Black V-Base Studio TV Stand
Instruction Manual
SKU: STAND-TV70B
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/stand-tv70b
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Related Manuals for Vivo STAND-TV70B
Summary of Contents for Vivo STAND-TV70B
- Page 1 Black V-Base Studio TV Stand Instruction Manual SKU: STAND-TV70B Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-tv70b GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com...
-
Page 2: Package Contents
WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual. -
Page 3: Tools Needed
DO NOT EXCEED TOOLS NEEDED WEIGHT CAPACITY. 88lbs Failure to do so may result in serious injury. Tape Phillips Drill Stud Finder 88lbs Pencil Screwdriver Measure (40kg) ASSEMBLY STEPS STEP 1 Slide the Feet (C) onto the base of the Leg (A). Insert M8x12mm Screws (S-A) into the bottom holes of the feet. - Page 4 STEP 2 Screw Pole (B) onto Leg (A). Loosen the set screws in Collar (B1) using the 4mm Allen Wrench (T-A). Adjust height of Collar (B1) to the recommended position below the top of the pole based on your TV’s VESA mounting hole pattern. Tighten the set screws, making sure they face towards the back of the stand.
- Page 5 STEP 3 Remove Screw (E1) from the lower VESA Bracket (E) and open the clamp. STEP 4 OPTION A: Flat Back TV Position Upper VESA Bracket (D) over top holes on TV and secure with Screws (M-A or M-B), M8 Washers (M-E) and Security Clips (P-B) Position Lower VESA Bracket (E) on the bottom holes and secure using Screws (M-A or M-B) and M8 Washers (M-E)
- Page 6 STEP 5 Slide the TV onto assembled stand. Close the clamp on the Lower VESA Bracket (E) over the pole and secure with previously removed Screw (E1).
- Page 7 STEP 6 Route cables through the cables holes in the Leg (A). Install Cable Covers (G) to the cables holes, using pliers to break out sections for x2 or x3 cables if needed.
- Page 8 Anchor TV Stand OPTION A: Wood Wall Installation Using Security Cable Clamps (P-C) as guides, mark drilling locations on the wall. Use of a stud finder is recommended. Drill holes at least 1.6” (40mm) deep using a 1/8” (3.5mm) drill bit.
- Page 9 Anchor TV Stand (continued) Mount Clamps (P-C) to the wall using ST4.8 x38mm Screws (P-E). Thread Steel Cable (P-A) through the Security Clips (P-B) on the TV and center holes in the Cable Clamps as shown, then tighten clamps using the 2mm Allen Wrench (P-C).
- Page 10 Anchor TV Stand (continued) OPTION B: Concrete/Brick Wall Installation Using Security Cable Clamps (P-C) as guides, mark drilling locations on the wall. Drill holes at least 1.6” (40mm) deep using a 9/32” (7mm) drill bit.
- Page 11 Anchor TV Stand (continued) Insert Anchors (P-F) into the holes and mount Clamps (P-C) to the wall using ST4.8 x38mm Screws (P-E). Thread steel cable (P-A) through the security clips on the TV and center holes in the cable clamps as shown, then tighten clamps using the 2mm Allen wrench (P-D).
- Page 12 AVG. RESPONSE TIME (within office hrs) - 23% within < 15m - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
