Service Manual
THIS DOCUMENT CONTAINS SENSITIVE
PROPRIETARY INFORMATION.
ALL RECIPIENTS MUST HAVE A CURRENT
NON-DISCLOSURE AGREEMENT ON FILE
WITH NUMARK INDUSTRIES.
COPIES OF THIS DOCUMENT
The information in this document contains privileged and confidential information. It is intended
only for the use of those authorized by Numark. If you are not the authorized, intended recipient,
you are hereby notified that any review, dissemination, distribution or duplication of this document
is strictly prohibited. If you are not authorized, please contact Numark and destroy all copies of
this document. You may contact Numark at support@numark.com.
Copyright Numark Industries
Confidential
Numark
iCDMIX 2
(NC10)
Rev. 1
2009.12.14
ATTENTION!
DO NOT MAKE ILLEGAL
Numark Service Manual
Advertisement
Related Manuals for Numark iCDMIX 2
Summary of Contents for Numark iCDMIX 2
- Page 1 The information in this document contains privileged and confidential information. It is intended only for the use of those authorized by Numark. If you are not the authorized, intended recipient, you are hereby notified that any review, dissemination, distribution or duplication of this document is strictly prohibited.
- Page 2 Your purchase of the Manual shall be for your own ultimate use and shall not be for purposes of resale or other transfer. As the owner of the copyright to the Manual, Numark does not give you the right to copy the Manual, and you agree not to copy the Manual without the written authorization of Numark.
- Page 3 CAUTION: The product under service may employ the use of a internal battery. Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer's instruction. Confidential Numark Service Manual...
-
Page 4: Safety Instructions
The product is exposed to water or excessive moisture, c. The AC power supply plug or cord is damaged, d. The product shows an inappropriate change in performance or does not operate normally, or e. The enclosure of the product has been damaged. Confidential Numark Service Manual... - Page 5 NC10-03 Unit explosive drawing...
- Page 6 NC10-01 Front panel explosive drawing...
- Page 7 NC10-02 Bottom panel explosive drawing Pick-up with deck 12 13...
-
Page 8: Block Diagram
MA ST ER B a l a n c e O u t p u t M a s t e r O u t p u t R E C O u t p u t LINE3 Ch 2 Hig h Mid B as s PHONO2 LINE2... - Page 9 NC10 BOM Position ERP Code Part name Specification Unit Q'ty 3.01.NC10.009CR Decoder board (L) NC10-14 PCB-09C 138×92mm FR-4 dual-layer R217 R227 R196 R248 R250 R252 R300 R301 3.25.05.0000R00JR SMT Resistor 0805 ±5％ R296 R297 R219 R218 BD120 BD121 BD113 BD115 R175 R174 R173...
- Page 10 NC10 BOM 3.03.LM1117.18R SMT IC LM1117-1.8 SOT-223 ±2％ U112 3.03.TCC8600.00R SMT IC TCC8600 SQFP14X14-128(N) U101 3.03.M1742.00R SMT IC PCM1742E SSO16 BB U108 3.03.39VF800.00R SMT IC SST39VF800A TSOP-48 U105 3.03.HY57V.00R SMT IC HY57V281620 TSOP54 U104 3.03.BU9543.00R SMT IC BU9543KV VQFP64 ROHM U114 SMT IC AIC809-31PU SOT-23 AIC...
- Page 11 NC10 BOM 3.11.06.01UH.10R SMT Capacitor 1UH 1210 ±10％ U109 3.23.05.222B.W1020R Electrolytic Capacitor 2200uF/10V Φ10×20mm +80%-20% 85℃ C230 C234 3.23.04.100C.W0511R Electrolytic Capacitor 100uF/16V Φ5×11mm +80%-20% 85℃ C211 C212 C233 C215 C218 C219 C220 3.23.03.10UC.W0511R Electrolytic Capacitor 10UF/16V Φ5×11 +80%-20% 85℃ C237 C238 C239 C240...
- Page 12 NC10 BOM Position ERP Code Part name Specification Unit Q'ty Remark 3.01.NC10.003DR NC10-PCB-03D 123×428mm 94VO 3.25.05.0000R00JR SMT Resistor 0Ω 0805 ±5％ RJ404 RJ202 3.25.05.0100R00JR SMT Resistor 100Ω 0805 ±5％ R211 R213 R311 R313 R411 R413 R643 R644 R101 R210 R212 R310 R312 R410...
- Page 13 NC10 BOM C204 C205 C402 C403 C603 C902 3.52.06.005R Wiring Φ0.6 J107 J213 J214 J218 J739 3.52.06.006R Wiring Φ0.6 R642 R641 J634 J633 J632 J536 J549 J553 J106 J203 J308 J317 J319 J321 J305 J303 J209 J208 3.52.06.075R Wiring 7.5mm Φ0.6 J430 J411 J104...
- Page 14 NC10 BOM 3.25.06.K560R00JR SMT Resistor 560K 1206 ±5％ R512 3.12.A8.0047R00JR Carbon Film Resistor 1/8W ±5% R500 R501 R502 R599 R529 R532 R519 R520 R523 R524 R530 R531 3.12.A8.0100R00JR Carbon Film Resistor 100R 1/8W ±5% R626 3.12.A8.0220R00JR Carbon Film Resistor 220R 1/8W ±5% R574 R573 R572...
- Page 15 NC10 BOM JR1063 JR1043 JR1042 JR1041 JR1038 JR1037 JR1036 JR1035 JR1073 JR1072 JR1071 JR1070 JR1069 JR1068 JR1025 JR1026 3.25.06.0000R00JR SMT Resistor 1206 ±5％ JR1022 JR1006 JR1024 JR1027 JR1066 JR1065 JR1067 JR1023 JR1074 JR1064 JR1031 JR1028 JR1034 JR1033 JR1030 JR1032 JR1029 3.25.06.0120R00JR SMT Resistor 120R 1206 ±5％...
- Page 16 NC10 BOM 3.07.3Y4HD.39R 3Y4HD-039 yellow LED1007 LED1005 LED1003 3.08.01.4148W05R SMT Diode IN4148 LL-34 D1001 3.05.S9014R SMT Transistor S9014 SOT23 Q1002 Q1003 3.03.78M05.00R SMT IC LM78M5 ±2％ TO252 U1005 3.03.74HC4094.00R SMT IC 74HC4094 SO-16 U1003 3.03.HT1621B.00R SMT IC HT1621B SSOP48 IC1001 3.10.03.RPI352R Coupling RPI-352...
- Page 17 +12V J1400 514S00117 DGND DGND RESERVED USB_D+ RESERVED USB_D- R1426 R1431 U1403 RESERVED J1037A +12V LM117-5V +15V 6.65K 1 ％ 26.7K 1 ％ USB_POWER +12v R1444 RESERVED +Vout U1401A ACC_ID C1425 C1426 R1423 C1400 IPOD_OUT_L RESERVED R1422 R1427 R1400 CON2 ％...
- Page 25 5.0V 5.0V J C100 BD113 L101 USBH0_D- BD120 R243 SHGND USBH0_D+ BD121 C207 R244 SHGND C223 R274 R270 MCLK_VCD C206 U107 R238 R240 BD115 BD116 R273 C193 C194 1.5K@100MHz C224 C225 VCOCLK 22pF 22pF R272 C209 R277 MCLK_1 R278 VCOIN R276 C210 Q105...
- Page 30 IC1300 J1300 KA7808 NC10-PCB-07A +8V-A CD8V C1306 3300uF/10V Φ13×20 IC1301 CON5 KA7808 J1301 C1300 103/50V +8V-B J1303 FU1001 CD8V D1300 T3A/63V~ C1323 C1307 2200uF/25V Φ12.5×25 3300uF/10V Φ13×20 IN5401 CON5 D1301 IC1302 IC1305 KA7808 KA7812 C1320 C1308 CON3 FU1002 2200uF/25V Φ12.5×25 6800uF/25V Φ18×35 R1306 T3A/63V~...
- Page 40 PB12 PB13 CON12 CON12 D1002 R1028 R1029 D1003 R1030 R1031 CU1337A-01 CU1337A-01 Title 控制板原理图 NC10 Size Number Revision Date: 15-Jul-2009 Sheet of File: D:\lzhua\Numark 4 款机 第四次修改 \nc1 0&1 4&2 00&4 00&ip od Drawn By: 控制板原理图 -4\CN1 0 控制板原理图 -C.DDB...
