ST STM32Cube Quick Start Manual page 19

Function pack for stevalstwinbx1 evaluation kit for high speed datalogging and ultrasound processing

Hide thumbs Also See for STM32Cube:

Firmware Update – USB

The STEVAL-STWINBX1 can also be reprogrammed via USB using the

STM32CubeProgrammer "USB mode".

To enter "Firmware upgrade" mode you must follow the procedure

below:

• Unplug the core system board.

• Press the USR button.

• While keeping the button pressed, connect the USB cable to the PC.

• Now the board is in DFU mode.

Open

STM32CubeProgrammer,

select the proper binary file and download the firmware.

For further details, see UM2965
