44 Installation fundamentals
Table 5
AC power specifications (cont'd.)
Efficiency

Nortel Ethernet Routing Switch 5530-24TFD

This section details the power requirements of the Nortel Ethernet Routing
Switch 5530-24TFD.
The following table lists the power specifications for the Nortel Ethernet
Routing Switch 5530-24TFD.
Table 6
AC power specifications
Input current
Input voltage (rms)
Typical power consumption
Typical thermal rating
Maximum power consumption
Maximum thermal rating
Inrush current
Turn on condition
Efficiency

5500 Series power options

This section describes the available power options for Ethernet Routing
Switch 5500 Series switches.
Nortel Ethernet Power Supply 10
This module describes the Nortel Ethernet Power Supply 10.
Copyright © 2008–2009 Nortel Networks
ERS 5000 Series Installation
NN47200-300 04.03
13 April 2009
70 percent minimum
1.7 A at 120 VAC or 0.85 A at 240
VAC
100 to 240 VAC 50/60 Hz
125 W
427 BTU/Hr
150W
512 BTU/Hr
20 A 120 VAC at maximum load, 40 A
240 VAC at maximum load
1 second maximum after application of
AC power.
Attention: 12 V output rise time,
from 10 percent to 90 percent,
shall be a maximum of 50 ms and
monotonic under all defined input
and output conditions.
70 percent minimum
