1.
General Information
The primary switched mode rectifier type PSR06-W (named SMPS on the next pages) delivers an output power of
approx. 600W. Typical applications are DC power supplies and uninterruptable power supply with battery.
Rectifiers of type SMPS have good dynamic regulation properties concerning input voltage changes and load varia-
tions.
It works with an IV characteristic in accordance with DIN 41772 and it is a complete connectable module in a wall
cabinet. The operation elements and measurement instruments are located on the front panel, the input/output
connectors are located at the bottom of the module.
SNT modules also operates single side grounded or ungrounded at input and output.
2.
Type Range
Type
Article code
Designation
PSR06/
24-20W
100-006-142.00
48-10W
100-006-152.00
60-8.2W
100-006-162.00
110-4.5W
100-006-172.00
Available options and accessories:
1) Temperature sensor lead LM 335 (sensor lead in M5 cable shoes with 2m wire); article code: 880-300-TMP.00
2) Temperature sensor lead LM 335 (sensor lead in M5 cable shoes with 4m wire); article code: 880-300-TMP.01
ELTEK VALERE DEUTSCHLAND ©2009
Input voltage range
(V
)
AC
120-230 (-15/+10%)
120-230 (-15/+10%)
120-230 (-15/+10%)
120-230 (-15/+10%)
Output-
Output-
voltage
current
(V
)
(A)
DC
24
20
48
10
60
8.2
108
4.5
UM_PSR06-W_E_R1.1
