- Page 1 BG-EXHOC 4K UHD 18Gbps HDMI Extender Over Single Coax Cable with 2-Way IR up to 363ft User Manual...
- Page 2 BZBGEAR BG-EXHOC PRODUCT MANUAL · · Address: 830 National Drive #140, Sacramento, CA 95834, USA Tel: +1(888)499-9906 Email: support@bzbgear.com...
-
Page 3: Table Of Contents
BZBGEAR BG-EXHOC PRODUCT MANUAL TABLE OF CONTENTS Statement Safety Precaution Introduction Features Packing List Specifications Operation Controls and Functions Application Diagram HDMI Pin Definition Tech Support Warranty Mission Statement Copyright · · Address: 830 National Drive #140, Sacramento, CA 95834, USA Tel: +1(888)499-9906 Email: support@bzbgear.com... -
Page 4: Statement
● This product does not contain parts that can be maintained or repaired by users. Damage caused by dismantling the product without authorization from BZBGEAR is not covered under the warranty policy. ● Installation and use of this product must strictly comply with local electrical safety standards. -
Page 5: Introduction
HDMI transmission range up to 110m (363ft) in Ultra HD 4K2K format over a single coaxial cable. BG-EXHOC is easy to install and works perfectly with Belden 1694A coaxial cables. This device is also equipped with bi-directional IR pass-through. This feature allows users to rely on the same coax cable to carry IR control data for devices like displays and media players. -
Page 6: Packing List
4K2K 60Hz 4:4:4 1080P 25Hz 4K2K 30Hz 4:4:4 10/12bit** ** Resolution supports 10/12 bit Packing List ● 1x BG-EXHOC [TX & RX] ● 2x DC 5V wall wart ● 1x User Manual · · Address: 830 National Drive #140, Sacramento, CA 95834, USA Tel: +1(888)499-9906 Email: support@bzbgear.com... -
Page 7: Specifications
BZBGEAR BG-EXHOC PRODUCT MANUAL Specifications Technical Role of usage Transmitter (TX) Receiver (RX) HDMI compliance HDMI 2.0a HDCP compliance Video bandwidth Single-link 594MHz (18Gbps) Video support up to 4K2K@60 4:4:4 8 bits Audio support Stereo audio HDMI over Coax Ultra HD (4K2K 24-bit color) - up to 110m (363ft) -
Page 8: Operation Controls And Functions
BZBGEAR BG-EXHOC PRODUCT MANUAL Operation Controls and Functions Transmitter Unit - BG-EXHOC-TX 1. +5V DC: Connects to 5V DC power supply 2. POWER/SIGNAL LED: Blue light - POWER; Green light - SIGNAL ACTIVE 3. COAX OUT: Connect to coaxial cable 4. -
Page 9: Application Diagram
BZBGEAR BG-EXHOC PRODUCT MANUAL Receiver Unit - BG-EXHOC-RX 1. +5V DC: Connects to 5V DC power supply 2. POWER/SIGNAL LED: Blue light - POWER; Green light - SIGNAL ACTIVE 3. COAX IN: Connect to coaxial cable 4. Micro-USB: for F/W update 5. -
Page 10: Hdmi Pin Definition
BZBGEAR BG-EXHOC PRODUCT MANUAL HDMI Pin Definition Type A (Receptacle) HDMI Pin 1 TMDS Data2+ Pin 11 TMDS Clock Shield Pin 2 TMDS Data2 Shield Pin 12 TMDS Clock– Pin 3 TMDS Data2– Pin 13 Pin 4 TMDS Data1+ Pin 14 Reserved (N.C. -
Page 11: Tech Support
1.888.499.9906 support@bzbgear.com bzbgear.com Warranty BZBGEAR Pro AV products and cameras come with a three-year warranty. An extended two-year warranty is available for our cameras upon registration for a total of five years. For complete warranty information, please visit bzbgear.com/warranty. For questions, please call 1.888.499.9906 or email support@bzbgear.com. -
Page 12: Copyright
PRODUCT MANUAL Copyright All the contents in this manual and its copyright are owned by BZBGEAR. No one is allowed to imitate, copy, or translate this manual without BZBGEAR’s permission. This manual contains no guarantee, standpoint expression or other implies in any form. Product specification and information in this manual is for reference only and subject to change...
