- Page 1 User Manual EXT.HDMI70IRSE HDMI/IR/RS232 Twisted Pair Extender All Rights Reserved Version: EXT.HDMI70IRSE_2016V1.1...
-
Page 2: Safety Precautions
Unplug the power cord when left unused for a long period of time. Information on disposal for scrapped devices: do not burn or mix with general household waste, please treat them as normal electrical wastes. Altimium www.altimium.com... - Page 3 Please refer to the dealers for the latest details. All rights reserved. No part of this publication may be copied or reproduced without permission. All product function is valid till 2016-12-5. Altimium www.altimium.com...
- Page 4 1.1. Introduction to the EXT.HDMI70IRSE ............... 1 1.2. Features ......................1 1.3. Package Contents .................... 1 2. Product Appearance ....................2 2.1. Appearance of EXT.HDMI70IRSET ..............2 2.2. Appearance of EXT.HDMI70IRSER ..............3 3. System Connection ....................4 3.1. System Diagram ....................4 3.2.
-
Page 5: Introduction
1.3. Package Contents 1 x EXT.HDMI70IRSET 1 x EXT.HDMI70IRSER (Packed separately from EXT.HDMI70IRSET) 8 x Plastic cushions 4 x Mounting ears (Separated from the EXT.HDMI70IRSET and EXT.HDMI70IRSER) 2 x RS232 cables 8 x Screws ... -
Page 6: Product Appearance
7) RS232: Serial port, 3-pin captive screw connector, connects with the control terminal to control the controlled terminal, supports bi-directional RS232 control between the EXT.HDMI70IRSET and the EXT.HDMI70IRSER. 8) 5V DC: Connect with DC 5V power adapter. Note: Pictures shown in this manual are for reference only, different model and specifications are subject to real product. -
Page 7: Appearance Of Ext.hdmi70Irser
CAT5e/CAT6 cable. 4) HDMI OUT: Connect to HDMI display, HDMI signal output. 5) IR IN: Connect with IR receiver, receive IR signals sent from EXT.HDMI70IRSET only. 6) IR OUT: Connect with IR emitter, the sending IR signal are received by EXT.HDMI70IRSET. -
Page 8: System Connection
Step1. Connect HDMI source (such as Blue-ray DVD) to HDMI IN port of the EXT.HDMI70IRSET with HDMI cable. Step2. Connect HDBT OUT port of the EXT.HDMI70IRSET to HDBT IN port of the EXT.HDMI70IRSER, with single CAT5e/CAT6 cable. Step3. Connect HDMI display (such as a HDTV) to HDMI OUT port of the EXT.HDMI70IRSER with HDMI cable. -
Page 9: Twisted Pair And Rs232 Cable Connection
Note: RS232 signal can be transmitted bi-directionally between the EXT.HDMI70IRSET and the EXT.HDMI70IRSER. Step6. Connect DC 5V power adaptors to both the EXT.HDMI70IRSET and the EXT.HDMI70IRSER. 3.4. Twisted Pair and RS232 Cable Connection ... -
Page 10: Application
& security institution etc. 4. Application Solution 4.1. System Diagram ① Receiver IR Remote Camera CAT5e RS232 PTN control panel ② Projector Laptop Video Signal Audio Signal Audio/Video Signal RS232 Control Signal Speaker3 Speaker Altimium www.altimium.com... -
Page 11: Product Assortment Description
Bridge connection function. User can switch the amplifier to be 1x40Watt@8OΩ by bridge connection. 48V phantom power to support condenser microphone. MIC port supports balance/unbalance signal, with which it can suppress the external noise effectively. Altimium www.altimium.com... -
Page 12: Specification
HDMI/IR/RS232 Twisted Pair Extender 5. Specification Model EXT.HDMI70IRSET EXT.HDMI70IRSER Spec Input Input Signal 1 HDMI,1 IR & 1 RS232 1 IR, 1 RJ-45 & 1 RS232 HDMI female, 3.5mm mini 3.5mm mini jack, RJ-45, 3p Input Connector jack, 3p captive screw... -
Page 13: Panel Drawing
HDMI/IR/RS232 Twisted Pair Extender NOTE: All nominal levels are at ± 10%. 6. Panel Drawing 6-1 EXT.HDMI70IRSET 6-2 EXT.HDMI70IR Altimium www.altimium.com... -
Page 14: Troubleshooting & Maintenance
Cannot control the device The device has already Send it to authorized by RS232 / IR been broken dealer for repairing. If your problem persists after following the above troubleshooting steps, seek further help from authorized dealer or our technical support. Altimium www.altimium.com... -
Page 15: After-Sales Service
Delivery, installation or labor charges for installation or setup of the product 3) Technical Support: Email to our after-sales department or make a call, please inform us the following information about your cases. Product version and name. Detailed failure situations. The formation of the cases. Altimium www.altimium.com... - Page 16 ALTIMIUM 587 Avenue Blaise Pascal 77550 MOISSY-CRAMAYEL Tél : 01.64.13.31.00 Fax: 01.60.29.62.70 Mail: contact@tesca-audio.com Web: www.altimium.com...
