- Page 1 Installation guide RMP24-micro radio machine probe www.renishaw.com/rmp24-micro #renishaw...
-
Page 3: Table Of Contents
RMP24-micro software licensing agreement ........ - Page 4 RMP24-micro – RMI-QE partnership ........
-
Page 5: Before You Begin
Renishaw office. Renishaw warrants its equipment and software for a limited period (as set out in the Standard Terms and Conditions), provided that they are installed and used exactly as defined in associated Renishaw documentation. -
Page 6: Patents
Patents Features of the RMP24-micro, and other similar Renishaw products, are the subject of one or more of the following patents and/or patent applications: CN 100416216 IN 215787 US 6941671 CN 100466003 IN 234921 US 7145468 CN 101476859 IN 8707/DELNP/2008... -
Page 7: Disposal Of Waste Electrical And Electronic Equipment (Weee)
Disposal of waste electrical and electronic equipment (WEEE) The use of this symbol on Renishaw products and/or accompanying documentation indicates that the product should not be mixed with general household waste upon disposal. It is the responsibility of the end user to dispose of this product at a designated collection point for waste electrical and electronic equipment (WEEE) to enable reuse or recycling. -
Page 8: Rmp24-Micro Software Notices
RMP24-micro software notices The RMP24-micro probe includes embedded software (firmware) to which the following notices apply: US government notice NOTICE TO UNITED STATES GOVERNMENT CONTRACT AND PRIME CONTRACT CUSTOMERS This software is commercial computer software that has been developed by Renishaw exclusively at private expense. -
Page 9: Safety
NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE. Intended use The RMP24-micro is a miniature radio spindle probe that enables automated workpiece inspection and job set-up on small machining centres. Safety Information to the user This product is supplied with non-rechargeable lithium metal-coin cell batteries. - Page 10 Information to the equipment installer All Renishaw equipment is designed to comply with the relevant UK, EU and FCC regulatory requirements. It is the responsibility of the equipment installer to ensure that the following guidelines are adhered to, in...
-
Page 11: Radio Approval
Radio approval Country name Logo EU, EFTA, Montenegro, Turkey: www.renishaw.com/rmp24-micro... - Page 12 This page is intentionally left blank. RMP24-micro: Before you begin...
-
Page 13: Rmp24-Micro Basics
RMP24-micro basics Introduction The RMP24-micro is a new generation radio transmission probe that is compatible for application with the RMI-QE radio machine interface. The RMP24-micro enables automated workpiece inspection and job set-up on small multi-tasking machines and machine centres. It is ideally suited to machining centres where line-of-sight between probe and receiver is difficult to achieve or where Z travel is limited. -
Page 14: System Interface
System interface The RMI-QE is an integrated interface/receiver used to communicate between the probe and the machine controller. For more details, refer to the RMI-QE radio machine interface installation guide (Renishaw part no. H-6551-8520). It is necessary that the RMP24-micro is partnered to an RMI-QE. -
Page 15: Partnering Mode
Partnering can take place anywhere within the operating envelope. Switch-on time (configured by RMI-QE) When the RMP24-micro radio machine probe is used with an RMI-QE, the turn-on time can be configured (in the interface) to either “fast” or “standard”. For best battery life, select ‘standard’ turn-on time. -
Page 16: Rmp24-Micro Dimensions
RMP24-micro dimensions 10.0 (0.39) 8.5 (0.33) 20.3 (0.80) A range of probe-ready shanks is available from Renishaw M2 stylus 31.4 (1.24) Dimensions given in mm (in) Stylus overtravel limits Stylus length ±X/±Y 30 (1.18) 9.3 (0.37) 4 (0.16) 10 (0.39) 4.5 (0.18) -
Page 17: Rmp24-Micro Specification
RMP24-micro specification Principal application Workpiece inspection and job set-up on small machining centres and multi-tasking machines Dimensions Length 31.4 mm (1.24 in) Diameter (maximum) 24 mm (0.94 in) Weight (without shank) With batteries 37 g (1.29 oz) Without batteries 33 g (1.16 oz) -
Page 18: Typical Battery Life
Battery life figures quoted in the above table are applicable to the probe when used in conjunction with an RMI-QE interface/receiver. 1% usage = 14 minutes/day. 5% usage = 72 minutes/day. Battery life is dependent on the quality of the external RF environment in which the probing system is operating. RMP24-micro: RMP24-micro basics... -
Page 19: System Installation
System installation Installing the RMP24-micro with an RMI-QE RMI-QE interface CNC machining centre spindle RMP24-micro radio machine probe machine controller Stylus Cable Workpiece Operating envelope Radio transmission does not require line-of-sight between the probe and transmitter, and will pass through very small gaps and machine tool windows. -
Page 20: Positioning The Rmp24-Micro And Rmi-Qe
5 m (16.4 ft) operating range Performance envelope when using the RMP24-micro with the RMI-QE RMP24-micro 75°... -
Page 21: Preparing The Rmp24-Micro For Use
Preparing the RMP24-micro for use Fitting the stylus 0.05 Nm – 0.15Nm (0.037 lbf.ft – 0.11 lbf.ft) M-5000-3540 www.renishaw.com/rmp24-micro... -
Page 22: Installing The Batteries
After the batteries have been inserted, the LED will display the current probe settings (see page 4-1,“Reviewing the probe settings”, for further information). C spanner C spanner Remove the battery isolation device from the battery compartment before use. NOTE: With the battery cap removed the sealing rating is not applicable. RMP24-micro: System installation... - Page 23 C spanner C spanner 1.5 Nm – 2.2 Nm (1.1 lbf.ft – 1.6 lbf.ft NOTE: Ensure that the probe is calibrated after installing the batteries. www.renishaw.com/rmp24-micro...
-
Page 24: Mounting The Probe On A Shank
Mounting the probe on a shank C spanner 1.5 Nm – 2.2 Nm (1.1 lbf.ft – 1.6 lbf.ft RMP24-micro: System installation... -
Page 25: Calibrating The Rmp24-Micro
Calibrating the RMP24-micro Why calibrate a probe? A spindle probe is just one component of the measurement system which communicates with the machine tool. Each part of the system can introduce a constant difference between the position that the stylus touches and the position that is reported to the machine. -
Page 26: Calibrating In A Ring Gauge Or On A Datum Sphere
The stored value for length is different from the physical length of the probe assembly. Additionally, the operation can automatically compensate for machine and fixture height errors by adjusting the probe length value that is stored. RMP24-micro: System installation... -
Page 27: Probe Configuration
Probe in standby mode (after 5 seconds) NOTES: Ensure that the probe is securely screwed together and torque tightened to between 1.5 Nm and 2.2 Nm (1.1 lbf.ft – 1.6 lbf.ft). Ensure that the probe is calibrated after installing the batteries. www.renishaw.com/rmp24-micro... -
Page 28: Probe Partnering Function
20 seconds and then go into standby. If “Partnering mode on” is not selected, the probe will timeout after 120 seconds and then go into standby (see page 4-4, “RMP24-micro – RMI-QE partnership”, for further information). - Page 29 4 seconds to select “Partnering mode active” again. NOTES: Ensure that the probe is securely screwed together and torque tightened to between 1.5 Nm and 2.2 Nm (1.1 lbf.ft – 1.6 lbf.ft). Ensure that the probe is calibrated after installing the batteries. www.renishaw.com/rmp24-micro...
-
Page 30: Rmp24-Micro - Rmi-Qe Partnership
RMP24-micro – RMI-QE partnership System set-up is achieved by using Trigger Logic™ and powering on the RMI-QE. Alternatively, partnering to an RMI-QE can be achieved by using ReniKey; a Renishaw machine macro cycle which does not require the RMI-QE to be power cycled. - Page 31 Displayed for 5 seconds The probe is now in standby and the system is ready for use. > 20 s NOTE: Refer to the RMI-QE radio machine interface installation guide (Renishaw part no. H-6551-8520) when partnering up to four radio probes. www.renishaw.com/rmp24-micro...
-
Page 32: Changing The Probe Settings When Partnered To An Rmi-Qe
To exit, leave the stylus Deflect the stylus and hold it untouched for more than deflected until after the battery 20 seconds. status has been displayed at the end of the review sequence. Battery status Battery low Battery good RMP24-micro: Probe configuration... - Page 33 “Partnering mode”. Ensure that the probe is securely screwed together and torque tightened to between 1.5 Nm and 2.2 Nm (1.1 lbf.ft – 1.6 lbf.ft). Ensure that the probe is calibrated after installing the batteries. www.renishaw.com/rmp24-micro...
-
Page 34: Master Reset Function
This action clears all probe settings and returns the probe to default settings. Following an LED, check the probe returns to Trigger Logic and displays “Trigger filter”. Further configuration using Trigger Logic may be necessary to achieve the required probe settings. > 5 s RMP24-micro: Probe configuration... - Page 35 System status LED Previous settings have been cleared. The probe now has default settings. www.renishaw.com/rmp24-micro...
- Page 36 The probe will continue to be partnered with the RMI-QE following the activation of the master reset function. Ensure that the probe is securely screwed together and torque tightened to between 1.5 Nm and 2.2 Nm (1.1 lbf.ft – 1.6 lbf.ft). Ensure that the probe is calibrated after installing the batteries. 4-10 RMP24-micro: Probe configuration...
-
Page 37: Operating Mode
The probe begins to run through the LED review sequence (see page 4-1, “Reviewing the probe settings”, for further information). Again, the batteries discharge and the probe ceases to function. Again, the batteries recover sufficiently to provide the probe with power, and the sequence repeats itself. www.renishaw.com/rmp24-micro 4-11... - Page 38 This page is intentionally left blank. 4-12 RMP24-micro: Probe configuration...
-
Page 39: Maintenance
Maintenance You may undertake the maintenance routines described in these instructions. Further dismantling and repair of Renishaw equipment is a highly specialised operation, which must be carried out at an authorised Renishaw Service Centre. Equipment requiring repair, overhaul or attention under warranty should be returned to your supplier. - Page 40 When changing batteries, check that the battery polarity is correct. Take care to avoid damaging the battery cassette gasket. Only use specified batteries. C spanner C spanner CAUTION: Dispose of dead batteries in accordance with local regulations. Never dispose of batteries in a fire. RMP24-micro: Maintenance...
- Page 41 Panasonic CR1632 Murata NOTE: Lithium manganese oxide CR1632 batteries are available from other manufacturers. However, these are untested by Renishaw so correct operation of the probe cannot be guaranteed. C spanner C spanner 1.5 Nm – 2.2 Nm (1.1 lbf.ft – 1.6 lbf.ft NOTE: Ensure that the probe is calibrated after installing the batteries.
- Page 42 This page is intentionally left blank. RMP24-micro: Maintenance...
-
Page 43: Fault-Finding
The probe crashes. Workpiece obstructing probe path. Review probing software. Probe length offset missing. Review probing software. In cases where there is more than Review interface wiring or part one probe on a machine, incorrect program. probe activated. www.renishaw.com/rmp24-micro... - Page 44 Probe and RMI-QE are not Partner probe with RMI-QE. partnered. Probe selection error. Verify that one radio probe is working and is correctly selected on the RMI-QE. 0.5 second turn-on error. Change the RMI-QE turn-on time to 1 second. RMP24-micro: Fault-finding...
- Page 45 No RMI-QE “start/stop” signal Check RMI-QE for green start LED. off. The probe goes into Probe was triggered when batteries Do not touch the stylus or stylus Trigger Logic™ were inserted. mounting face during battery configuration mode and insertion. cannot be reset. www.renishaw.com/rmp24-micro...
- Page 46 This page is intentionally left blank. RMP24-micro: Fault-finding...
-
Page 47: Parts List
A-6551-0120 RMI-QE mounting bracket with fixing screws, washers and nuts. bracket Styli tool M-5000-3540 Tool for tightening/releasing styli. Publications. These can be downloaded from our website at www.renishaw.com RMI-QE H-6551-8520 Installation guide: for set-up of the RMI-QE. Styli H-1000-3200 Technical specifications: Styli and accessories – or visit our Online store at www.renishaw.com/shop. - Page 48 +44 (0) 1453 524524 uk@renishaw.com © 2023 Renishaw plc. All rights reserved. This document may not be copied or reproduced in whole or in part, or transferred to any other media or language by any means, without the prior written permission of Renishaw.
