- Page 1 User Manual TP50P HDMI Extender over Cat5e/6 All Rights Reserved Version: TP50P_2019V1.0...
- Page 2 Always unplug the power to the device before cleaning. Unplug the power when not used for a long period of time. Refer all servicing to qualified service personnel. After-sales Service We provide limited warranty for the product within three years. Altimium www.altimium.com...
- Page 3 HDMI transmission. Advanced power design (PoC) allows this product to be powered at Transmitter, and only one power supply is required. In addition, the TP50P send/receive IR signals each other over the same CATx cable with IR pass through.
- Page 4 ⑥ HDMI OUT: HDMI loop output, connect to display. ⑦ RESET: Reboot. Receiver (RX) HDMI OUT CAT IN IR IN IR OUT EQ SETTING ① CAT IN: RJ45 connector with Green& Yellow indicators. Connect to Transmitter over CATx cable. ② IR IN: Connect with IR Receiver. Altimium www.altimium.com...
- Page 5 (1) IR IN; (1) IR OUT Control Connector (2) 3.5mm mini jacks (2) 3.5mm mini jacks General Transmission 1080p@60Hz≤55m Distance HDMI Standard HDMI 1.3, HDCP 1.4 compliant EDID Management Built-in EDID Input: 100VAC~240VAC, 50/60Hz; Output: 5VDC Power Supply Altimium www.altimium.com...
- Page 6 -10~55℃ Relative Humility 10%-90% Dimensions 66mm x 16.8 mm x66 mm (W*H*D) Weight Transmitter: 36g; Receiver: 38g; Connection Diagram Catx Projector Display IR Emitter IR Emitter DC 5V IR Receiver Projector Remote IR Receiver DVD Remote 1080P 55m Altimium www.altimium.com...
- Page 8 ALTIMIUM 587 Avenue Blaise Pascal 77550 MOISSY-CRAMAYEL Tél : 01.64.13.31.00 Fax: 01.60.29.62.70 Mail: contact@tesca-audio.com Web: www.altimium.com...
