- Page 1 User Manual TP630P-4K HDMI2.0 HDBaseT Extender All Rights Reserved Version: TP630P-4K_2017V1.0...
- Page 2 All product function is valid till 2017-4-13. Trademarks Product model, ALTIMIUM and its logo are trademarks of ALTIMIUM. Any other trademarks mentioned in this manual are acknowledged as the properties of the trademark owner. No part of this publication may be copied or reproduced without the prior written consent of ALTIMIUM.
- Page 3 Unplug the power cord when left unused for a long period of time. Information on disposal for scrapped devices: do not burn or mix with general household waste, please treat them as normal electrical wastes. ALTIMIUM www.altimium.com...
-
Page 4: Table Of Contents
2.1 Transmitter TP630T-4K ..................2 2.2 Receiver TP630R-4K ..................3 3. System Connection ..................... 5 3.1 Usage Precautions .................... 5 3.2 System Diagram ....................5 4. Specification ....................... 8 5. Troubleshooting & Maintenance ................. 9 6. After-sales Service ....................11 ALTIMIUM www.altimium.com... -
Page 5: Introduction
1. Introduction 1.1 Brief Introduction TP630P-4K is an ultra-thin HDMI2.0 HDBaseT Extender, includes Transmitter TP630T- 4K & Receiver TP630R-4K. It extends 3840x2160@60Hz 4:4:4 (Max) HDMI signal up to 100m via Cat5e/6 based on HDBaseT technology, providing a good solution for long-distance transmission application. -
Page 6: Panel Description
⑧ L+R OUT Stereo analog audio output port. ⑨ Ethenet port, work as Ethernet Switch together with the 2 ⑩ ETHERNET Ethenet ports of Receiver. Connect router to any one port, the others are able to access LAN. ALTIMIUM www.altimium.com... -
Page 7: Receiver Tp630R-4K
HDMI OUT Connect with HDMI display. ⑦ Toslink audio input port, connect with audio source. SPDIF IN/TO TX ⑧ Coaxial audio input port, when this port is connected with audio source ， the Toslink audio input port shouldn’t be ALTIMIUM www.altimium.com... - Page 8 HDBT IN Connect to the TP630T-4K via Cat5e/6 cable. ⑩ DC24V Connect with the included power adapter. ⑪ This extender to be powered at either the Transmitter or Receiver end, and only one power adaptor is required. ALTIMIUM www.altimium.com...
-
Page 9: System Connection
All devices should be connected before power on. 3.2 System Diagram TP630P-4K boast ARC (Audio Return Channel) function, which enables a display via a single audio/ HDMI cable, to send (upstream) audio to amplifiers/ speakers, increasing user flexibility. ARC Switcher Status... - Page 10 All utilized devices including the HDMI cable should support ARC. System Diagram shown in this manual are for reference only, more specific schemes depend on real devices. Connect HDBT ports via straight-thru CAT5e/6 cable with TIA/EIAT568B standard terminations at both ends. ALTIMIUM www.altimium.com...
- Page 11 RS232 communication protocol: Baud Rate: 9600; data bit: 8; stop bit: 1; parity: none. TP630P-4K receives RS232 control from devices with various baud rate (2400, 4800, 9600, 19200, 38400, 57600, 115200). HDBT ports can work with our company’s HDBT devices that has same power ...
-
Page 12: Specification
Up to 3840x2160@60Hz 4:4:4. Signal Standard HDMI2.0& HDCP2.2. Temperature -10~ 55℃. Reference Humidity 10% ~ 90%. Power Supply Input: 100V~240V AC; Output: 24VDC, 1.25A. Power Consumption 19W (Max.) Dimension(W*H*D) 152mm x 19mm x84mm 152mm x 19mm x84mm Net Weight 227g 232g ALTIMIUM www.altimium.com... -
Page 13: Troubleshooting & Maintenance
No digital audio output Change for other output devices Audio Output device don’t that support the audio formats support the audio format. listed in Specifications. No analog audio Audio OUT port (RCA connector) Change for other audio input ALTIMIUM www.altimium.com... - Page 14 Network or server failure. Service Provider. Cannot use the Send it to authorized dealer for the device is broken device repairing. If your problem persists after following the above troubleshooting steps, seek further help from authorized dealer or our technical support. ALTIMIUM www.altimium.com...
-
Page 15: After-Sales Service
If there appear some problems when running the device, please check and deal with the problems reference to this user manual. Product Limited Warranty: ALTIMIUM warrants that its products will be free from defects in materials and workmanship for three years, which starts from the first day the product leaves warehouse (check the SN mark on the product). - Page 16 ALTIMIUM 587 Avenue Blaise Pascal 77550 MOISSY-CRAMAYEL Tél : 01.64.13.31.00 Fax: 01.60.29.62.70 Mail: contact@tesca-audio.com Web: www.altimium.com ALTIMIUM www.altimium.com...
