- Page 1 E51.D7S Series Piezo Controller User Manual Version: V1.0 This document describes the following products: ■ E51.D7S Servo controller SGS sensor 7 channels...
- Page 2 DECLARATION Declaration! This user manual is a integrated user manual of the E51.D7S series piezoelectric controller. Please read this user manual carefully before using this controller. Follow the instructions in the manual during use. If there is any problem, please contact us for technical support. If you do not follow this manual or disassemble and modify the product yourself, the company will not be liable for any consequences arising therefrom.
-
Page 3: Table Of Contents
Contents 1.Security ………………………………………………………………………………………………………………………… 2 1.1 Introduction …………………………………………………………………………………………………………… 2 1.2 Safety Instructions ………………………………………………………………………………………………… 2 1.3 Notes ……………………………………………………………………………………………………………………… 2 2. Introduction ………………………………………………………………………………………………………………… 3 3.Driving Principle …………………………………………………………………………………………………………… 3 4.Open-Box Inspection …………………………………………………………………………………………………… 4 5.Installation …………………………………………………………………………………………………………………… 4 5.1 Installation Notes …………………………………………………………………………………………………… 4 5.2 Ensure Ventilation …………………………………………………………………………………………………… 4 5.3 Power Supply …………………………………………………………………………………………………………... -
Page 4: Security
The latest user manual is available for download on CoreMorrow website. When operating the E51.D7S, the user manual should be placed near the system for easy reference in time. If the user manual is missing or damaged, please contact CoreMorrow customer service department. -
Page 5: Introduction
supplements or technical descriptions. If your user manual is incomplete, it will miss a lot of important information, cause serious or fatal injuries, and cause property damage. Please read and understand the content in the user manual before installing and operating the E51.D7S. Only professionals who are authorized to meet the technical requirements could install, operate, maintain and clean the E51.D7S. -
Page 6: Open-Box Inspection
When you receive the device, unpack the package and check whether the surface of the device is damaged.If there is damage which may have occurred during shipment, please contact Coremorrow in time.Check whether all accessories are complete according to the packing list. Please take good care of the original packaging for subsequent maintenance. -
Page 7: Cable Connection
5.4 Cable Connection When the power supply is disconnected, the swing mirror cable is connected to the E51. D7S controller interface. Note that the number of the piezoelectric actuator corresponds to the number of the controller. Connect the RS-422 interface via cable to a computer or other device with RS-422 interface. -
Page 8: Interface
E51.D7S Series Piezo Controller User Manual 6.3 Interface DB15-HD interface CH1 driving output and sensor connector Pin definition Pin definition CH2 CH3 sensing power supply CH2 drive output ground CH3 drive output CH1 sensing power supply ground CH3 sensor input signal -... - Page 9 Pin definition Pin definition CH6 drive output CH4 sensing power supply ground CH6 sensor input signal - CH4 constant voltage drive output CH6 sensor input signal + CH5 sensor input signal - Sensor power supply: DC 10V CH5 sensor input signal + CH4 drive output CH4 sensor input signal + CH5 CH6 drive output ground...
-
Page 10: Operating Calculation
E51.D7S Series Piezo Controller User Manual 7.Operating Calculation ● Average output（Sine wave operation mode） Pa ≈ Upp • Us • f• Cpiezo Pa=Average output[W] Cpiezo=Piezo actuator capacitance[F] Upp=Peak and peak drive voltage [V] f=Operating frequency of the sine wave[Hz] Us=Drive voltage[V]（（Vs+）-（Vs-））... -
Page 11: Transportation And Storage
9.1 Disposal When disposing of old equipment, please abide by the national regulations and local regulations.Please dispose of the old equipment properly.Please contact CoreMorrow for the upgrade and replacement of old equipment in order to meet the customer's handling of system products. -
Page 12: After-Sales Service
Any part of E51.D7S is dismantled, there will be no warranty service. E51.D7S is a precision instrument which should be handled with care. In case of any problem, please record the problem and contact CoreMorrow to be repaired by professional technicians.
