SPECIFICATIONS

Inputs:
Line: 10K ohm input impedance
63mV rms sensitivity for 1.22V output
Mic: 600 ohm input impedance unbalanced
1.5mV rms sensitivity for 1.22V output
180mV rms max input
Phono: 47Kohm input impedance
1mV rms sensitivity @ 1KHz for 1.22V output
Outputs:
Line: 9V rms max
Headphone: 0.5W into 47ohm
Distortion: less than 0.01%
Signal to Noise Ratio: (maximum output) JIS-A weighted
Line: Better than 92dB
Mic: Better than 82dB
Phono: Better than 85dB
Frequency response:
Line: 20Hz-20KHz +/-0.5dB
Mic: 20Hz-15KHz +/-0.5dB
Phono: +/-1dB except for controlled attenuation of -3dB
@ 20Hz to reduce rumble and feedback
Channel equalizer:
Bass: +12/-32dB @40Hz
Middle: +12/-32dB @1KHz
Treble: +10/-28dB @15KHz
Power consumption:
11.5 Watt typical
14.2 Watt with full headphone output
Dimensions:
220mm(W) by 370mm(D) by 90mm(H)
Weight: 4.2 kgs
PAGE 19 SPECIFICATIONS
