Rectifier
PSR06-W
User Manual
Page 7 (24)
3.
Start up procedure
Before connecting to the input voltage, it should be checked whether the voltage information on the rating plate
corresponds to the available voltage and also that the polarity corresponds to the connection plan of the plug. The
mains connection is done via terminals below the cabinet. The protective conductor should be generally connected
(protection class 1, leakage current ≤ 3.5mA).
The DC output contact has to be connected on terminal X1. The signalling contacts for monitoring, sense links and
active current are to be connected on terminal X2/X3.
Important:
The rectifier has big capacitors at the output. If you connect a switched off module to a battery or other modules
which operate in paralleling, there is a big capacitor charge current. This current may destroy the contacts on out-
put connectors.
WARNING! After switching off, the capacitors hold its voltage for several times. Do not touch!
The rectifier operates with convection cooling. The ambient temperature has to be less than +55°C. If there is a
higher temperature, the life time of the modules will be decreased.
The losses per module are approx. 40 to 80W (depends on type).
4.
Operation
All operation elements are located on the front panel of the module. The function of each element is explained on
the following pages. See also the front panel drawing on section 7.1.
ELTEK VALERE DEUTSCHLAND ©2009
UM_PSR06-W_E_R1.1
