- Page 1 User manual DUAD540 STROBE Please read the instructions carefully before use...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Safety Instructions……………………………………………………………………………3-4 Technical Specifications…………………………………………………………………………4 Control Menu ………………………………………………………………………………………5 DMX Channels ……………………………………………………………………………………6-9 Trouble Shooting…………………………………………………………………………………10 Fixture Cleaning………………………………………………………… ………………………10 STATEMENT The product has well capability and intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also can not be responsible for any malfunction &... -
Page 3: Safety Instructions
1.Safety Instructions Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. Unpack and check carefully there is no transportation damage before using the unit. •... -
Page 4: Technical Specifications
fixed to avoid vibration and slipping while operating. And make sure that the structure to which you are attaching the unit is secure and is able to support a weight of 10 times of the unit’s weight. Also always use a safety cable that can hold 12 times of the weight of the unit when installing the fixture. •The equipment must be fixed by professionals. -
Page 5: Control Menu
3.Control Menu Item Silkscreen Function MENU Enter/check menu ① Check the last menu ② Button: DOWN Check the next menu ③ ENTER Enter the menu or confirm ④ Menu Operation System Settings Menu 1 Menu 2 Menu 3 Function DMX Address 001--512 DMX Address Code CH-16... -
Page 6: Dmx Channels
4.DMX Channels 16 CH Mode Value Function Pan movement, 0-540°Adjustable Speed fast-slow No function Anticlockwise unlimited rotation, fast-slow Stop rotation Clockwise unlimited rotation, slow-fast Tilt movement, 0-360°adjustable Move speed,fast-slow No function Tilt Unlimited rotation(down),fast-slow Stop rotation Unlimited rotation(up),slow-fast Brightness 0-100% Dimmer Red linear dimmer,0-100% Green linear dimmer,0-100%... - Page 7 Y fine No function Unlimited rotation(down),fast-slow Stop rotation Unlimited rotation(up),slow-fast Brightness 0-100% Dimmer CH10 LED1 color selection CH11 LED2 color selection CH12 LED3 color selection 40W,LED CH13 LED4 color selection CH14 LED5 color selection CH15 LED1 color selection CH16 LED2 color selection CH17 LED3 color selection SMD RGB...
- Page 8 Random Show Show speed, slow-fast Speed/ sound control CH22 sentivity Sound control & sensitivity, low-high No function CH23 Reset after 3s Reset No function 48 CH Mode Value Function Pan movement, 540° adjustable Tilt movement, 540° adjustable X fine No function Anticlockwise unlimited rotation, fast-slow Stop rotation Clockwise unlimited rotation, slow-fast...
- Page 9 CH32 B1 dimmer,0-100% CH33 R2 dimmer,0-100% CH34 SMD 2 G2 dimmer,0-100% CH35 B2 dimmer,0-100% CH36 R3 dimmer,0-100% CH37 G3 dimmer,0-100% SMD 3 CH38 B3 dimmer,0-100% CH39 R4 dimmer,0-100% CH40 SMD 4 G4 dimmer,0-100% CH41 B4 dimmer,0-100% CH42 R5 dimmer,0-100% CH43 G5 dimmer,0-100% SMD 5 CH44...
-
Page 10: Trouble Shooting
6.Trouble Shooting Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. The unit does not work, no light and the fan does not work 1. Check the connection of power and main fuse. 2.
