- Page 1 White Mobile Portrait to Landscape TV Cart Instruction Manual SKU: STAND-TV02PW Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-tv02pw help@vivo-us.com www.vivo-us.com 309-278-5303...
- Page 2 WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.
- Page 3 TOOLS NEEDED Phillips Wrench Needle Nose Screwdriver Pliers ASSEMBLY STEPS STEP 1 Press the lock on each caster (B) to the down (locked) position, then install the casters to the base (A). Adjust to sit flat if needed, then tighten each caster using the 10mm wrench (U). STEP 2 Slide the base poles (C) into the base, making sure the cable holes are facing towards the...
- Page 4 STEP 4 Slide the shelf mounting brackets up to cover the installed bolts, then insert x4 M6x12 bolts (O) to secure the brackets. Tighten with a Phillips screwdriver. STEP 5 1. Install the front cover (G) between the poles, making sure the face of the cover is facing towards the front, and secure using x4 M6x12 bolts...
- Page 5 STEP 6 (Continued) OPTION B: VESA 600x200mm - 600x400mm Attach VESA extensions (J, K) to the mounting plate (H) using M8x8 bolts (Q), and tighten with the 5mm Allen wrench (W). Install the assembled mounting plate to the TV. For flat back TVs, use shorter screws (M- A, M-B) with washers (M-F).
- Page 6 STEP 8 Insert x2 M8x20 bolts (M) into either the front or rear lower holes of the mounting plate. Tighten all bolts with the 5mm Allen wrench (W). STEP 9 To adjust the ease of rotation, loosen or tighten the nuts on the back of the mounting plate using the 6mm wrench (T).
- Page 7 STEP 11 (Continued) Place a power strip in the back of the mounting plate, and secure using cable ties. STEP 12 Install cable covers (L) to the cables holes in the poles, using pliers to break out sections for x2 or x3 cables if needed. STEP 13 Place the rear cover (I) onto the back of the mounting plate and secure using x4 M6x8mm bolts.
- Page 8 - 83% within < 2hr - 92% within < 3hr www.vivo-us.com : < 15 M AVG. RESOLUTION TIME (within office hrs) : 5M 4S 309-278-5303 AVG. RESOLUTION TIME (within office hrs) FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
