Ford Bantam 2007 Owner's Manual
  1. Manuals
  2. Brands
  3. Ford Manuals
  4. Automobile
  5. Bantam 2007
  6. Owner's manual

Ford Bantam 2007 Owner's Manual

Hide thumbs

Advertisement

Table of Contents

Bantam

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Bantam 2007 and is the answer not in the manual?

Questions and answers

Terry
June 3, 2025

i need to remove and repair the side air vents and replace them

0

Related Manuals for Ford Bantam 2007

Summary of Contents for Ford Bantam 2007

  • Page 1 Bantam...
  • Page 2 WSH-M17B19-A TYRE PRESSURE - COLD TYRES (KPA) Tyre size Normal load Full load up to 2 persons Front Rear Front Rear 165/80R13T 175/65R14T Produced by Ford Motor Company of Southern Africa (Manufacturing) (Pty) Ltd. PART NO. 8S69-120609-AA Print: October 2007...

  • Page 3: Table Of Contents

    No liability can be accepted for any inaccuracies or omissions in this publication, although every possible care has been taken to make it as complete and accurate as possible. All rights reserved. Ford Motor Company of Southern Africa (Manufacturing) (Pty) Ltd. Copyright in South Africa 2005 Printed in South Africa PART NO.

  • Page 4: Introduction

    INTRODUCTION You are reminded that this manual We are delighted that you have covers specifications for all FORD selected a new FORD. Your new Bantam models and you may come vehicle has been designed and across items not necessarily speci- manufactured to provide you with fied for your vehicle.

  • Page 5: For Your Safety

    Safety and Security FOR YOUR SAFETY AND ENVI- RONMENT PROTECTION Protecting the environment We must all play our part in protecting the environment. Correct vehicle usage and Warning symbols in the authorised disposal of this guide waste cleaning and lubrica- How can you reduce tion materials are significant the risk of personal...
  • Page 6 By operating other electronic equipment (e.g. mobile tele- We wish you safe and plea- phone without exterior aerial) surable driving with your Ford electro-magnetic fields may vehicle. occur which may cause mal- function of the vehicle elec- tronics.

  • Page 7: Instrumentation

    Instrumentration On some variants the appearance and location of some items may differ from those shown here. Clock (if equipped) Ventilation vents Air conditioning (if equipped) Recirculation vent (if equipped) Front fog lamps (if equipped) Radio: See “Audio Guide” Anti-theft systems (if equipped) control light Storage compartment...
  • Page 8 Instrumentration Hazard flasher Horn Exterior lights/ Instrument direction indicators cluster Wiper lever Ignition switch Bonnet release Fuse box lever On some variants the appear- ance and location of some items may differ from those shown here. Fuel injection system shut- off switch In the event of an accident the shut-off switch will automati-...
  • Page 9 Instrumentration INSTRUMENT CLUSTER The individual instruments, warn- ing and control lights are described on the following pages. Oil pressure warning light If the light comes on during a jour- ney, stop immediately, switch off the engine and check the engine oil level.
  • Page 10 Instrumentration driving, switch off all unneces- sary electrical equipment and drive immediately to the nearest Authorised Dealer. Direction indicator control light Flashes during operation. A sud- den increase in the rate of flashing warns of a failed indicator bulb. Brake system warning light Extinguishes when the handbrake is released.
  • Page 11 Instrumentration Speedometer Speedometer Indicates the current road speed. Odometer Registers the total mileage of the vehicle. To activate press the reset Tripmeter Reset button button. Odometer Tripmeter Registers the mileage of individual journeys. To reset, depress the but- Odometer ton for approximately 3 seconds. Tachometer Indicates the engine speed in revo- lutions per minute.
  • Page 12 Instrumentration Temperature warning light (If equipped) If the light flashes, the engine is overheating. Stop immediately and Temperature switch off the ignition. Determine Warning Light the source of the problem once the engine has cooled down. Temperature gauge (If equipped) Indicates the temperature of the engine coolant.
  • Page 13 Instrumentration Air bag control light (If equipped) When the ignition is switched on (position II), the control light illuminates for approximately 5 seconds to confirm that the air bag and seat belt pretensioner systems (if equipped) are operational. In the event of the light illuminating while driving, have the system checked by an Authorised Dealer.

  • Page 14: Controls And Features

    Controls and Features HEATING AND VENTILATION Air interchange Outside air flows into the vehicle through air intakes in front of the windscreen and is directed through an air intake door, a blower, heat- er/air conditioning housing and through various distribution vents into the passenger compartment.
  • Page 15 Controls and Features Side window Recirculation vent Side window de-icing/demisting vents (if equipped) de-icing/demisting vents Air conditioner (if equipped) Centre vents De-icing/demisting vents (adjustable) De-icing/demisting vents Side vents (adjustable) Side vents (adjustable) Air distribution The airflow volume and direction can be regulated with the controls on the instrument panel and the controls on the side and centre Centre and side vents...
  • Page 16 Controls and Features Air distribution control Air distribution De-icing/demisting The left rotary control directs the air flow as follows: Face level The air flows to the face level area, a small amount is directed to the front screen. Footwell Face level Defroster The air flows to the front screen.
  • Page 17 Controls and Features Blower switch positions Front screen defrosting/ demisting Slow Select maximum temperature, set the air distribution control to Medium High the blower to its highest speed and close side and centre vents. After defrosting/demisting, switch to or a postion between to obtain comfortable distribution of air flow.
  • Page 18 Controls and Features Air conditioning Recirculation vent (If equipped) (If equipped) AIR CONDITIONING (If equipped) The air conditioning system can operate only when the outside air temperature is above +4ºC, the engine is running and the blower is switched on. Close all the windows and doors completely.
  • Page 19 Controls and Features Cooling with outside air In dry weather and high external temperatures switch on the air conditioning and turn the switch to outside air. Turn the blower on. Set the temperature control to cold. Set the air distribution to suit individual requirements.
  • Page 20 Controls and Features switched on again. Re-heating and dehumidifying of air If you find the air flow is too cool, turn the temperature control clock- wise until the air temperature is more comfortable. Select outside air or recirculated air. The air distribution should be set to suit individual requirements.
  • Page 21 When connecting appliances use only specified connectors from the FORD range. Glove compartment Pull up the handle to open. The opened lid can be used as a cup holder and has a pencil tray.
  • Page 22 Controls and Features Cup holder (If equipped) For your convenience, a cup holder is situated behind the seat. The receptacle can be moved to any position along the shelf. CAUTION Care must be taken when driving with hot drinks in the holder as sharp vehicle movements could result in occupants being scalded.
  • Page 23 Controls and Features Exterior lights/ Hazard direction indicators flasher Horn Instrument Wiper cluster lever Fuse box Ignition Bonnet release switch lever STEERING COLUMN CONTROLS Steering column lock/ignition switch The combined steering column lock/ignition switch has the follow- ing key positions: 0 Ignition off, steering wheel locked.
  • Page 24 Controls and Features II Ignition switched on, all elec- trical circuits operational. Warning and control lights If the engine does not start. illuminate. Key position ‘II’ is Do not drive the vehicle on for normal driving and must be the starter motor, as the selected if being towed.
  • Page 25 Controls and Features Adjusting to the second Hold both buttons depressed simul- taneously and release them, when a radio time signal is broadcast. Then adjust hour and minutes as described previously. Multi-function switch The following functions are avail- able only with the ignition switched on with the exception of the horn, side lights and hazard flasher.
  • Page 26 Controls and Features Hazard flasher switch Depress to activate all indicators simultaneously. Depress again to switch off. Use only in an emergen- cy to warn traffic of vehicle break- down, approaching danger, etc. It operates with the ignition switched on or off. Horn Press the pads in the steering wheel.
  • Page 27 Controls and Features 4 Washer Depress the button. The washer will operate until the button is released. Interior rear view mirror To reduce glare when driving at night, dip the mirror by pushing the lever to the rear (if equipped). Sun visors The sun visors can be released from their retention clips and swiv-...
  • Page 28 Controls and Features DOOR MOUNTED CONTROLS Convex door mirrors In both outside door mirrors the rearward field of vision is increased to minimise the so-called blind spot at the rear quarter of the vehicle. Objects seen in the outside door mirrors will look smaller and appear further away than they actually are.
  • Page 29 Controls and Features Electrically operated windows (If equipped) The windows can be operated only when the ignition is switched on. Always remove the igni- tion key when leaving chil- dren alone in the vehicle, in order to avoid risk of injury through inadvertent opera- tion of the power windows.
  • Page 30 Controls and Features CONSOLE CONTROLS Reverse gear should be engaged only when the vehi- cle is stationary. To select reverse gear, shift the lever into the neutral position and then move the lever fully to the right against spring pressure, before pulling backwards.
  • Page 31 Controls and Features Handbrake Always apply the handbrake fully before leaving the vehicle. To apply the handbrake, pull the lever up. To release it, pull the lever up slightly, depress the locking but- ton and push the lever down. The handbrake acts on the rear wheels.
  • Page 32 Controls and Features • Keys Your vehicle is supplied with two coded keys: marked with a red dot. Only these keys can be used to start your vehicle. • Automatic arming The system is armed immediately after switching off the ignition. •...
  • Page 33 Dealer with security access. Your Authorised Dealer can replace and delete keys already programmed and add new keys. The system is maintenance-free. If keys become lost you must have your FORD Dealer clear and reprogramme the code for security reasons.
  • Page 34 Controls and Features Key with radio frequency remote control The transmitter is integrated into the key. (Where specified). Radio frequency remote control The vehicle will be opened if the button is pressed unintentionally, without the remote control being directed towards the vehicle (e.g. in your pocket).
  • Page 35 Double locking should not be applied when persons are inside the vehicle. Key programming A maximum of four keys with radio frequency remote control can be programmed for your vehicle. Please ask your Ford Dealer for instructions. (Where specified).
  • Page 36 Controls and Features Replacing the battery If the range of the transmitter in the key decreases gradually, the battery (battery type 3V CR 2032) should be replaced. Proceed as follows: • Carefully separate the transmit- ter unit from the key using a flat object (e.g.
  • Page 37 Controls and Features LOCKS Door locks The doors can be locked and unlocked from the outside with the key or from the inside using the door handle. Depress (to lock) Pull (to open) The driver’s door can be locked from the outside only with the key. To lock the front passenger door, depress the door lever and close the door.
  • Page 38 Controls and Features Fuel filler flap and fuel cap To open Open the fuel filler flap, insert the key into the fuel cap, turn the key anti-clockwise and remove cap. To close Insert filler cap into filler neck, turn key clockwise, remove key and close flap.
  • Page 39 Controls and Features TAILGATE To open the tailgate, lift the handle and swing the tailgate open. Check- straps are provided which allow for ø and 180 ø opening (if equipped). To lower the tailgate to the 180 position open the tailgate to approx- imately 60 and lift the check- strap as shown in the illustration.
  • Page 40 Controls and Features Tonneau Cover Fitting Fully slide the front end of the tonneau cover into the guide rail situated on the cab back panel and ensure that it is centralised. Fit the bow into the locating pocket on the underside of the cover. Locate the bow into its locating lugs on the inside of the load body.

  • Page 41: Seating And Safety Restraints

    Seating and Safety Restraints SEATS Sitting in the correct position The occupant protection system of your vehicle utilises the seats, head restraints and seat belts. Optimal use of these components will give you more protection. Therefore, observe the following points: Max 30º...
  • Page 42 Seating and Safety Restraints Do not adjust the seats while the vehicle is moving. Moving the front seats forwards or backwards To adjust the position of a seat, lift the lever located at the inner front edge of the seat upwards. After releasing the lever, rock the seat to ensure that the catch is securely engaged.
  • Page 43 Seating and Safety Restraints SUPPLEMENTARY RESTRAINT SYSTEM Air bag (If equipped) An air bag, in combination with a seat belt, can help reduce the risk of severe injuries in the event of a significant collision. Function The air bag system activates during major collisions which are either frontal or when the impact angle is up to 30 degrees from the left or...
  • Page 44 Seating and Safety Restraints Minor front, rear, or side col- Max 30º lisions; or if the vehicle over- turns, will not activate the air bag system. For the optimum safe seating/pos- ture position please refer to “Sitting In the correct position” on the previ- ous page.
  • Page 45 Seating and Safety Restraints Front-seat-mounted rear-fac- ing child or baby seats must not be used when a passen- ger side air bag is fitted. System The air bag system comprises the following: • An inflatable nylon bag (air bag) with a gas generator concealed behind the centre pad of the steering wheel and, for the pas- senger air bag, behind the instru-...
  • Page 46 Seating and Safety Restraints Repairs to the steering wheel, steering column and air bag system should be carried out by properly trained mechan- ics. Injuries may result if the air bag is triggered inadver- tently. Your Authorised Dealer has technicians who have been carefully trained to ser- vice your vehicle.
  • Page 47 Seating and Safety Restraints SEAT BELTS Use seat belts/child restraints at all times. Never use a seat belt for more than one person. Ensure belts are worn without slack or twists and are not obstructed by other passengers or parcels etc. Avoid wearing thick and bulky clothing.
  • Page 48 Seating and Safety Restraints The seat belt should rest in the Max 30º centre of the shoulder. The lap part should fit tightly across the hips and not on the stomach. Make sure the correct buckle is used for each seat belt. Do not recline the front seats exces- sively as the belts provide maxi- mum protection when the seats are...
  • Page 49 Seating and Safety Restraints Cleaning seat belts Use FORD Upholstery Cleaner or clean warm water. Rinse and dry naturally, away from artificial heat. Do not use chemical cleaners, hot water, bleach or dye. Do not allow moisture to penetrate the inertia reel retractor mechanism.
  • Page 50 Seating and Safety Restraints Restraint System for Infants and Children Children weighing under 18 kg should be protected by a child restraint system. Seating units for infants and small children must fit the vehicle prop- erly. Before installing this kind of seat, read the seat manufacturer’s instructions.
  • Page 51 Seating and Safety Restraints Pregnant Women Pregnant women should wear seat belt assemblies as recommended by their doctors. The lap belt should be worn SNUGLY AND AS LOW AS POSSIBLE.

  • Page 52: Starting And Driving

    Starting and Driving GENERAL POINTS ON STARTING Do not operate the starter for lon- ger than approximately 15 seconds at a time. Release the ignition key as soon as the engine has started. Starter inhibitor: Before the starter motor can be operated a second time, the ignition key must be returned to position ‘I’...
  • Page 53 Starting and Driving If the battery has been disconnect- ed, the vehicle may exhibit some unusual driving characteristics for approximately 8 km after battery reconnection. This is due to the automatic relearning of the engine man- agement system and should be ignored.
  • Page 54 Starting and Driving STARTING THE ENGINE COLD ENGINE • Depress the clutch fully and start engine without touching the accelerator. Note: A cold engine runs at a higher idling speed after starting. Clutch pedal • If the engine does not start with- in 5 seconds, wait for a period and repeat procedure.
  • Page 55 Starting and Driving BRAKES Dual circuit braking system Your vehicle is equipped with a diagonally split dual circuit braking system. Disc brakes are fitted to the front wheels and drum brakes to the rear. If one of the brake cir- cuits fail, the other remains opera- tive.
  • Page 56 Starting and Driving Always use unleaded fuel only. Your vehicle has a reduced diameter fuel tank filler neck compatible with unleaded fuel supply nozzles only. Use the highest octane unleaded fuel available. Do not use Lead Replacement Fuel (LRP). To avoid fuel overspill from Euro Emission II the filler neck, stop refuel- The vehicle is equipped with...
  • Page 57 Starting and Driving Euro II Emissions FUEL CONSUMPTION Fuel consumption and CO emissions The vehicle is equipped with an are dependent upon the motor, the active carbon canister that will store type of gear transmission, the tyre all evaporative emissions until it size, the kerb weight as well as many can be purged through the intake other factors.
  • Page 58 Starting and Driving Vehicle load conditions Travelling fully laden will result in higher fuel consumption. Hints for economical driving and preserving the environ- Vehicle condition ment: Low tyre pressure or inadequate engine or vehicle maintenance will • Drive away immediately also result in higher fuel consump- without warming the engine tion.

  • Page 59: Roadside Emergencies

    Roadside Emergencies HAZARD FLASHER WARNING SWITCH Use only in an emergency to warn traffic of vehicle breakdown, approaching danger etc. Depress to activate. Depress again to switch off. The hazard lights can be operated when the ignition is switched off. LIMITED OPERATION STRATEGY PROGRAMME The engine management system...
  • Page 60 Roadside Emergencies The switch is located in the side panel in front of the left hand side door. The button will be raised when the switch has been activated. To avoid the possibility of fire or personal injury, do not reset the fuel pump shut-off switch if you see or smell fuel from the fuel system.
  • Page 61 Roadside Emergencies Have the headlamp alignment checked by an Authorised Dealer after removal of any of the light assemblies. Removing the light assembly • Switch off the lights. • Open the bonnet. • Lift the radiator grille straight up. • Remove the 3 screws in the light assembly.
  • Page 62 Roadside Emergencies High Beam Release the wire clip and remove the electric connection and the bulb. Install in reverse order. Pay attention to the tab guide when replacing. Side light 5 watt wedge base bulb. Pull the socket out. Pull the bulb out.
  • Page 63 Roadside Emergencies Rear lights Remove the four rear light retaining screws and disconnect the electrical connector. Brake lights/Tail lights, Rear direction indicator lights, Reverse lights. 1. Turn the bolts anticlockwise and remove them. 2. Turn the socket and bulb assembly anticlockwise and remove it.
  • Page 64 Roadside Emergencies Interior light Switch off the interior light. Carefully prise off the lens with a flat screwdriver and replace the defective festoon bulb. 10 watt festoon bulb. Number plate light Carefully remove the number plate retaining screws. Remove the number plate light cover.
  • Page 65 Roadside Emergencies FUSES AND RELAYS Switch off the ignition and Central fuse box all the electrical equipment before changing a fuse or relay. Always replace a faulty fuse with a new one of the same rating. The fuse box is located as shown above and contains the main fuses and the main relays.
  • Page 66 Roadside Emergencies Central fuse box, front Fuse Ampere Rating Colour Circuits protected blue Cigar lighter, central locking Interior lights, clock, radio station memory, diagnostic plug Fuel pump blue Hazard flasher/horn Side lights left-hand side Side lights right-hand side blue PCM module Light switch ignition Dipped beam left-hand side Dipped beam right-hand side...
  • Page 67 Roadside Emergencies Central fuse box, rear side Fuse Ampere Rating Colour Circuits protected Diode High and low beam head lamp interface *The replacement of this fuse/relay requires specialised knowledge...
  • Page 68 Roadside Emergencies Relays in the central fuse box Relay Colour Circuits connected green Starter motor Intermittent wipers green Front fog lamps – Not used green Ignition switch – Not used white Anti-theft flasher Vlll green Lights-on warning – Not used –...
  • Page 69 Roadside Emergencies CHANGING A WHEEL It is extremely important to observe the following pre- cautions before jacking up the vehicle. Park your vehicle in such a posi- tion that neither the traffic nor you are hindered or endangered when changing the wheel. Ensure that the vehicle is on firm, level ground.
  • Page 70 Roadside Emergencies Jack The jack and wheel wrench are stored behind the passenger‘s and driver’s seat backs, respectively. When the vehicle is raised with the vehicle jack carry out wheel changes only. Do not work underneath the vehicle. Using the wheel wrench loosen the spare wheel carrier retaining bolt.
  • Page 71 Roadside Emergencies Jacking points Place the jack at the front or rear jacking position closest to the tyre you are changing. (1) When changing a front wheel, this is identified by a small inden- tation on the flange of the sill. (2) When changing a rear wheel, locate the jack under the turn- down on the rear leaf spring.
  • Page 72 Roadside Emergencies Removing a wheel • Make sure that the front wheels are pointing straight ahead. • Apply the handbrake and select reverse or first gear. • Nobody should be in the vehicle. • Secure the vehicle against roll- ing or sliding. •...
  • Page 73 Roadside Emergencies Fitting a wheel • Push the wheel onto the wheel studs. Screw on the wheel nuts and secure in a clockwise direc- tion ensuring that the tapered end of the wheel nuts are facing the wheel. • Lower the vehicle and remove the jack.
  • Page 74 Roadside Emergencies BATTERY Safety advice Always take the following precautions when handling a battery: • Wear eye protection. Do not let acid or lead particles come into contact with your skin or cloth- ing. • Battery acid is caustic. Wear gloves and eye protection.
  • Page 75 Roadside Emergencies Removal and installation Always take the following precautions when removing and refitting a battery: • The current and capacity of any battery must correspond with that of the old battery. Contact an Authorised Dealer for correct bat- tery specifications. •...
  • Page 76 Roadside Emergencies If the battery has been disconnect- ed, the vehicle may exhibit some unusal driving characteristics for approximately 8 km after battery reconnection. This is due to the automatic relearning of the engine man- Flat battery agement system and should be ignored.
  • Page 77 Roadside Emergencies Do not connect to the negative (-) terminal of the flat battery. • Make sure that the jump leads Flat battery are clear of any moving parts. To start the engine • Run the engine of the vehicle with the booster battery at mod- erate speed.
  • Page 78 Roadside Emergencies TOWING THE VEHICLE Your vehicle is equipped with a tow- ing eye at the front for attaching a towrope. Prise off the cover in the bumper with a flat-bladed screwdriver. After use re-insert the cover. Note: The towing eye is fitted with a left-hand thread.
  • Page 79 Roadside Emergencies Proper lifting or towing equipment is necessary to prevent damage to the vehicle during any towing operation. Government laws appli- cable to vehicles on tow must be observed. If the transaxle, rear axle and steer- ing system are not damaged, the vehicle may be towed on all four wheels, at speeds of less than 55 km/h, for distances up to 80 km.
  • Page 80 Roadside Emergencies Power brake/steering assis- tance will not be available when the engine is inop- erative. When towing under such conditions, the effort required to steer and brake the vehicle will be substan- tially increased. Starting the engine by hav- ing the vehicle towed can be dangerous.
  • Page 81 Roadside Emergencies The ignition key must be set to position ‘II’ if the vehicle is being towed so that the steering, direction indica- tor warning lights and brake lights are fully operational. Front towing eye Note: The towing eye is fitted with a left-hand thread.
  • Page 82 Roadside Emergencies Starting vehicles by towing or pushing It is possible to start a cold engine by towing or pushing the vehicle: • Turn the ignition key to position ‘II’. • Depress the accelerator pedal. • Depress the clutch pedal and select third gear.

  • Page 83: Maintenance And Care

    Maintenance and Care SERVICING Servicing by FORD When it comes to maintenance operations which are essential for the reliability and roadworthiness of your vehicle, keep to the service intervals indicated in the Service Book. We recommend that you always use an Authorised Dealer.
  • Page 84 Maintenance and Care The electronic ignition sys- tem works with high voltage. Never touch these compo- nents with the engine run- ning or the ignition switched General vehicle care When an engine is washed, fuel, grease and oil residues are washed off.
  • Page 85 Maintenance and Care MAINTENANCE CHECKS Everyday check: • Operation of all exterior and inte- rior lights. Replace burnt out or dim bulbs and make sure that all lenses are clean. When refuelling check: • Engine oil level. • Brake fluid level. •...
  • Page 86 Maintenance and Care Opening the bonnet • Pull the bonnet release lever (1). • Raise the bonnet slightly at the front and push the safety catch (2) sidewards. • Raise the bonnet and support it with its strut in the yellow coloured retainer ensuring it is secure.
  • Page 87 Maintenance and Care 1.3/1.6 RoCam engine compartment Purge Valve Asy Windscreen washer Engine coolant Brake/Clutch fluid reservoir reservoir fluid reservoir Engine oil filler cap Vehicle identification plate Power steering Air cleaner fluid reservoir Battery (if equipped) Engine oil dipstick Note: For ease of identification, all filler caps and the engine oil dip- stick are marked yellow/black.
  • Page 88 Maintenance and Care Engine oil dipstick The oil consumption of your engine is influenced by many factors. New engines reach normal oil consump- tion after approximately 5 000 km. High performance engines consume slightly more oil. Under high loads, your engine also will All RoCam engine variants consume more oil.
  • Page 89 Maintenance and Care If the oil level lies at the MIN mark refill using only engine oil that meets Ford’s specifications. Approximately 0.5 - 1.0 litre of engine oil will raise the level of the oil film on the dipstick from the MIN to the MAX mark.
  • Page 90 MIN mark, the brake fluid level warning light will illuminate. Add only brake fluid that meets FORD’s specifications. Refer to the section Capacities and specifica- tions. Have the system checked for leakage by an Authorised Dealer as soon as possible.
  • Page 91 Wait a moment then open fully. Top up with a mixture of 50% water and 50% coolant. Add only coolant that meets the FORD specification. For fur- ther details, refer to the section Capacities and specifications. Do NOT mix different colour...
  • Page 92 For this reason, use only coolant which meets FORD’s specifications. See the section Capacities and specifications. Power steering fluid level Switch off the engine. With the...
  • Page 93 Maintenance and Care Battery The battery requires minimal main- tenance. The level of battery fluid should be checked regularly as part of every service. When replacing a battery, the cur- rent and capacity of the new battery must correspond with that of the old battery.
  • Page 94 Traces of grease, silicone and fuel also prevent wiper blades from functioning properly. We recom- mend FORD cleaning solutions to clean wiper blades. Change the wiper blades at least once a year. Renewing wiper blades...
  • Page 95 Maintenance and Care Observe the correct tyre pres- sures especially with high payloads and when driving at high speeds. Under-inflation reduces stabil- ity, increases rolling resistance, accelerates tyre wear and causes preliminary damage that may lead to accidents. If you have to mount a kerb, do so slowly and, if possible, approach it with the wheels at right angles.
  • Page 96 Maintenance and Care Tyre rotation Tyre rotation chart with spare wheel Because a vehicle’s wheels perform different jobs, the tyres often wear differently. To make sure your tyres wear evenly and last longer, rotate them every 10,000 km. If you notice that the tyres wear unevenly, have them checked.
  • Page 97 Maintenance and Care VEHICLE CARE Washing your vehicle Use only car washing areas that have environmentally friendly drainage systems. Cleaning materials must not be dis- posed of in the household waste. The most important element required to maintain the vehicle’s paintwork is clean water.
  • Page 98 Maintenance and Care Unscrew and remove the radio aerial before entering an auto- matic car wash. Switch off the heater blower. Power washer The manufacturer’s instructions for any power washer should be fol- lowed, especially in reference to the pressure and spraying distance. Do not spray the radiator with a power washer.
  • Page 99 Never use abrasives as these will damage the special surface finish. Cleaning products For best results use the following products from the FORD Car Care range available at your Authorised Dealer: • Car shampoo. • Car shine.
  • Page 100 Maintenance and Care Paint chip repair Paint damage such as chips or minor scratches can be dealt with using touch-up paint from an Authorised Dealer. Observe the application instructions on each product. To retain vehicle warranty on paintwork remove harmless looking but often aggressive particles from the paintwork immediately - e.g.
  • Page 101 Maintenance and Care Body paintwork preservation Wax the body paintwork of your vehicle once or twice a year. This will help retain the glossy paint- work finish and water droplets will run off more easily. When polishing your vehicle, ensure that the polish does not come into contact with the plastic surfaces, as it may prove difficult to remove.

  • Page 102: Capacities And Specifications

    Capacities and Specifications IDENTIFICATION NUMBERS Vehicle identification plate The vehicle identification plate is located in the engine compartment. This plate bears information on vehicle type, vehicle weights and identifies various components. Vehicle identification plate Engine number The engine number is stamped on the engine block.
  • Page 103 Capacities and Specifications When the filler cap is removed, a hissing noise may be heard. This is normal and should be ignored. To avoid fuel spillage, always stop refuelling at the second automatic shut-off of the filler nozzle. Unleaded fuel (95 Octane - coast;...
  • Page 104 EFL 600 ENGINE OIL Gear Ratios Engine oil change 1.3l 1.6l FORD Motor Company recom- Gear RoCam RoCam mends the use of SAE 15W-40 SH 3.58 3.58 or SJ engine oil. The engine in your vehicle was designed to use this oil.
  • Page 105 Capacities and Specifications Engine oil top-up If you are unable to find an oil that meets any of the aforementioned specifications, you can use an oil of the viscosity SAE 10W-30, SAE 10W-40 or SAE 5W-40 according to the ambient temperature. Use of these oils may result in longer cranking periods, reduced engine performance, reduced fuel econo-...
  • Page 106 VEHICLE FLUIDS Gear oil Manual transmission/transaxle Use FORD transmission oil or transmission oil meeting FORD specification WSD-M2C200-B 75W90. The transmission does not require any maintenance. No oil changes are necessary.
  • Page 107 Capacities and Specifications Brake and clutch fluid Use brake fluid meeting DOT 4 specification or brake fluid accord- ing to FORD specification SAM- 6C9103-A. Top up to the MAX mark if required. Use only brake fluid which is ‘paraf- fin-free’.
  • Page 108 Capacities and Specifications A/C refrigerants Use CFC-free refrigerant R134a, YN11 meeting the FORD specifica- tion WSH-M17B19-A. A/C system charge capacity: 350g Ask your Authorised Dealer to ser- vice the A/C system. Screen washer fluid Fill the reservoir with water and screen washer solution.
  • Page 109 Inclusive of coolant, lubricants, tools and spare wheel but exclud- ing the weight of fuel. (c) Maximum Gross Axle FORD MOTOR COMPANY OF SOUTHERN AFRICA Mass (Rear) MODEL CHASSIS TRIM (b) Maximum Gross Axle...
  • Page 110 Capacities and Specifications VEHICLE WEIGHTS Observe the weights shown on your vehicle’s Data Plate and do not exceed the permis- sible gross mass. Exceeding these values causes changes to the braking and driving behaviour of the vehicle and might cause an accident. The kerb weight is the mass of the vehicle with the fuel tank filled, i.e.
  • Page 111 Capacities and Specifications Dimensions (mm) A = Overall length 4269 B = Overall width (excluding exterior mirrors) 1632 C = Overall height (kerb weight) 1374 D = Wheelbase 2662 E = Track Front 1429 Rear 1437...

  • Page 112: Index

    Index Door mounted controls ....26 Air bag control light ....11/44 Air conditioning ....16/18 Alarm .
  • Page 113 Index Power assisted steering ..104 Identification numbers ..100 Power steering fluid level ..90 Ignition switch operation ..21 Proper use and care Ignition warning light .
  • Page 114 Index Tripmeter ....9 Tripmeter reset knob ... 9 Transmission oil ....104 Turn and lane change signal lever .
