Summary of Contents for StarTech.com VIDWALLMNT
Page 1
Video-Wall Mount VIDWALLMNT *actual product may vary from photos FR: Guide de l’utilisateur - fr.startech.com DE: Bedienungsanleitung - de.startech.com ES: Guía del usuario - es.startech.com NL: Gebruiksaanwijzing - nl.startech.com PT: Guia do usuário - pt.startech.com IT: Guida per l’uso - it.startech.com JP: 取扱説明書...
Page 2
StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby...
Page 3
Warning statements Dichiarazioni di avvertenza Make sure that you assemble this product according to the instructions. Assicurarsi di Assemblare il prodotto secondo le istruzioni. Read the entire manual and make sure that you understand the instructions before you start to assemble Leggere l’intero manuale e assicurarsi di aver compreso tutte le istruzioni prima di iniziare ad assemblare and use this product.
Page 4
Advertencias de uso Asegúrese de ensamblar este producto según las instrucciones. Lea todo el manual y asegúrese de haber comprendido bien las instrucciones antes de proceder con el ensamblaje y el uso de este producto. Nunca opere o ponga en funcionamiento este producto si faltan piezas o hay daños en las mismas. El uso de este producto es solo para interiores y no debe utilizarse en exteriores.
Table of Contents Warnings ..............................i Product dimensions ................1 Product diagram ..................2 Technical specifications ................3 Requirements ..................3 Package contents ...................4 Attach the wall plate to the wall ............7 Attach the adjustment module ............9 Attach the adapter brackets to the TV ..........11 Attach the TV to the adjustment module ...........14 Pop a TV out from the wall ..............15 Use the kickstand ...................16...
Page 6
Adjust the gap between the TVs ............29 Technical support ...................30 Warranty information ................30 Instruction manual...
RATED LOAD -50 to +30 TILT Between 45 in. and 70 in. SCREEN -30 to +30 LEVEL Requirements • TV that is compatible with one of the VESA mounting hole patterns that VIDWALLMNT supports • Phillips type screwdriver Instruction manual...
Package contents Wall plate Adjustment module Qty: One Qty: One Adapter brackets Stoppers Qty: Two Qty: Two Plastic tabs Hex key Qty: Two Qty: One Instruction manual...
Page 11
M5x14 mm screws M6x14 mm screws Qty: Four Qty: Four M8x20 mm screws M6x30 mm screws Qty: Four Qty: Four M8x30 mm screws Rectangular washers Qty: Four Qty: Four Instruction manual...
Page 12
Small spacers Large spacers Qty: Eight Qty: Four 6.3x55 mm screws Concrete anchors Qty: Six Qty: Six Washers Instruction manual Qty: Six Qty: One Instruction manual...
Warning! Make sure that the weight of the TV doesn’t exceed the weight capacity of this product. If you exceed the weight capacity, you might experience personal injury or damage to the product. The video-wall mount can support up to 70 kg (154 lb.). Attach the wall plate to the wall Warning! The wall mount is designed to be installed on a wood stud, solid concrete, or cinder block wall.
mounting hardware. (figure 3) 5. Follow the appropriate steps for the type of wall that you’re using and attach the wall plate to the wall. (figure 4) figure 2 Wall plate Attach the adjustment module figure 3 Wall Wall plate Instruction manual...
Page 15
Note: It may require two people to attach the adjustment module to the wall plate. figure 4 Mounting hardware Wall plate 1. Remove the zipped ties from around the adjustment module. 2. Push on the front of the adjustment module to expand it. 3.
figure 5 Adjustment module Plastic cap Attach the adapter brackets to the TV figure 6 Adjustment module Wall plate Instruction manual...
Page 17
1. Determine if the back of the TV is flush or inset and measure the depth and figure 7 Adjustment module Screw diameter of the mounting holes on the TV. 2. With the information you obtain in step 1, consult the diagrams on the next page to determine the best configuration of the mounting hardware for the TV that you’re using.
Page 18
4. Position the adapter brackets over the spacers or the mounting holes in the back of M5x14 mm M6x14 mm M8x20 mm the TV. (figure 8) M8x20 mm Small spacer M8x20 mm M8x30 mm M6x30 mm Two small spacers M8x30 mm M6x30 mm Small spacer Large spacer...
Note: Make sure that the arrows on the adapter brackets are pointing towards the top of the TV. 5. Place the rectangular washers over the adapter brackets. 6. Insert the screws through the rectangular washers, adapter brackets, spacers (if required), and into the back of the TV. (figure 9) figure 8 Adjustment bracket Top of TV...
Page 20
1. At the top of each of the adapter brackets, push the knobs down and turn them counterclockwise to the unlocked position. (figure 10) 2. Carefully hook the adapter brackets onto the adjustment module. (figure 11) 3. At the top of each of the adapter brackets, push the knobs down and turn them clockwise to the locked position.
(padlock not provided). (figure 12) Pop a TV out from the wall The VIDWALLMNT includes a pop-out feature that you can use to access and adjust the figure 12 mounted TVs. • Carefully push the TV in towards the wall. (figure 13) To retract the TV, carefully push the TV towards the wall again.
1. Carefully push the TV in towards the wall to pop it out. 2. Pull the bottom of the TV away from the wall and pull the kickstand down. (figure 14) Lock the TV against the wall figure 14 Kickstand If you want to lock the TV and prevent people from being able to pop it out from the wall, complete the following: 1.
figure 15 Projection Position upwards Adjusting the position of the TV You can adjust the tilt, horizontal position, vertical position, depth, and swivel of the figure 16 Plastic tab Instruction manual...
Warning! If you’re adjusting a TV that is part of a multi-unit display, you need to adjust the TVs in a specific order. Starting on the lowest row of TVs, adjust the TV on the far left and move right. When the lowest row has been adjusted, move up a row and adjust the TVs from left to right.
1. If necessary, pop the TV out from the wall. 2. Position the stoppers so that the screws are facing towards the TV. 3. Slide the stoppers onto the adjustment module, placing them right next to the adapter brackets. 4. Use the hex key to tighten the screws in both of the stoppers. (figure 19) Adjust the tilt angle of the TV figure 19 Stopper...
figure 20 Handle Adapter brackets Adjust the vertical position of the TV figure 21 Handle Adapter brackets Instruction manual...
Page 27
1. If necessary, pop the TV out from the wall. 2. Do one of the following: • To move the TV upwards, use a Phillips type screwdriver and turn the screws at the top of the adapter brackets clockwise. (figure 22) •...
Make the TV level figure 23 Screw Adapter brackets Instruction manual...
Page 29
1. If necessary, pop the TV out from the wall. 2. Do one of the following: • To move the left side of the TV upwards, use a Phillips type screwdriver and turn the screw at the top of the left adapter bracket clockwise, and the screw at the top of the right adapter bracket counterclockwise.
Page 30
turn the screw at the top of the left adapter bracket counterclockwise, and the screw at the top of the right adapter bracket clockwise. (figure 25) figure 25 Screw Adapter brackets Left Right Instruction manual...
Adjust the depth of the TV 1. If necessary, pop the TV out from the wall. 2. Do one of the following: • To move the TV away from the wall, turn the knobs on either side of the adjustment module counterclockwise. (figure 26) figure 26 Knob Adjustment module...
Page 32
• To move the TV towards the wall, turn the knobs on either side of the adjustment module clockwise. (figure 27) figure 27 Knob Adjustment module Instruction manual...
Adjust the swivel angle of the TV 1. If necessary, pop the TV out from the wall. 2. Do one of the following: • To move the left side of the TV away from the wall, turn the knob on the left side of the adjustment module counterclockwise, and the knob on the right side of the adjustment module clockwise.
Page 34
• To move the right side of the TV away from the wall, turn the knob on the left side of the adjustment module clockwise, and the knob on the right side of the adjustment module counterclockwise. (figure 29) figure 29 Knob Adjustment module Left...
Page 35
Adjust the gap between the TVs Warning! To have the clearance to pop TVs out from the wall and to accommodate any expansion of the TVs, you need to make sure that there is a 1.2 mm gap between all of the TVs.
Page 36
Limitation of Liability In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their officers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product.
Page 37
Hard-to-find made easy. At StarTech.com, that isn’t a slogan. It’s a promise. StarTech.com is your one-stop source for every connectivity part you need. From the latest technology to legacy products — and all the parts that bridge the old and new — we can help you find the parts that connect your solutions.
