- Page 1 User Manual TP421P-4K Ultra-thin HDBaseT Extender All Rights Reserved Version: TP421P-4K_2016V1.0...
- Page 2 Any changes or modifications not expressly approved by the manufacture would void the user’s authority to operate the equipment. Altimium www.altimium.com...
- Page 3 Unplug the power cord when left unused for a long period of time. Information on disposal for scrapped devices: do not burn or mix with general household waste, please treat them as normal electrical wastes. Altimium www.altimium.com...
-
Page 4: Table Of Contents
Ultra-thin HDBaseT Extender Table of Contents 1. Introduction ......................... 1 1.1 Introduction to TP421P-4K ................... 1 1.2 Features ......................1 1.3 Package Contents ..................... 1 2. Panel Description ......................2 2.1 Transmitter (TP421T-4K) ................... 2 2.2 Receiver (TP421T-4K) ..................3 2.3 Twisted Pair Cable Description ................ -
Page 5: Introduction
Ultra-thin HDBaseT Extender 1. Introduction 1.1 Introduction to TP421P-4K This product is an ultra-thin HDBaseT Extender set consist of transmitter and receiver. It distributes HDMI signal via CAT5e/CAT6a cable at 100m/PoE, and enables IR and RS232 passthrough to control remote displays. It also supports 4 Ethernet interface for network. -
Page 6: Panel Description
CAT6a cable, support unidirectional PoE. ⑨ 100M Ethernet interface, when need to work in a LAN, one of ETHERNET these 4 ports (both the Ethernet ports of transmitter and ⑩ ETHERNET receiver) should be used for internet access, and the others Altimium www.altimium.com... -
Page 7: Receiver (Tp421T-4K)
Connect with 5V/12V IR receiver (with carrier) to collect infrared ⑤ IR IN signal, work with far-end IR OUT port Connect with 5V/12V IR Emitter to send infrared signal, work with ⑥ IR OUT far-end IR IN port ⑦ HDMI OUT Connect with HDMI display Altimium www.altimium.com... -
Page 8: Twisted Pair Cable Description
Ground 3--6 1--2 Notice: Cable connectors Ground Ground MUST be metal one, the 1--2 3--6 shielded layer of cable Group Group MUST be connected to the 7--8 7--8 connector’s metal shell, to Group Group make a better transmission. Altimium www.altimium.com... -
Page 9: System Connection
Step2. Connect HDBT OUT port of transmitter and HDBT IN port of receiver with single CAT5e/CAT6a cable. Step3. Connect HDMI displayer (such as HDTV) to HDMI OUT port of receiver with HDMI cable. Step4. Both transmitter and receiver have IR IN and OUT. When one model use for IR Altimium www.altimium.com... -
Page 10: Application
Step7. Connect with DC24V power adaptor(s) separately or only connect power adaptor to transmitter). 3.4 Application TP421P-4K has a good application in various occasions, such as computer realm, monitoring, big screen displaying, meeting room, education and bank & securities institution etc. -
Page 11: Specification
HDBaseT 800x600@60Hz、1024x768@Hz、1280x720@60Hz、 1280x1024@60Hz 、 1366x768@60Hz、 1600x1200@60Hz Resolution 1920x1080@60Hz、1920x1200@60Hz、3D、4K×2K Transmission 1080P: 100m Distance 4K×2K: 70m Bandwidth 10.2Gbps HDMI Standard HDCP2.2 75Ω Impedance 0~ 50℃ Temperature 0% ~ 90% Humidity Power Consumption Power Supply Input: 100VAC~240VAC, 50/60Hz; Output: 24VDC 1.25A Altimium www.altimium.com... - Page 12 Ultra-thin HDBaseT Extender Dimension (W*H*D) 152mmx16mmx84mm Net Weight 186g 196g NOTE: All nominal levels are at ± 10%. Altimium www.altimium.com...
-
Page 13: Panel Drawing
Ultra-thin HDBaseT Extender 5. Panel Drawing 152 mm 5-1 Transmitter (TP421T-4K) 152 mm 5-2 Receiver (TP421R-4K) Altimium www.altimium.com... -
Page 14: Troubleshooting & Maintenance
Cannot control The device has already been Send authorized device by RS232 / IR broken dealer for repairing. If your problem persists after following the above troubleshooting steps, seek further help from authorized dealer or our technical support. Altimium www.altimium.com... -
Page 15: After-Sales Service
Product version and name. Detailed failure situations. The formation of the cases. Remarks: For any questions or problems, please try to get help from your local distributor. Altimium www.altimium.com... - Page 16 ALTIMIUM 587 Avenue Blaise Pascal 77550 MOISSY-CRAMAYEL Tél : 01.64.13.31.00 Fax: 01.60.29.62.70 Mail: contact@tesca-audio.com Web: www.altimium.com...
