Altronix Trove2M2R Installation Manual page 5

Configuration of Altronix Power Supply and/or Sub-Assembly Boards and Mercury Boards
1. Fasten spacers onto metal pems configuration of backplane depending on the board (Fig. 6, pg. 5).
2. Position module over corresponding spacers and fasten screws into spacers (Fig. 6a, 6b, pg. 5).
3. Mount backplane to enclosure with hardware.
Position Chart for the Following Models:
Altronix / Mercury
AL400ULXB2, AL600ULXB, AL1012ULXB, AL1024ULXB2,
eFlow4NB, eFlow6NB, eFlow102NB, eFlow104NB
ACM8(CB), ACMS8(CB), ACMS12(CB), LINQ8ACM(CB)
ACM4(CB), LINQ8PD(CB), PDS8(CB), PDS16(CB), VR6
LP1502, LP4502, MR52, MR16IN, MR16OUT
LP2500, MUX8
Genetec Cloudlink
Fig. 6
A
B C
Fig. 6a
Pan Head Screw
Power Supply
or
Sub-Assembly
Backplane
Spacer
Pem
Trove2M2R Installation Guide
TM2R:
C
C
Fig. 6b
Pan Head Screw
Mercury Board
Backplane
Spacer
Pem
D
D
Pem Mounting
A
B
C
D
E
F
D
D
F E
