XR5FC/XR5SL Commercial Fire Panels
Programming Guide
5 Zone Fire Panels with Built-in Communicators
Do Not Throw Away!
This programming guide contains information you need to program and service the
panel and should be kept along with your other DMP technical documentation.
2841 E. Industrial Drive Springfield, MO 65802-6310 800-641-4282
LT-0312 (7/96)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XR5FC and is the answer not in the manual?

Questions and answers

Related Manuals for DMP Electronics XR5FC

Summary of Contents for DMP Electronics XR5FC

  • Page 1 XR5FC/XR5SL Commercial Fire Panels Programming Guide 5 Zone Fire Panels with Built-in Communicators Do Not Throw Away! This programming guide contains information you need to program and service the panel and should be kept along with your other DMP technical documentation.
  • Page 2 MODEL XR5FC/XR5SL PROGRAMMING MANUAL When using the XR5FC/XR5SL panel for any UL, NFPA, CSFM or other listing organization's approved methods, refer to this manual and the XR5FC/XR5SL Installation Guide (LT-0229). These documents outline the installation and programming requirements of all applications for which the XR5FC/XR5SL is approved.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS Section INTRODUCTION Before You Begin .................... 1.1 Getting Started ....................1.2 Programming Menu ..................1.3 Programmer Lockout Codes ................1.4 Reset Timeout ....................1.5 Special Keys ....................1.6 Entering Alpha Characters ................1.7 Entering Non-Alpha Characters ............... 1.8 Keypad Prompts Display Current Programming ..........
  • Page 4 TABLE OF CONTENTS Section OUTPUT OPTIONS Output Options ....................6.1 Bell Cutoff Time ....................6.2 Bell Action ......................6.3 Fire Type ....................6.3A Supervisory Type ..................6.3B Auxiliary 1 Type ..................6.3C Output Action ....................6.4 Cutoff Outputs ................... 6.4A Output Cutoff Time ..................

  • Page 5: Before You Begin

    Before starting to program, we recommend you read through the contents of this guide. The information contained here allows you to quickly learn the programming options and operational capabilities of the XR5FC and XR5SL panels. In addition to this guide, you should also read and be familiar with the following XR5FC and XR5SL documents: •...

  • Page 6: Programming Menu

    Reset Timeout The XR5FC and XR5SL has a feature that requires you to enter the Programmer within 30 minutes of resetting the panel. After 30 minutes, if you attempt to program by entering the 6653 (PROG) code, the keypad displays: RESET PANEL.

  • Page 7: Special Keys

    The SELECT keys are also used for selecting a section from the programming menu. This is done by pressing any one of the SELECT keys when the name of the programming section you want is displayed. XR5FC/XR5SL Programming Guide 2841 E. Industrial Drive Springfield, MO 65802-6310 800-641-4282...

  • Page 8: Entering Alpha Characters

    It is not necessary to enter numbers with leading or trailing zeros. The XR5FC and XR5SL automatically justifies the number when you press the COMMAND key.

  • Page 9: Initialization

    A description of each selection follows: CLEAR PROGRAMMING - YES sets the panel's programming back to factory default DEFAULTS? NO YES selections and clears any information stored in Display Events Memory. SURE? XR5FC/XR5SL Programming Guide 2841 E. Industrial Drive Springfield, MO 65802-6310 800-641-4282 Page 5...

  • Page 10: Communication

    3 - COMMUNICATION Section 3 allows you to configure the communication settings for the XR5FC and COMMUNICATION XR5SL panels. After choosing the Communication Type, continue through the list of additional communication options. COMM TYPE: NONE COMMUNICATION TYPE specifies the communication method the panel uses to contact the receiver.

  • Page 11: Receiver 2 Programming

    After twelve hours has elapsed, the Recall Test is sent to the receiver. Whatever time of day this happens to be is the time the Recall Test will be sent every 24 hours. XR5FC/XR5SL Programming Guide 2841 E. Industrial Drive Springfield, MO 65802-6310 800-641-4282...

  • Page 12: Remote Options

    NOT the same so the panel can determine the difference between receivers. When NO is selected remote commands and programming are not accepted from a secondary service receiver. XR5FC/XR5SL Programming Guide 2841 E. Industrial Drive Springfield, MO 65802-6310 800-641-4282 Page 8...

  • Page 13: System Options System Options

    5 - SYSTEM OPTIONS SYSTEM OPTIONS SYSTEM OPTIONS - This section allows you to select system wide parameters used in the operation of the XR5FC and XR5SL system. A description of each System Option follows: CRS ZONE TM: CROSS ZONE FAULT TIME - Enter the time allowed after a zone trips to indicate a zone fault condition.

  • Page 14: Output Options Section

    Form C relay outputs are available on the 6-position terminal strip on the panel. Annunciator outputs (open collector) are available by using the 4-wire output header on the XR5FC and XR5SL board. Refer to the XR5FC and XR5SL Installation Guide (LT-0299) for complete information. A description of each output option follows: BELL CUTOFF TIME - Enter the maximum time the Bell Output remains on.

  • Page 15: Zone Information Zone Information

    120 seconds, the cycle is repeated. If no other Fire Verify or Fire zone is alarmed within 120 seconds, a zone fault report is sent to the receiver. XR5FC/XR5SL Programming Guide 2841 E. Industrial Drive Springfield, MO 65802-6310 800-641-4282...

  • Page 16: Zone Type Specifications

    7 - ZONE INFORMATION ZONE TYPE SPECIFICATIONS The XR5FC and XR5SL panels contains four default zone types for use in configuring the system. These zone types provide the most commonly selected functions for their applications. All zone types except the Arming zone type can be customized by changing the variable options listed below.

  • Page 17: Armed Open

    Output Number selected in section 7.9B activates. 7.8B OUTPUT NUMBER - You can specify any of the outputs on the XR5FC or XR5SL to OUTPUT NO: 0 be activated by a zone condition. The output can be activated regardless of the report to transmit or whether or not the zone is programmed as local.

  • Page 18: Zone Retard

    At the STOP prompt, pressing any SELECT key allows you to exit the programmer STOP function of the XR5FC or XR5SL panel. When selected, the panel performs an internal reset and exits the programmer. The Stop function clears the panel's Status List.

  • Page 19: 10 - Appendix

    When a Fire Verify zone initiates an alarm, the panel performs a Fire Reset. If any Fire zone initiates an alarm within 120 seconds after the reset, an alarm is indicated. If an alarm is initiated after 120 seconds, the cycle is repeated. XR5FC/XR5SL Programming Guide 2841 E. Industrial Drive Springfield, MO 65802-6310 800-641-4282 Page 15...

  • Page 20: Manual Telephone Line Seizure

    39 Fire alarm to the central station receiver. 10.6 Walk Test The XR5FC and XR5SL panels also provide a walk test feature that allows a single technician to test the protection devices connected to zones on the system. To conduct the Walk Test: From an alphanumeric keypad 1.

  • Page 21: Reporting Operation

    3. If the panel detects it is communicating with a DMP receiver, all reports are sent in SDLC format. 4. If the panel last communicated to a 4-2 compatible receiver, a SDLC only event cannot initiate a call to the receiver. The SDLC only events for the XR5FC and XR5SL are Walk Test and Code Change reports.

  • Page 22: Serviceman's Programmer Access

    The DMP 4-2 format communicates to the central station as 4-2 with a checksum at 40 pulses per second (pps). The XR5FC and XR5SL panels using 4-2 communication will accept either a 1400Hz or 2300Hz acknowledgment tone (handshake) from the receiver.
