SURESHADE™ POWER BIMINI MANUAL OVERRIDE

Purpose

This document outlines the procedure to manually close the SureShade
top will not respond to a powered "close" command.
Note: Images used in this document are for reference only when assembling, installing and/or operating
this product. Actual appearance of provided and/or purchased parts and assemblies may differ.

Safety

Read and understand all instructions before installing or operating this product. Adhere to all safety labels.
Never attempt to operate the top or perform the manual override procedure while the boat
Do not open Bimini top in excessively high winds. High winds could cause product damage, which

Resources Required

• 1-2 people, depending on task.
5/32
•
" hex wrench (provided with models manufactured May 2020 and later)
• Zip ties, hook-and-loop strips or rope
Rev: 09.21.20
may result in personal injury.
Moving parts can pinch, cut or crush. Keep clear and use caution.
MARINE
is in motion
Page 1
Power Bimini Top in the event the
TM
CCD-0003693

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SURESHADE POWER BIMINI and is the answer not in the manual?

Questions and answers

Related Manuals for Lippert Components SURESHADE POWER BIMINI

Summary of Contents for Lippert Components SURESHADE POWER BIMINI

  • Page 1 SURESHADE™ POWER BIMINI MANUAL OVERRIDE MARINE Purpose This document outlines the procedure to manually close the SureShade Power Bimini Top in the event the top will not respond to a powered "close" command. Note: Images used in this document are for reference only when assembling, installing and/or operating this product.
  • Page 2 SURESHADE™ POWER BIMINI MANUAL OVERRIDE MARINE Procedure If the Power Bimini Top will not close (retract) a manual override of the Power Bimini Top must be done before storing, towing or operating the pontoon. Unzip the front pocket of the Bimini canvas. Have a second person push forward on the rear frame to relieve some pressure off the canvas and hold up the rear and middle frames when the canvas is being unzipped.
  • Page 3 SURESHADE™ POWER BIMINI MANUAL OVERRIDE MARINE Use the 5/32" hex wrench (Fig. 3A) to remove the two 1/4" hex cap screws (Fig. 3B) from the front frame (Fig. 3C) on both actuators (Fig. 3D). Fig. 3 Lift the front frame (Fig. 4A) off of the port and starboard actuator gear handles (Fig. 4B). Fig.
  • Page 4 SURESHADE™ POWER BIMINI MANUAL OVERRIDE MARINE Place the front frame assembly on top of the rear frame (Fig. 5). Fig. 5 Front Frame Assembly Zip the front canvas pockets over the loose front frame to help hold it in-place. Note: Canvas top not shown for clarity. 10.
