- Page 1 User Manual WFH130 Wireless HDMI Extender All Rights Reserved Version: WFH130_2019V1.0...
- Page 2 Any changes or modifications not expressly approved by the manufacture would void the user’s authority to operate the equipment. Altimium www.altimium.com...
- Page 3 Unplug the power cord when left unused for a long period of time. Information on disposal for scrapped devices: do not burn or mix with general household waste, please treat them as normal electrical wastes. Altimium www.altimium.com...
-
Page 4: Table Of Contents
5. Default System Configuration ..................6 6. System Configuration....................7 6.1 Preparation to connect to Web Server ............... 7 6.2 Configuration Rx ....................12 6.3 Configuration Tx ....................15 7. Troubleshooting & Maintenance ................16 8. Customer Service ..................... 17 Altimium www.altimium.com... -
Page 5: Product Introduction
Wireless HDMI Extender 1. Product Introduction The WFH130 is a wireless HDMI extension solution kit, it transmits full HD video up to 130m with low latency of 60~100ms as well as low power consumption. It can be used at home theater, conference center, auditorium etc. -
Page 6: Specification
802.11n, 5GHz, 2T2R Booting Time 38~40s Speed of Change Resolution Transmission Distance up to 426ft/130m at 1080P External Power Supply 100V~240V AC, 50/60Hz or 5VDC 1A Tx: 5V 580mA=2.9W Power Consumption Rx: 5V 540mA=2.7W Product Temperature Rx: 37℃, Tx:49℃ Altimium www.altimium.com... - Page 7 Wireless HDMI Extender Operation Temperature -10℃ ~ +55℃ Storage Temperature -25℃ ~ +70℃ Relative Humidity 10% ~ 90% 87.0mm(W) x 24.5mm(H) x 64.0mm(D) Dimension (W*H*D) Net Weight Tx/Rx: 225g Altimium www.altimium.com...
-
Page 8: Panel Description
110V ~ 220V,50/60HZ ③ DC5V: Micro-USB port for external 5V DC power supply ④ Power LED: The LED illuminates red when power is applied. ⑤ LINK LED: The LED blinks green when the receiver is successfully connected to the transmitter. Altimium www.altimium.com... -
Page 9: System Connection
3) The Tx and the Rx are directly connected through the wireless network. 4) The red power LED of the device is on, if the power is set to the device. 5) The green link LED is blinking after the connection is established. Altimium www.altimium.com... -
Page 10: Default System Configuration
The extender has the default system configuration value by the Factory Reset. <Table 2 Default Configuration Value> Contents Transmitter (Tx) Receiver (Rx) QIM Mode Start Mode Station(Client) Local IP Address 20.20.20.1 Station(Client) Local Net Mask 255.255.255.0 255.255.255.0 SSID QDM-3000 QDM-3000 Radio Channel 44ch (5.22GHz) 44ch (5.22GHz) Altimium www.altimium.com... -
Page 11: System Configuration
Please use PC static IP to connect the web server. Go to “Control Panel -> All Control Panel Items -> Network and Sharing Center -> Change adapter settings” (Microsoft Windows version) to set the Static IP of the PC. Altimium www.altimium.com... - Page 12 Wireless HDMI Extender And then, click the properties of the Wireless Network in the “Network Connection‟ page. Open “Internet Protocol Version 4 (TCP/IPv4)” on the tap of the Networking, and then click the “Properties‟. Altimium www.altimium.com...
- Page 13 Wireless HDMI Extender Set the IP address and Subnet mask as the following figure. Please check if the wireless network is connected to Tx SSID, “QDM-3000”. Altimium www.altimium.com...
- Page 14 Wireless HDMI Extender After the network setting of the PC, please power on the Tx and Rx. After pairing the both of the devices, please type “20.20.20.1” in the web browser to configure the web servers to configure Tx. Altimium www.altimium.com...
- Page 15 RootAP should be alive and paired with the client. They show that Startup Mode are RootAP and Client. If you change the SSID in the RootAP, the PC has to connect to the SSID’s AP that has changed, not the QDM-3000’s AP. Altimium www.altimium.com...
-
Page 16: Configuration Rx
“Device tap” on the left, and configure as below: A. QIM Mode : rx B. Startup Mode : Client C. Local IP Addr : 20.20.20.2 (for example) D. Local Netmask : 255.255.255.0 Click the “Save‟ button after all configuration. Altimium www.altimium.com... - Page 17 Wireless HDMI Extender 2) Please select “Wireless” tap on the left to configure SSID name. To be aware of both of the Tx and Rx should connect to the same SSID. Altimium www.altimium.com...
- Page 18 Wireless HDMI Extender 3) Please click the “Save‟ button after the configuration of the wireless part. Subsequently, click the “Reboot‟ button to restart the Tx and Rx, and they will be automatically paired and connected automatically. Altimium www.altimium.com...
-
Page 19: Configuration Tx
“QDM-3000”. The Tx and Rx are connected through this SSID network. The pair of the devices should be the same SSID network. After the configuration, click the “Save” button and click the “Reboot‟ button to restart the extender as the settings of Altimium www.altimium.com... -
Page 20: Troubleshooting & Maintenance
Loose or failed power cord Double check the power work or no respond to any connection. cord connection. operation. Note: If your problem still remaining after following the above troubleshooting steps, please contact your local dealer or distributor for further assistance. Altimium www.altimium.com... -
Page 21: Customer Service
Remarks: Please contact your local distributor for further assistance or solution. Altimium www.altimium.com... - Page 24 ALTIMIUM 587 Avenue Blaise Pascal 77550 MOISSY-CRAMAYEL Tél : 01.64.13.31.00 Fax: 01.60.29.62.70 Mail: contact@tesca-audio.com Web: www.altimium.com...
