HOLEMAKER HMPRO35-MS Operator's Manual

Portable magnetic drilling machine
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
HOLEMAKER PRO 50
HOLEMAKER HMPRO35-MS
HOLEMAKER PRO 50
Holemaker Portable Magnetic Drilling Machine
OPERATOR'S MANUAL
Holemaker Portable Magnetic Drilling Machine
Holemaker Portable Magnetic Drilling Machine
OPERATOR'S MANUAL
OPERATOR'S MANUAL
BEFORE USE
BEFORE USE
EYE PROTECTION
REQUIRED
EYE PROTECTION
REQUIRED
S
r e
a i
# l
Ver: 1.01 24/01/2020
Ver: 1.10
14/08/2015
S
r e
a i
# l
Ver: 1.10
14/08/2015
OPERATOR'S MANUAL
WARNING!
,
ENSURE EVERYONE USING THIS MACHINE READS AND UNDERSTANDS
WARNING!
ALL SAFETY AND OPERATING INSTRUCTIONS IN THIS MANUAL
,
ENSURE EVERYONE USING THIS MACHINE READS AND UNDERSTANDS
P
R
P
R
ALL SAFETY AND OPERATING INSTRUCTIONS IN THIS MANUAL
DRILLING MACHINE
WITH MAGNETIC BASE
HEARING PROTECTION
NEVER PLACE
REQUIRED
FINGERS NEAR
CUTTING AREA OR
MACHINE ARBOR
HEARING PROTECTION
NEVER PLACE
REQUIRED
FINGERS NEAR
CUTTING AREA OR
MACHINE ARBOR
ul. Elewatorska 23/1, 15-620 Białystok, Poland
O
3
6
M
S
O
3
6
M
S
LINE VOLTAGE
PRESENT
LINE VOLTAGE
PRESENT
D
a
e t
f o
P
r u
h c
D
a
e t
f o
P
r u
h c
.
.
BEWARE OF
ROTATING
MACHINE PARTS
BEWARE OF
ROTATING
MACHINE PARTS
a
e s
a
e s

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HMPRO35-MS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for HOLEMAKER HMPRO35-MS

Summary of Contents for HOLEMAKER HMPRO35-MS

  • Page 1 HOLEMAKER PRO 50 HOLEMAKER HMPRO35-MS HOLEMAKER PRO 50 Holemaker Portable Magnetic Drilling Machine OPERATOR’S MANUAL Holemaker Portable Magnetic Drilling Machine Holemaker Portable Magnetic Drilling Machine OPERATOR’S MANUAL OPERATOR’S MANUAL OPERATOR’S MANUAL WARNING! BEFORE USE ENSURE EVERYONE USING THIS MACHINE READS AND UNDERSTANDS...

  • Page 2: Table Of Contents

    HMPRO35-MS OPERATOR’S MANUAL LIMITED WARRANTY Industrial Tool & Machinery Sales (hereinafter referred to as ITMS) will, within twelve (12) months from the original date of purchase, repair or replace any goods found to be defective in materials or workmanship. This warranty is void if the item has been damaged by accident, neglect, improper service or other causes not arising out of defects in materials or workmanship.

  • Page 3: General Information

    HMPRO35-MS OPERATOR’S MANUAL PRO 36 MS 1. GENERAL INFORMATION 1.1. Application The PRO 35 MS is a drilling machine designed to drill holes with diameters of up to 35 mm (1-3/8’’) to a depth of up to 35 mm (1-3/8’’) by using annular cutters. It drills in surfaces that are flat, convex, or concave.

  • Page 4: Equipment Included

    HMPRO35-MS OPERATOR’S MANUAL PRO 36 MS 1.3. Equipment included Drilling machine with cooling system 1 unit bottle and chip guard Metal box 1 unit Handle 1 unit Handle adapter 1 unit Safety strap 1 unit 4 mm hex wrench with handle...

  • Page 5: Dimensions

    HMPRO35-MS OPERATOR’S MANUAL PRO 36 MS 1.4. Dimensions 309 mm (12-3/16’’) 243 mm (9-9/16’’) 1.5. Design Cooling system bottle Bottle valve lever Carrying handle MOTOR start button Control panel Spindle with arbor Chip guard MOTOR stop button Power switch Magnet switch...

  • Page 6: Safety Precautions

    HMPRO35-MS OPERATOR’S MANUAL PRO 36 MS 2. SAFETY PRECAUTIONS 1. Before starting, read this Operator’s Manual and complete proper occupational safety and health training. 2. Use the machine only in applications specified in this Operator’s Manual. 3. The machine must be complete and all parts must be genuine and fully functional.
  • Page 7 HMPRO35-MS OPERATOR’S MANUAL PRO 36 MS 20. Use the safety strap in all work positions. Attach the machine to a fixed structure by fastening the strap through the opening in the machine body. When working in horizontal position fasten the strap to the carrying handle. Never insert the strap into the buckle from the front.

  • Page 8: Startup And Operation

    HMPRO35-MS OPERATOR’S MANUAL PRO 36 MS 3. STARTUP AND OPERATION 3.1. Installing and removing the handle Install the handle by using the adapter as shown in Fig. 2. The machine can allow use by a left-handed person or in places hard to reach. To do this, install the handle at the opposite side of the machine.

  • Page 9: Installing, Removing, And Operating The Annular Cutter

    HMPRO35-MS OPERATOR’S MANUAL PRO 36 MS 3.2. Installing, removing, and operating the annular cutter Unplug the machine from the power source, and then rotate the handle to the right (1, Fig. 3) to raise the motor. Wear protective gloves and insert the proper pilot pin into the annular cutter (2).
  • Page 10 HMPRO35-MS OPERATOR’S MANUAL PRO 36 MS Fig. 4 shows how annular cutters work. As the cutter drills into the workpiece, the pilot pin retracts and the coolant gets into the cutter. After the drilling, the tightened spring causes the slug core to be pushed out.

  • Page 11: Installing And Removing The Cooling System Bottle

    HMPRO35-MS OPERATOR’S MANUAL PRO 36 MS 3.3. Installing and removing the cooling system bottle Rotate the handle (1, Fig. 6) to raise the motor. Next, place the cooling system bottle on the machine (2), and then attach the bottle hose to the hose fitting (3).

  • Page 12: Preparing

    HMPRO35-MS OPERATOR’S MANUAL PRO 36 MS 3.4. Preparing Before starting, clean steel parts, including the arbor, from anti-corrosion coating used to preserve the machine for storage and transport. Install the handle as described before. Select the proper annular cutter based on the hole size desired. Use a clean and dry cloth to wipe the arbor and cutter.
  • Page 13 HMPRO35-MS OPERATOR’S MANUAL PRO 36 MS Inverted drilling Vertical drilling CORRECT INCORRECT ✓ Horizontal drilling Fig. 7. Protecting the machine from falling by using the safety strap Rotate the handles to the left to place the cutter above the workpiece.

  • Page 14: Drilling

    HMPRO35-MS OPERATOR’S MANUAL PRO 36 MS 3.5. Drilling Connect the machine to the power source and set the POWER switch to ‘I’. Next, start the motor with the green MOTOR button. Then, slowly rotate the handles to the left to lower the cutter to the workpiece, and start drilling. Drill the hole in one pass.

  • Page 15: Replacing The Motor Brushes

    HMPRO35-MS OPERATOR’S MANUAL PRO 36 MS 3.6. Replacing the motor brushes Check the condition of the carbon brushes every 100 work hours. To do this, unplug the machine from the power source, and unscrew the cover (1, Fig. 8). Next, unscrew the pressing plate (2), and then remove the brush holder (3) and the brush (4).

  • Page 16: Wiring Diagram

    PRO 36 MS HMPRO35-MS OPERATOR’S MANUAL 5. WIRING DIAGRAM 4. WIRING DIAGRAM This document is protected by copyrights. Copying, using, or distributing without permission of PROMOTECH is prohibited. www.itmtools.com.au...

  • Page 17: Www.itmtools.com.au

    HMPRO35-MS OPERATOR’S MANUAL Parts list PRO 36 MS v.5.06 ITEM PART NUMBER DESCRIPTION Q-TY SKR-0440-21-00-00-0 METAL BOX KLC-000036 4 MM HEX WRENCH WITH HANDLE PAS-000007 SAFETY STRAP 250 KLC-000048 RATCHET WRENCH 3-8 PRD-000002 TORQUE STICK OPK-000001 TOOL CAN www.itmtools.com.au This document is protected by copyrights.
  • Page 18 HMPRO35-MS OPERATOR’S MANUAL Parts list PRO 36 MS v.5.06 www.itmtools.com.au This document is protected by copyrights. Copying, using, or distributing without permission of PROMOTECH is prohibited.
  • Page 19 HMPRO35-MS OPERATOR’S MANUAL Parts list PRO 36 MS v.5.06 ITEM PART NUMBER DESCRIPTION Q-TY SZN-0212-10-02-00-2 POWER CORD 230V 3x1.5 WITH STRAIN RELIEF ASSY (EU) SZN-0212-10-02-00-1 POWER CORD 230V 3x1 WITH STRAIN RELIEF ASSY (AU) SZN-0075-00-51-00-5 POWER CORD 120V 3x2.08 WITH STRAIN RELIEF ASSY (US) PWD-0212-10-02-00-6 POWER CORD 230V 3x1.5 WITH STRAIN RELIEF ASSY (INDIA)
  • Page 20 HMPRO35-MS OPERATOR’S MANUAL Parts list PRO 36 MS v.5.06 ITEM PART NUMBER DESCRIPTION Q-TY KNC-0234-00-10-00-0 HOSE FITTING WKR-000241 SELF-TAPPING SCREW 4x20 SCZ-000008 MOTOR BRUSH 6x9x17 SCT-0271-03-06-00-0 BRUSH HOLDER ZSP-0588-01-00-00-0 MAGNETIC BASE SET ASSY LOZ-000053 BALL BEARING 8x22x7 PKR-0440-03-02-00-1 MOTOR COVER...
