  • Page 1 Programming guide Xr5FC/Xr5SL Fire Command ProCeSSor™ PaneLS...
  • Page 2 FIRE COMMAND PROGRAMMING GUIDE When using the XR5FC/XR5SL panel for any listing organization's approved methods, refer to this manual and the Specifications Compliance section of the XR5FC/XR5SL Installation Guide (LT-0299). These documents outline the instal- lation and programming requirements of all applications for which the XR5FC/XR5SL is approved.

  • Page 3: Table Of Contents

    T abLe oF ConTenTS Introduction ..............1 Before You Begin ..............1 About this Guide ..............1 Reading the Contents ............. 1 Programming Information Sheets ..........1 Getting Started............... 1 Initializing the Panel ............... 1 Program from Any Keypad Address ......... 1 Accessing the Programmer .............
  • Page 4 T abLe oF ConTenTS Output Options..............11 Output Options ..............11 Bell Cutoff Time ..............11 Bell Action ................11 6.3.1 Fire ..................11 6.3.2 Supervisory ................11 6.3.3 Auxiliary ................11 Output Action ................11 6.4.1 Cutoff Outputs ..............11 6.4.2 Output Cutoff Time..............11 6.4.3 Communication Failure Output ..........11 6.4.4 Fire Alarm Output ..............12 6.4.5...

  • Page 5: Introduction

    Before starting to program, we recommend you read through the contents of this guide. This information allows you to quickly learn the programming options and operational capabilities of the XR5FC and XR5SL panels. In addition to this guide, you should also read and be familiar with the following XR5FC and XR5SL documents: •...

  • Page 6: Programming Menu

    Reset Timeout The XR5FC and XR5SL has a feature that requires you to enter the Programmer within 30 minutes of resetting the panel. After 30 minutes, if you attempt to program by entering the 6653 (PROG) code, the keypad displays: RESET PANEL. You must reset the panel, enter the program code, then begin programming within the next 30 minutes.

  • Page 7: Special Keys

    inTroduCTion Special Keys Fire Command Center LCD Display POWER Function Keys TROUBLE ALARM SILENCE RESET Select Keys ENABLE TEST DRILL COMMAND COMMAND Key Back Arrow Key COMMAND Key Pressing the COMMAND key allows you to go forward through the programming menu and through each step of a programming sec tion.

  • Page 8: Entering Alpha Characters

    It is not necessary to enter numbers with leading 0s (zero). The XR5FC and XR5SL automatically right justifies the number when you press the COMMAND key.

  • Page 9: Initialization

    iniTiaLiza Tion Initialization Initialization INITIALIZATION The Initialization function allows you to set the panel programmed memory back to the factory defaults in preparation for system programming. After you select YES to clear part of the memory, the panel asks if you are sure you want to clear the memory.

  • Page 10: Communication

    YES enables tone dialing. NO enables rotary dialing. Receiver 1 Programming RECEIVER 1 PROG Allows you to set the options for the first receiver the XR5FC and XR5SL panels attempt to contact when sending reports. The XR5FC and XR5SL support communication to two receivers.

  • Page 11: Backup Reporting

    CommuniCa Tion 3.10 NO YES Backup Reporting BACKUP YES enables Receiver 1 to be a backup to Receiver 2 in the event the panel cannot contact Receiver 2. 3.11 First Telephone Number FIRST PHONE NO: This is the first number the panel dials when sending reports to this receiver. A phone number can consist of two lines of 16 characters to equal 32 characters.

  • Page 12: First Telephone Number

    CommuniCa Tion 3.19 First Telephone Number FIRST PHONE NO: This is the first number the panel dials when sending reports to this receiver. A phone number can consist of two lines of 16 characters to equal 32 characters. You can program a three second pause in the dial ing se quence by en tering the let ter P. You can program a dial tone detect by entering the letter D.

  • Page 13: Remote Options

    remoTe oPTionS Remote Options Remote Options REMOTE OPTIONS This section allows the information needed for Remote Command/Remote Programming operation to be entered. A description of the Remote Options follow. Note: A complete functional checkout of the panel is required following any programming or reprogramming.

  • Page 14: System Options

    System Options SYSTEM OPTIONS This section allows you to select system wide parameters used in the operation of the XR5FC and XR5SL system. Cross Zone Fault Time CRS ZONE TM: Enter the time allowed after a zone trips to indicate a zone fault condition. When a zone programmed for cross zoning trips, the panel begins counting down the Cross Zone Fault Time you enter here.

  • Page 15: Output Options

    Output options for the Form C relays and annunciator outputs. Form C relay outputs are available on the panel 6-position terminal strip. Annunciator outputs (open collector) are available by using the 4-wire output header on the XR5FC and XR5SL board. Refer to the XR5FC and XR5SL Installation Guide (LT-0299) for complete information.

  • Page 16: Fire Alarm Output

    ouTPuT oPTionS 6.4.4 Fire Alarm Output FIRE ALR OUT: This output is turned on any time a fire type zone is placed in alarm. The output is turned off using the Sensor Reset option when no additional fire type zones are in alarm.

  • Page 17: Zone Information

    zone inForma Tion Zone Information Zone Information ZONE INFORMATION This allows you to define the operation of each protection zone used in the system. A description of each programming option follows: Zone Number ZONE NO: – Enter the zone number to program. Press COMMAND to enter a zone name. Address Programming Zone Number Panel...

  • Page 18: Next Zone

    120 seconds, a zone fault report is sent to the receiver. 7.7 Zone Type Specifications The XR5FC and XR5SL panels contain four default zone types for use in configuring the system. These zone types provide the most commonly selected functions for their applications. Zone Information...

  • Page 19: Armed Open

    Output Number OUTPUT NO: You can specify any of the outputs on the XR5FC or XR5SL to activate by a zone condition. The output can be activated regardless of the report to transmit or whether or not the zone is programmed as local.

  • Page 20: Swinger Bypass

    zone inForma Tion SWGR BYP: NO YES Swinger Bypass YES allows the zone to be bypassed by the panel after three alarm, trouble, or local trips within one hour. Selecting NO disables swinger bypassing for this zone. After the first trip, if the zone does not trip two more times within an hour, the bypass trip counter returns to zero.

  • Page 21: Stop

    Stop Stop STOP At the STOP prompt, press any Select key to exit the XR5FC or XR5SL panel programmer function. When selected, the panel performs an internal reset and exits the programmer. The Stop function clears the panel Status List.

  • Page 22: Appendix

    10.3 2-Button Panic Keys The XR5FC and XR5SL panels support the 2-button Fire (flame icon) feature on the 630F and 692F keypad. Pressing the two right Select keys sends a zone 39 Fire alarm to the central station receiver. Digital Monitoring Products...

  • Page 23: Walk Test

    10.4 Walk Test The XR5FC and XR5SL panels provide a walk test feature that allows a single technician to test the protection devices connected to zones on the system. To conduct the Walk Test: From the 630F Keypad 1. From the keypad, enter the code 8144. If the system is monitored and the communication type is set to DD, the system sends a System Test Begin report to the central station.

  • Page 24: Revisions To This Document

    reviSionS Revisions to this Document This section explains the changes made to this document during this revision. This section lists the date the change was made, the section number and section heading, and a brief explanation of the change. Date Section Number and Heading Quick Explanation of Changes 1.01 1.6 Special Keys...
  • Page 25 This page intentionally left blank Digital Monitoring Products XR5 Programming Guide...

  • Page 26: Listings And Approvals
