Levelflex FMP53 FOUNDATION Fieldbus

Distance

Navigation
Description
Additional information

Level linearized

Navigation
Description
Additional information
Endress+Hauser
17.4.4

"Measured values" submenu

Navigation  Diagnostics → Measured val.
 Diagnostics → Measured val. → Distance
Displays the measured distance D
or threaded connection) and the level.
 45 Distance for liquid measurements
The unit is defined in the Distance unit parameter (→  126).
 Diagnostics → Measured val. → Level linearized
Displays linearized level.
The unit is defined by the Unit after linearization parameter →  147.
between the reference point (lower edge of the flange
L
D
L
Operating menu
A0013198
183
