CVM-B100 - CVM-B150
7�2�- RELAY DIGITAL INPUTS/OUTPUTS
This expansion module features 8 relay digital inputs and 8 relay digital outputs.
7�2�1�- CONNECTION TERMINALS
A�- Terminals on the upper face
Table 68: List of terminals on the upper face, Relay digital inputs/outputs module�
1: R , Digital output of relay 1
1
2: R
, Digital output of relay 2
2
3: R
, Digital output of relay 3
3
4: R
, Digital output of relay 4
4
5: COM , Common digital outputs of relay R
B�- Terminals on the lower face
Table 69: List of terminals on the lower face, Relay digital inputs/outputs module�
11: COM, for digital inputs
12: I
1
13: I
2
14: I
3
15: I
4
Instruction Manual
Device terminals
R R
1, 2, 3 and
3
1 2 4
Figure 261: Terminals of Relay Digital Inputs/Outputs, upper face�
Device terminals
, Digital input 1
, Digital input 2
, Digital input 3
Digital input 4
,
11 12 13 14 15 16 17 18 19
Figure 262:Terminals of Relay Digital Inputs/Outputs, lower face�
6: R , Digital output of relay 5
5
7: R
, Digital output of relay 6
6
8: R
, Digital output of relay 7
7
9: R , Digital output of relay 8
8
10: COM, Common digital outputs of relay R
R
4
R
8
5 6 7 8 9 10
16: I
, Digital input 5
5
17: I
, Digital input 6
6
18: I
, Digital input 7
7
19: I , Digital input 8
8
R R
5, 6, 7 and
