CONTROLS

5. Master Output Controls

"Master" (Main Output Level Control)
This rotary control adjusts the main output levels for any equipment connected to the Master Output on
the rear panel (Section 9 "Inputs and Outputs".) Turning the knob completely to the right increases the
level to +10dB and turning the knob completely to the left mutes the signal.
"Booth" (Master/Split Style Headphone Cueing Switch)
This rotary control adjusts the auxiliary (AKA booth) output levels for any equipment connected to the
Booth Output on the rear panel (Section 9 "Inputs and Outputs".) Turning the knob completely to the
right increases the level and turning the knob completely to the left mutes the signal.
Blue Power LED
The blue power LED will illuminate when the mixer has been connected to a power source and switched to
the "on" position (See Section 9 "Inputs and Outputs.")

6. Crossfader Controls

Crossfader with Tracking Light System
This slide fader blends between CH-1 and CH-2. Its action can be fine-tuned using the "Slope" control
switch or it can be reversed or deactivated by the "Direction" switch. A red light glows on either the right,
left or both sides for the Crossfader indicating only the position of the Crossfader, not the amount of
signal being sent to the master output.
"Slope" (Crossfader Curve Style Control)
The position of this switch determines where the startup level of CH-1 and CH-2 lie on the crossfader
(with respect to "Direction.") When switched to the left, the Crossfader will gradually fade the channel in
to the master output signal as it is engaged. When switched to the right, a very sharp fade of the
channel will occur immediately when the fader is engaged.
"Direction" (Crossfader Assignment Reverse and Deactivation Control)
The position of this switch can reverse the assignment of CH-1 and CH-2 or deactivate the Crossfader. In
the left switch setting ("Normal",) CH-1 is assigned to the left side of the Crossfader and CH-2 is assigned
to the right side of the crossfader. In the right switch setting, the assignment of CH-1 and CH-2 are
reversed on the Crossfader. In the center position, the Crossfader is deactivated.
PAGE 11
MASTER OUTPUT, CROSSFADER CONTROLS
