone or email account. 2.3 Insert SD Card The camera does not come with internal memory. So it will not work without a SD (Secure Digital) memory card or SDHC (High Capacity) card.
  • Page 9: Enter Live Mode

    PIR sensor. By doing this test, you can find the best placement when mounting and aiming the Ltl Acorn camera. In general, you are recommended to place the camera 3 to 6 feet (1 to 2 meters) above the ground.
  • Page 10: Advantages Of Prep Sensors

    With the unique side prep PIR sensors design, our Ltl Acorn solves this issue. The combination of the two side prep sensors and the main sensor comes up with a 100 to 120°...
  • Page 11: Advanced Settings

    ADVANCED SETTINGS The Ltl Acorn trail camera comes with preset manufacturer settings. You can change the settings to meet your requirements. Please make sure the camera is in the test mode. 3.1 Parameter Settings Press “MENU” key to enter/exit the menu. Press ,...
  • Page 12 Set Clock Enter Press Enter to set up date and time. Internal capacitor will retain the clock time for up to 7 minutes when changing batteries. Picture No. (affects 01 Photo, 02 Photos, Select the number of photos taken in still photos only) 03 Photos sequence per burst in Camera mode.
  • Page 13 Timer 2 Off, On Select On if you only want the camera to work within a specified time period every day. For instance, if the starting time is set at 18:35 and the ending time at 8:25, the camera will function from 18:35 the current day to 8:25 the next day.
  • Page 14: File Format

    In the submenu, you can set the daily number of pictures sent via MMS. 0 stands for Unlimited. 1- 99/Day gives you flexibility sending up to 99 pictures per day SMS remote control 0, 1~24, Off represents the SMS receipt time, “0” indicates 10mins, “1~24”...
  • Page 15 from http://www.sendspace.com/folder/7zd6ic The following window prompts: Click on Camera Setup, and you will see the following interface:...
  • Page 16 Getime Set up the camera based on your need. Click on to retrieve the Select computer time. Click on to choose the directory to save your settings, usually under the root directory of the SD card (You need to insert the SD card in the SD card reader and plug it in your computer.) Then, click on Generate .
  • Page 17: Set Up Mms Function On Pc

    purchasing the MMS-module battery box (Part # LTL-MM1), skip the following step and go directly to 3.4 Set up MMS Function on PC. If your camera is Model Ltl-5310MC, the standard scouting camera, you’re done with the camera setting. Click on Exit to exit the interface. Retrieve the SD card from the computer and insert it in the camera.
  • Page 18 First, you need to choose how you like to set up the MMS Mode --Auto or Manual. If you choose Auto, then you need to choose the country and the Mobile Phone Network Operator (MPNO). After doing that, the below section will populate with parameters pertaining to the selected MPNO, such as URL, APN, Gateway and Port.
  • Page 19: Sms Remote Control

    If you choose Manual to manually input all the parameters, you need to contact your Mobile Phone Network Operator (MPNO) to have them provide you all the required information. Note: Because each local MPNO has their own settings for their MMS service, and those settings can change over time, we recommend you verify all the settings with your MPNO, even you choose Auto to let the system to configure the settings.
  • Page 20 Video size VGA(0), QVGA (1) ,720P 03*1# QVGA Picture No 01 photo 02 photo 04*2# 3 photos 03 photo Video length 1-60 indicates different value 05*59# Interval beginning with S represents Second, with M m represents minute 1-60 06*s30# Interval:30s indicates different value Serial No take camera...
  • Page 21 All the order code ends with“*”, all the value ends with“#” LTL01*0#02*2#06*S30#07*10A3Z#AA Definition camera mode 1.3MP interval:30s serial No: 0A3Z For SMS remote control setting, different value with different extra power consumption, “0” the highest, “off” zero. Maximum 60 bytes for all the SMS content, for multiple parameters setting please send by more times.
  • Page 22 Select your language and the correct model from the drop-down list. Click on Smtp Setup, and you will see the following menu: In Auto mode, first select country and operator. In manual mode, you fill in APN / Account / Password. This parameter you can find from your mobile operator. Write in your E-mail server / port / sender E-mail / Password and Recipients E-mail.
  • Page 23: Camera Working With Mms

    SMS remote control, the value ranges from “0”to “off “which represents the SMS receipt time, “0” indicates 10mins, “1~24” indicates the interval time 1~24h to receive SMS, “off” indicates the close of the SMS remote control. Select the related value based on your own need. Then press save parameter to SD card, generate and insert SD card into camera and power on the camera, done.
  • Page 24: View Local Mnop Name And Signal Strength On Tft Display

    The Timer function is OFF. If you have the Timer ON, make sure you are in the specified time period when expecting incoming MMS pictures. Make sure MMS Status is not set OFF or SMS. The setting is “0”, or the daily limit has not been reached. If the daily limit has been reached, you can reset that number on your computer or on the TFT display.
  • Page 25 CREG: SIM card is password-protected, or deactivated due to zero balance in the account, or not able to register with the GSM system. CGREG: Not able to register with GPRS network. COPS: Searching for the MNPO of the SIM card. Once it is found, the operator’s name and the signal strength will show on the screen.
  • Page 26: Ltl-5310 Series Products

    LTL-5310M SERIES PRODUCTS 4.1 Ltl-5310M Series Consists of Three Parts: 1. Ltl-5310M Camera 2. LTL-BM1 Standard battery box (without MMS-module) 3. LTL-MM1 MMS-module battery box 4.2 Models for Purchase: Ltl-5310MM = Ltl-5310M Camera + LTL-MM1 MMS-module battery Ltl-5310MC = Ltl-5310M Camera + LTL-BM1 Battery box LTL-MM1 ----- MMS-module battery box Ltl-5310M Camera LTL-MM1 MMS-...
  • Page 27: Power Supply And Battery Box

    5.2 Power Supply and Battery Box Ltl-5310M Series camera can work on up to 12 voltages. The 4 AA batteries in the camera, the 4 AA batteries in the battery box, and the external power supply form a three-path parallel circuit. Each path is isolated from others and does not charge nor discharge others.
  • Page 28: 850Nm And 940Nm Ir Led

    thirty percent more full-length video clips. Besides that, when battery power gets low, our camera automatically shortens the video length so as to take more clips of more game. As a result, the total number of video clips doubles, even triples that of products of its kind, which provides users with more useful information.
  • Page 29: Faqs On Mms Function

    5.7 FAQs on MMS Function x I set up a new receiving phone number. But the MMS pictures are still being sent to the old number. What should I do? Switch the camera OFF. Wait for at least two minutes. Then switch it ON.
  • Page 30: Firmware Upgrades

    FIRMWARE UPGRADES 6.1 Firmware Upgrades The manufacturer reserves the right to upgrade the camera and the firmware. Follow the steps below to implement the upgrades: Install batteries and the SD card. Back up SD card contents. Format SD card on cmera. Retrieve the SD card and plug it in your computer (SD card reader may needed).
  • Page 31: Warranty Information

    LIMITED WARRANTY We take great pride in our products. We always stand behind our promises. We provide a leading warranty term and service. Buying a Ltl Acorn product, you are covered under the limited warranty. We guarantee our products to be free of defects in materials and workmanship under normal use and service for a period after registered date of purchase.
  • Page 33 Stand-by Current Stand-by Time 3 6 Months 4xAA 8xAA Auto Power Off Auto power off in 2 minutes while no keypad controlling Power 150mA (+650mA when IR LED lights up) Consumption Low Battery 4.2~4.3V Alarm Interface TV out (NTSC); USB; SD Card Slot; 6V DC External Mounting Strap;...
  • Page 34: Appendix Ii Package Contents

    Appendix II: PACKAGE CONTENTS Part Name Quantity (Ltl- Quantity Ltl- LTL-MM1 5310MC) 5310MM MMS-module battery box Digital Camera Additional Battery 1 (Standard) 1 (With MMS 1 (With MMS module) module) TV AV IN Cable USB Cable Strap External DC Cable (optional) Installation CD Warranty Card...
  • Page 35: Appendix Iii Instruction On Installing Battery Box
