- Page 1 User Manual FO1HD-4K 4K Optical Fiber Extender All Rights Reserved Version: FO1HD-4K_2015V1.2...
-
Page 2: Fcc Statement
All product function is valid till 2015-7-7. Trademarks Product model, ALTIMIUM and its logo are trademarks of Altimium. Any other trademarks mentioned in this manual are acknowledged as the properties of the trademark owner. No part of this publication may be copied or reproduced without the prior written consent of Altimium. -
Page 3: Safety Precautions
4K Optical Fiber Extender SAFETY PRECAUTIONS To insure the best from the product, please read all instructions carefully before using the device. Save this manual for further reference. Unpack the equipment carefully and save the original box and packing material for possible future shipment ... -
Page 4: Package List
4K Optical Fiber Extender Introduction FO1HD-4K is a mini optical fiber extender for 4K resolution. It contains a transmitter module and a receiver module. Compatible with multi-mode and single-mode fiber, it extends graphic TMDS signals up to 400m/300m via single-mode cable/ multi-mode cable. - Page 5 IN: Connect with OUT of Rx Connection: The figure below illustrates a typical connection that can be utilized with FO1HD-4K: Step1. Insert the transmitter into the HDMI port of a HDMI source device (e.g. a PC). Step2. Connect the OUT port of the transmitter to the IN port of the receiver with an optical fiber cable.
-
Page 6: Specification
4K Optical Fiber Extender Specification Model FO1HD-4K FO1HDR-4K Spec Input Input Signal 1 HDMI 1 Optical Fiber Input Connector 19-pin Type A male HDMI LC connector Signal HDMI1.4 Optical Fiber Output Output 1 Optical Fiber 1 HDMI Output Connector LC connector... -
Page 7: Troubleshooting And Maintenance
4K Optical Fiber Extender Troubleshooting & Maintenance Problems Causes Solutions Color losing or vague/ Poor quality of the HDMI double image in HDMI Change for qualified cable. cable (if used) display Not been powered Power up the unit Power led is off, operations Make sure power adapter don’t work Poor contact of USB port... -
Page 8: After Sales Service
If there appear some problems when running the device, please check and deal with the problems referring to this user manual. 1) Product Limited Warranty: ALTIMIUM warrants that its products will be free from defects in materials and workmanship for two years, which starts from the first day the product leaves warehouse (check the SN mark on the product). - Page 9 4K Optical Fiber Extender ALTIMIUM 587 Avenue Blaise Pascal 77550 MOISSY-CRAMAYEL Tél : 01.64.13.31.00 Fax: 01.60.29.62.70 Mail: contact@tesca-audio.com Web: www.altimium.com...
