Mounting
24
6.1.4

Special installation situations

Tanks with spray ball for probe cleaning
1
Mounting close to vessel wall
Mounting the probe close to the vessel wall improves the cleaning effect when a spray ball
is used. The cleaning jet is directed onto the probe via the vessel wall. As a result, the
probe is also cleaned in places the spray ball jet would normally not reach. You only require
one spray ball for this probe arrangement.
Mounting in the center of the vessel
If the probe is mounted in the center of the vessel, the use of a second spray ball may be
necessary. These balls should then be mounted to the left and right of the probe.
Levelflex FMP53 FOUNDATION Fieldbus
2
Endress+Hauser
A0014131
