EVAL-AD7606BFMCZ
Link Default Position Function
JP3 A Use to select the V
In Position A, the
In Position B, the
JP4 A The EVAL-AD7606BFMCZ evaluation software controls the RANGE pin. If using the EVAL-AD7606BFMCZ board
in standalone mode, this jumper allows selection of the analog input range in hardware mode. In this case,
change the R20 resistor to a 0 Ω link.
In Position A, the RANGE pin is tied to V
In Position B, the RANGE pin is tied to AGND, and the ±5 V range is selected.
In software mode, this pin is ignored.
JP5 A The EVAL-AD7606BFMCZ evaluation software controls the PAR/SER SEL pin. If using the EVAL-AD7606BFMCZ
board in standalone mode, this jumper allows digital interface selection. In this case, change the R19 and R21
resistors to 0 Ω links
In Position A, the PAR/SER SEL pin is tied to V
In Position B, the PAR/SER SEL pin is tied to AGND, and the parallel interface is selected.
The EVAL-AD7606BFMCZ evaluation software controls the REF SELECT pin. By default, the internal reference is
JP6 A
selected. If switching to the external reference is required through the EVAL-AD7606BFMCZ evaluation
software, R1 must be populated. If using the EVAL-AD7606BFMCZ board in standalone mode, this jumper
allows reference selection. In this case, change the R13 resistor to a 0 Ω link.
In Position A, the REF SELECT pin is tied to AGND, the internal reference is disabled, and the external reference is
selected. R1 must be populated.
In Position B, the REF SELECT pin is tied to V
unpopulated.
S1 Open The EVAL-AD7606BFMCZ evaluation software controls the REF SELECT pin. If using the EVAL-AD7606BFMCZ in
standalone mode, these switches can select the logic level on the OSx pins.
User Guide
source for the AD7606B.
DRIVE
AD7606B is supplied with 3.3 V V
AD7606B is supplied with 3.3 V from the
Rev. A | Page 5 of 15
from the ADP7118.
DRIVE
EVAL-SDP-CH1Z
, and the ±10 V range is selected.
DRIVE
, and the serial interface is selected.
DRIVE
, and the internal reference is enabled and selected. R1 must be
DRIVE
UG-1225
(SDP-H1).
