Item Quantity Reference
28 1
29 1
U4, U5, U6, U7, U8, U9, U10, U11,
30 15
U12, U13, U14, U15, U16, U17, U18
31 2 U19, U21
32 1
33 1
34 1
35 4 D12, D13, D14, D15
36 1
37 1
38 1
39 1 NO POP
40 4
SLLU163 – May 2012
Submit Documentation Feedback
Table 1. TUSB8040AEVM BOM (continued)
Part
U2 TPS3808G33DBV - Voltage Supervisor
U3 AT24C04 / SOCKET - I2C EEPROM
TPD2EUSB30 - USB ESD Protection
TPS2560DRC - USB Power Switch
U20 TPS7A4533 - 3.3V Voltage Regulator
U22 TPS74801RGW - 1.1V Voltage Regulator
Y1 ECS-24MHZ Crystal
Green Amber LED
JP1 Conn 2x5 shroud
R8 9.09K 1%
FB2 0 ohm
NO POP AC Power Adapter
PCB Feet
Copyright © 2012, Texas Instruments Incorporated
Manufacturer Part Number
Texas Instruments TPS3808G33DBV
AT24C04A-10PU-1.8 /
Atmel / Tyco
2-641260-1
Texas Instruments TPD2EUSB30
Texas Instruments TPS2560DRC
Texas Instruments TPS7A4533KTT
Texas Instruments TPS74801RGW
ECX-53B
ECS
(ECS-240-20-30B-TR)
Panasonic LNJ115W88
3M LNJ115W88
Panasonic - ECG ERJ-2RKF9091X
CUI Inc ETSA050360UDC-P5P-SZ
Richco Plastic Co RBS-12 or RBS-32
TUSB8040AEVM Bill of Materials
Appendix B
Package
6DBV
8DIP / 8SOIC SOCKET
3DRT
10SON
DDPAK-5
20VQFN
5.0mm x 3.2mm
603
HDR5X2 M 0.1" TH
402
603
2.1mm I.D. x 5.5mm
