Sway Command™ Controller
Operation
1. When Sway Command™ detects excessive sway, the light
pod will blink red and the tow operator may feel the trailer
brakes activate until the sway is dampened.
2. Sway Command™ will "wake up" if it senses external brake
activations. During wake up, Sway Command™ performs
self-checks and alternately fl ashes the light pod lights green
and red.
Note: The Sway Command™ light pod will be green if no
issues are detected. If an issue is detected, the light pod will
blink green once, followed by a number of red fl ashes. See
troubleshooting for a description of the various blink codes.
3. Sway Command™ will enter a low power mode after 10
minutes when it senses no tow vehicle brake activation or
movement. The Sway Command™ light pod will turn off
when it powers down.

Light Codes and Troubleshooting

In the event a tow vehicle brake controller detects a fault after
Sway Command™ detects a sway event, manually activate the
tow vehicle brake controller a few times to clear the fault.
Light Flash Why?
Unit is not
powered
Off
and not
active.
Green, Wake up
Red, Re- self-checks
peat in progress.
www.lci1.com (574) 537-8900
What Should Be Done?
Unit is in low power.
Activate tow vehicle
brake to wake unit.
Unit is not connect-
ed to DC 12V power
supply. Verify wiring.
After a few seconds,
the unit will complete
self-checks, and set
the lights green if unit
is ready, or a fl ashing
code if an issue is
found.
Rev: 02.16
Sway Command™ (Prepped Unit Only)
Aftermarket Install
Manual
Light Flash Why?
Unit is
Green awake and
Solid monitoring
for sway.
Red Blink Sway Com-
(1/2 sec- mand™ de-
ond on, tected sway
1/2 sec- event and
ond off, is activating
repeats) brakes.
A short to 12
Green, 2
volt detect-
Red
ed.
Not connect-
Green, 3
ed to trailer
Red
brakes.
A short to
Green, 4
ground de-
Red
tected.
Green, 5 Low voltage
Red detected.
Red Solid
Red Fast
Unit is not
Blink
functional.
(100ms
on, 100ms
off, re-
peats)
7
Sway Command™ Prepped Unit Aftermarket Install Manual
What Should Be Done?
Every 5 seconds,
there will be a brief
time the green LED
turns off for a fraction
of a second. This
indicates unit is func-
tional.
After sway subsides,
light will return to
green.
Verify the break away
switch is not activat-
ed.
Verify blue brake wire
not shorted to 12 volt.
Verify the blue brake
wire is connected to
the trailer brakes.
Verify the blue brake
wire is not shorted
to ground or trailer
frame.
Verify tow vehicle and
tow battery are at 12
volts.
Disconnect harness,
wait 10 seconds.
Connect harness. If
light comes on solid
red, unplug unit and
contact service de-
partment.
