DMP Electronics XR150FC System User's Manual

Fire control panel
Hide thumbs Also See for XR150FC:
Table of Contents

Advertisement

Quick Links

Download this manual
SYS T E M U S E R G U I D E
X R
F I R E
C O N T R O L
P A N E L

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XR150FC and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for DMP Electronics XR150FC

Summary of Contents for DMP Electronics XR150FC

  • Page 1 SYS T E M U S E R G U I D E F I R E C O N T R O L P A N E L...
  • Page 3 HOW TO HANDLE AN ALARM While the fire alarm horns, strobes, or sirens are going off, use one of the following methods to silence the alarm: Turn the keyswitch to enable the four function keys, then press the SILENCE key. Enter your User Code, then press COMMAND.

  • Page 5: Table Of Contents

    TABLE OF CONTENTS Get to Know the Fire Command Center ..1 Door Lock/Unlock ..........20 Door Access ...............21 The Select Keys ............2 Outputs On/Off ............22 Data Entry Keys ............2 Favorite ...............23 The Back Arrow Key ..........2 Zone Status ...............24 The Command Key ...........
  • Page 6 FIRE CONTROL PANEL FEATURES Status LEDs LCD Display Select Keys Fire Command Center POWER TROUBLE ALARM Keyswitch SILENCE RESET ENABLE TEST DRILL COMMAND Function Keys Back Arrow Key Data Entry Keys COMMAND Key Figure 1: Fire Control Panel Features...

  • Page 7: Get To Know The Fire Command Center

    GET TO KNOW THE FIRE COMMAND CENTER Your system comes equipped with a built-in, easy-to-use Fire Command Center that allows you to properly operate the system. The Command Center is also available in a remote version. The keyswitch to the left of the keyboard must be turned to the “enable”...

  • Page 8: The Select Keys

    The Select Keys There are four keys under the display called the Select Keys. They allow you to choose what to do by pressing the Select Key under choices being shown in the display. Data Entry Keys These keys allow you to enter your user code and other information into the system.

  • Page 9: Status Leds

    Status LEDs Power LED This LED remains on steady when both AC and battery input are good. The LED turns off when AC input is low. The LED flashes when battery input is low. Trouble LED This LED turns on when any trouble displays in the status list, such as AC, battery, phone line, transmit, ground fault, NAC, or any zone trouble.

  • Page 10: Entering Non-Alpha Characters

    Entering Non-Alpha Characters To enter a space in an alpha entry, press the 9-digit key followed by the third Select Key. The three characters on the 9-digit key are Y, Z, and space. You can also enter the following characters: – (dash), . (period), * (asterisk), and # (pound sign) using the 0 (zero) key and the four Select Keys from left to right.

  • Page 11: Using The Keypad

    Using the Keypad Multi-Lingual Display Option Your system may be programmed to display the User Menu and Status Display text in multiple languages. When the COMMAND key is pressed, the option to choose the language displays. Keypad Displays Current Programming Most User Menu options displayed at the keypad show the currently selected option in the panel memory.
  • Page 12 Multiple Displays For many User Menu options on burglary keypads of combination burglary and fire systems, such as Access Areas, there are several displays containing lists. For example, in Access Areas, areas 1 - 32 display on four separate displays. First, areas 1 - 8 display.
  • Page 13 Asterisks in Burglary Area Armed Displays Asterisks display next to a programming option that is already selected. As shown in the example, options chosen to display the current programming selection have an asterisk next to the number. Those that are not selected simply display the number.

  • Page 14: User Options

    User Options Allows you to make adjustments to your keypad. To access User Options, press and hold the Back Arrow and COMMAND keys for two seconds. The keypad display changes to SET BRIGHTNESS. Press the COMMAND key to display the next option or the Back Arrow key to exit. Backlighting Brightness Volume Level Sets the keypad LCD and AC LED...

  • Page 15: Four Function Keys

    Four Function Keys After turning the keyswitch, you can quickly perform vital functions using the four keys on the left side of the keypad. SILENCE Key Pressing the SILENCE key silences the alarm bells. RESET Key Pressing the RESET key performs a sensor reset and silence the alarm bells. TEST Key Pressing the TEST key performs a system test.

  • Page 16: Special Fire Command Center Displays

    Special Fire Command Center Displays SILENCED ALARM An Alarm Silence has been performed A 24-hour zone or an armed burglary to turn off the notification appliances. zone has been tripped. Zone names display. ALARM NOT SENT SUPVSRY (SUPERVISORY) On a Burglary Keypad, the alarm signal A Supervisory type zone alarm has was not sent to the central station occurred.
  • Page 17 ENTER CODE INVALID AREA The system requires you to enter your A user has attempted a door access for user code. User codes can be required an area they are not assigned. for turning your system on (arming), INVALID TIME turning your system off (disarming), A user code assigned to a specific etc.
  • Page 18 FAILED TO EXIT SYSTEM TROUBLE or (ANTI-PASS BACK) SERVICE REQUIRED On a Burglary Keypad, anti-passback There is a problem with one or more requires users to exit (egress) an area of the components in your system. they have previously accessed. If they Contact our service department.

  • Page 19: Special Fire Command Center Tones

    Special Fire Command Center Tones Fire Alarm Tone Exit Tone An intermittent sweeping siren that A continuous pulsing tone that sounds sounds until the fire alarm is silenced. during the exit countdown just after arming to remind you to exit the Key Press Tone premise.

  • Page 20: User Menu

    USER MENU Some features displayed in the User Menu can’t be intereacted with. Only the features that can be interacted with are listed in this guide. Press the COMMAND key to skip any displays and prompts not discussed in this User Guide. User Menu Options The list below shows the User Menu options in the order they display.
  • Page 21 SYSTEM STATUS TIME Displays the current condition of the Allows you to change the Day, Date, or system AC power, backup battery, Time that is currently programmed in optional panel tamper, and keypad the system. model and version numbers. DISPLAY EVENTS SYSTEM TEST Allows you to view or print the last Tests the system siren, communication...

  • Page 22: Accessing The User Menu

    Accessing the User Menu Press the COMMAND key, if the multi-language option is enabled, the available languages display. Press the top row Select Key under the language to use for text display. Press the COMMAND key until MENU? NO YES displays. Select YES.

  • Page 23: Alarm Silence

    Alarm Silence Silences the alarm bells or sirens during an alarm. Using Alarm Silence does not stop an alarm report from being sent to the central station and does not reset any alarmed devices. Note: The keypad tone silences as soon as the first user code digit key is pressed.

  • Page 24: Sensor Reset

    Sensor Reset Resets smoke or glassbreak detectors which must be reset before they can detect any additional alarm conditions. Also clears Fire/Supervisory alarm and trouble displays. Make sure all smoke is cleared from around the smoke detector areas before performing a Sensor Reset to prevent the alarm from occurring again. Access the User Menu.

  • Page 25: Lockdown

    Lockdown Locks all Public Doors from the keypad in an emergency situation. Access the User Menu. Press COMMAND until LOCKDOWN? displays. Press any Select Key. The door access relay is activated and all Public Doors are locked. Press COMMAND to return to the Status List display. Digital Monitoring Products, Inc.

  • Page 26: Door Lock/Unlock

    Door Lock/Unlock Locks and unlocks doors from the keypad. Access the User Menu. Press COMMAND until DOOR LOCK/UNLOCK? displays. Enter the door number and press COMMAND. -OR- Press the fourth Select Key to browse door names. Use the COMMAND key to scroll through names and press any Select Key when the desired door is displayed.

  • Page 27: Door Access

    Door Access Operates an electric door strike from the keypad. Note: The door strike function is not available on the Model 7872 Graphic Touchscreen keypad. Door Access is used to operate the door strike relay that is built into some keypads.

  • Page 28: Outputs On/Off

    Outputs On/Off Allows you to manually turn the system or door access relay outputs ON and OFF. This function can individually turn your system relay and access door outputs ON and OFF. Your system may use these outputs to control door access, interior and exterior lighting, heating, air conditioning, or other appliances.

  • Page 29: Favorite

    Enter the output number you want to turn ON or OFF. The output number displays. The range for outputs is 1-6, 500-999. The range for the door is 1-16. With the output number displays, press the Select Key under ON or OFF. The remains in that chosen state until you change it.

  • Page 30: Zone Status

    Zone Status Zone Status can be used to give you a list of zones by category or display the current status of an individual zone number. Access the User Menu. Press COMMAND until ZONE STATUS? displays. Press any Select Key to display ARM BYPS ALR NBR. ARM, BYPS, and ALR provide a list of zones with that status to scroll through using COMMAND.
  • Page 31 Select NBR and ZONE NO displays. Enter the zone number you want • to check and press COMMAND. The zone number and name display followed by the zone status. The following is a list of the zone status displays: OKAY The zone is in a normal condition BYPAS The zone is bypassed...

  • Page 32: System Status

    System Status System Status displays the internal system hardware current condition. System Status shows the panel condition of AC power, battery power, and optional panel tamper. When System Status is selected, each monitor displays followed by OKAY or TRBL (Trouble) to indicate the current condition. Access the User Menu.

  • Page 33: System Test

    System Test System Test is used to test the battery, alarm bell or siren, and communi cation to a central station. The System Test function begins automatically as soon as you select it. Using the System Test Function Access the User Menu. Press COMMAND until SYSTEM TEST? displays. The keypad displays SYSTEM PANICS.
  • Page 34 Using the Panic Zone Test (XR550DNFC with Network) Access the User Menu. Press COMMAND until SYSTEM TEST? displays. Press any Select Key. The keypad displays SYSTEM PANICS. Press the Select Key below PANICS. The Panic Zone Test begins automatically and the keypad displays TRIPS: END.
  • Page 35 When PANIC TEST OKAY displays, the Panic Zone Test is completed and all zones tested OK. When the Panic Zone Test ends and a zone failed (did not trip) during the test, the keypad displays the zone name and number and the buzzer sounds for one second.

  • Page 36: User Profiles

    User Profiles Change User Profiles, that define the authority of each user code in the system. Several characteristics define the authority of each User Profile within the system. Always make sure that at least one administrator in your system has a profile with all authorities and all areas.
  • Page 37 Access Areas User Menu Assignments Each profile may be assigned door Each user profile may have any of the access area assignments. Default for menus assigned to it as shown in the profile 1 to 98 is NO areas assigned. User Profile Record below.
  • Page 38 User Profiles Reference MENU DISPLAY PRIVILEGE MENU DISPLAY PRIVILEGE PROFILES User Profiles Disarm USR CODE User Codes ALM SLNC Alarm Silence SCHEDULS Schedules SNSR RST Sensor Reset TIME Time LOCKDOWN Lockdown DIS EVNT Display Events DOOR LOCK/ SERV REQ Service Request Door Lock/Unlock UNLOCK FIRE DRILL...
  • Page 39 At the PROFILE NO option, enter a profile number and press COMMAND. The display changes to PROFILE NAME. Press any Select Key to display -. Enter a profile name of up to 16 characters. The default Profile Name uses the Profile Number. Enter the Profile Name and press COMMAND.
  • Page 40 TEMP CODE ACCESS SCHEDULES When you select YES for this menu This option allows you to assign option, and this profile is assigned to two Schedules to a profile for door a user code (see next section), the access. When the keypad displays keypad displays TEMP EXPIRE DATE.
  • Page 41 RE ARM DELAY is also used to delay a late to close message to the central station when the panel does not use automatic arming. If the user has Extend Schedule authority, 2HR 4HR 6HR 8HR displays at disarming. If the user does not make a choice, the RE ARM DELAY is used to extend the schedule.

  • Page 42: User Codes

    User Codes This option allows you to add, delete, or change a user code. You may also assign specific User Profiles to individual users. User Number User Names Every user is numbered 1 - 9999. This Each code may also be programmed number identifies the user to the with the user name.
  • Page 43 Adding User Codes Access the USER CODES? display. Press any Select Key. The keypad displays ADD DEL CHG BAT. Press the Select Key under ADD or BAT (Batch) to add a new user code. At the USER NUMBER prompt, enter a user number and press COMMAND. The display changes to USER CODE.
  • Page 44 Deleting User Codes To delete a user code, you must have a user code with a profile that has user code authority. Access the USER CODES? display. Press any Select Key. The keypad displays ADD DEL CHG BAT. Press the second Select Key, under DEL, to delete a user code from the system.
  • Page 45 Changing User Codes Access the USER CODES? display. Press any Select Key. The keypad displays ADD DEL CHG BAT. Press the third Select Key, under CHG, to change a user code. At the USER NUMBER prompt, enter the user number to change and press COMMAND.

  • Page 46: Extend Closing

    Extend Closing Extending schedules (EXT) allows the Closing Check operation to delay until the new closing time expires. This allows the current schedule to ignore its closing time and not send a LATE TO CLOSE message to the central station. This function is designed to allow workers to stay later and does not extend door access authority.

  • Page 47: Setting Schedules

    Setting Schedules Access the User Menu. The keypad displays TIMES AREAS DOOR. Press COMMAND to display OUTPUT HOLIDAYS. Select the function you want to program. Times The keypad displays ADD DEL CHG. Adding a Schedule Select ADD to enter a new schedule number. Enter the Schedule number 01-99 that you want to add.
  • Page 48 Note: After selecting the day of the week or holiday for the schedule to begin, the keypad displays any currently programmed Begin and End times previously set for that day. This feature allows you to review programmed schedules at any time. If Begin and End times already exist, the keypad then displays DELETE KEEP.
  • Page 49 Now that the new shcedule is programmed into your system, the keypad goes back to the SUN MON TUE WED display. Press the Back Arrow key to enter another schedule. To clear a schedule press DELETE and then AM when the opening time is requested.
  • Page 50 Change a Schedule Select CHG to edit an existing schedule. Enter the schedule number 01-99 that you want to change. The keypad displays ENTER SCHEDULE and the schedule name. To edit the name press any Select Key to make changes. Press CMD to proceed. The keypad displays SELECT WEEK DAY and SUN MON TUE WED.
  • Page 51 Setting Area, Output, and Door Schedules The Schedules function allows you to assign up to 8 different schedule numbers to each area, output, and door access relay connected to your system. The schedule number allows the opening and closing times for the area and on/off times for outputs and door access relays Access the User Menu.
  • Page 52 Setting Holiday ABC Schedules Three Holiday Schedules are available. This allows an output, area, or door to have three different schedules for holidays. For example, Holiday Schedule A for those holidays when the building stays closed, Holiday Schedule B for a day that only opens for a morning, etc.
  • Page 53 The keypad displays A - : AM PM. Note: After selecting the schedule, the keypad displays any current times previously set for that holiday. This feature allows you to review the programmed times. If times display, the keypad then displays DELETE KEEP. Select DELETE to enter new times.

  • Page 54: Setting Holiday Dates

    Setting Holiday Dates Setting Holiday Dates provides the system with dates in the year when the normal opening and closing schedules are not used and superseded by one of the Holiday Schedules A or B or C. When the panel determines that it is a holiday, the Holiday Schedule supersedes the current schedule for that day.

  • Page 55: Setting The Date And Time

    To step to the next holiday number, press COMMAND. To clear a holiday press any top row Select Key when the appropriate holiday number displays. Press the Back Arrow key when HOL: 1 or the COMMAND key when HOL: 40 displays to exit the menu. Note: The Holiday Dates entered indicate the days of the year when HOL schedules are used.
  • Page 56 Press the Select Key under TIME to change the time. The keypad displays AM PM. Enter the current time and select AM or PM. The display changes back to TIME DAY DATE. Press the Select Key under DAY to change the day of week. The keypad displays SUN MON TUE WED.

  • Page 57: Ambush Codes

    Ambush Codes Your system may be programmed to allow user number 1 to be used as an Ambush code. This Ambush code functions identically to a standard code with the exception that it sends a silent alarm to the central station. This silent alarm alerts the operator to a duress situation at the premises and prompts immediate notification of authorities.

  • Page 58: Display Events

    Display Events Allows you to review up to 12,000 past door access and system events. Examples of these events include: • Zone Activity: zone alarms, troubles, and restorals. • User Code: adding, deleting, and changing user codes. Supervisory: problems with system hardware components. •...
  • Page 59 Using the Display Events Access the User Menu. Press the COMMAND key until DISPLAY EVENTS? displays. Press any Select Key. The keypad displays FRST LST PRT SRT. a. Select FRST (first) to view the oldest to newest events. Then use the COMMAND key to scroll up through the events.
  • Page 60 At USER NUMBER, to sort events for a particular user, enter their user number or press COMMAND to sort for all users. To search for a user, press any Select Key then use the COMMAND and Back Arrow keys to browse through the user names in the system.

  • Page 61: Service Request

    Service Request Your user code profile may be programmed for Service Request. This allows you to press any top row Select key when SERVICE REQUEST? displays and have the system send a “Request for Service” message to the central station. The REQUEST MADE display confirms your request was sent.

  • Page 62: Fire Drill

    Fire Drill Fire Drill is used to test the fire bells or fire horns in your system. The Fire Drill test turns your system bell circuit on, but does not send a message to the central station. Starting a Fire Drill test Access the User Menu.

  • Page 63: Common Keypad Displays

    COMMON KEYPAD DISPLAYS Listed in the following table are several keypad messages you may see on the display. Follow the instructions in the Possible Solutions column to correct the problem. In many case, you need to call a service person to correct the problem. Displays that are not discussed here mean that your service representative should be called.
  • Page 64 MESSAGE: MEANING: POSSIBLE SOLUTIONS: INVALID AREA The user has attemped a door access to Change the user access areas if access to an area they are not assigned. the area is needed. If access is needed, the user cannot enter the area. INVALID CODE The user code you entered is not Check the user code and try again.
