- Page 1 User Manual TP503P-4K Ultra-thin HDBaseT2.0 Extender Set All Rights Reserved Version: TP503P-4K_2015V1.0...
-
Page 2: Fcc Statement
Any changes or modifications not expressly approved by the manufacture would void the user’s authority to operate the equipment. Altimium www.altimium.com... -
Page 3: Safety Precautions
Unplug the power cord when left unused for a long period of time. Information on disposal for scrapped devices: do not burn or mix with general household waste, please treat them as normal electrical wastes. Altimium www.altimium.com... -
Page 4: Table Of Contents
3.4 PoH Solution ...................... 7 3.5 ARC Solution ..................... 8 3.6 Application ......................9 4. Specification ......................10 4.1 Supported Resolution ..................11 5. Panel Drawing ......................12 6. Troubleshooting & Maintenance ................13 7. After-sales Service ....................15 Altimium www.altimium.com... -
Page 5: Introduction
1 x Power Adapter (DC12V 2A) 4 x Mounting Ears 8 x Screws 8 x Rubber Feet 1 x User manual Confirm if the product and the accessories are all included, if not, please contact with the dealers Altimium www.altimium.com... -
Page 6: Panel Description
Blinking GREEN: Normal operation Activate 100m/ 150m transmission mode. Transmission 100m mode: 4Kx2K@60Hz and 1080P signals can be ⑥ Mode Switcher transmitted up to 100m 150m mode: 1080P signal can be transmitted up to 150m, Altimium www.altimium.com... - Page 7 IR IN port Serial port, connects with control device or device to be ⑮ RS232 controlled, supports bi-directional RS232 control ⑯ DC 12V Connect with a DC12V 2A power adapter. Pictures for reference only, subject to our existing products. Altimium www.altimium.com...
-
Page 8: Receiver
Activate 100m/ 150m transmission mode. 100m mode: 4Kx2K@60Hz and 1080P signals can be Transmission ⑥ transmitted up to 100m Mode Switcher 150m mode: 1080P signal can be transmitted up to 150m, but do not support 4K signal. Altimium www.altimium.com... - Page 9 IR IN port Serial port, connects with control device or device to be ⑭ RS232 controlled, supports bi-directional RS232 control ⑮ DC 12V Connect with a DC12V 2A power adapter. Pictures for reference only, subject to our existing products. Altimium www.altimium.com...
-
Page 10: System Connection
Step3. Connect a HDMI displayer (such as HDTV) to HDMI OUT and SPDIF IN port of the receiver with HDMI cable and digital audio cable. Step4. Connect an AV amplifier to AUDIO OUT or SPDIF OUT of Transmitter. Step5. Connect speakers to AV amplifier. Altimium www.altimium.com... -
Page 11: Poh Solution
RS-232 control signals over a single Cat 5e/Cat 6 cable, it transfers DC power over a single network cable to a distance up to 150 meters (m) bi-directionally. Connect the DC adapter to either the transmitter or the receiver, the other end is able to Altimium www.altimium.com... -
Page 12: Arc Solution
Figure 3-3 ARC Solution Diagram When using ARC feature, please connect the amplifier via HDMI cable. All utilized devices including the HDMI cable should support ARC. Make sure the ARC switcher is switched to ON when using ARC function. Altimium www.altimium.com... -
Page 13: Application
Compliant with HDBT2.0, this product has a good application in occasions where high-definition AV distribution, long-distance transmission, Ethernet Switch are needed, such as computer realm, monitoring, big screen displaying, meeting room, education and bank & securities institution etc. Altimium www.altimium.com... -
Page 14: Specification
1 x RS232 (3-pin pluggable 1 x RS232 (3-pin pluggable terminal block) terminal block) General 1080p≤150m; Transmission Distance 4Kx2K≤100m Temperature 0~ 50℃ Reference Humidity 10% ~ 90% Input:100V~240V AC Power Supply Output: DC 12V 2A Power Consumption 196*19*100 196*19*100 Dimension (W*H*D) Altimium www.altimium.com... -
Page 15: Supported Resolution
1080P 3D, 1920x1080@60Hz, 1600x900@60Hz, 1366x768@60Hz, 16:9 1280x720@60Hz, 1024x576@60Hz 1920x1200@60Hz, 1680x1050@60Hz, 1440x900@60Hz, 16:10 1360x768@60Hz, 1280x800@60Hz 1600x1200@60Hz, 1400x1050@60Hz, 1280x1204@60Hz, 1024x768@60Hz, 800x600@60Hz, 640x480@60Hz This product supports 4k&1080p 3D HDMI signal, please adopt high-quality HDMI cables compliant with HDMI1.4 for optimum range and performance. Altimium www.altimium.com... -
Page 16: Panel Drawing
Ultra-thin HDBaseT2.0 Extender Set 5. Panel Drawing 196 mm TP503PT-4K HDCP LINK 100m / 150m ON / OFF MODE HDCP LINK Figure 5-1 Transmitter 196 mm TP503PR-4K HDCP LINK 100m / 150m ON / OFF MODE HDCP LINK Figure 5-2 Receiver Altimium www.altimium.com... -
Page 17: Troubleshooting & Maintenance
No digital audio connected correctly. output Change for other output Audio Output device don’t devices that support the support the audio format. audio formats listed in Altimium www.altimium.com... - Page 18 Internet Service Provider. Cannot use the Send it to authorized the device is broken device dealer for repairing. If your problem persists after following the above troubleshooting steps, seek further help from authorized dealer or our technical support. Altimium www.altimium.com...
-
Page 19: After-Sales Service
Product version and name. Detailed failure situations. The formation of the cases. Remarks: For any questions or problems, please try to get help from your local distributor. Altimium www.altimium.com... - Page 20 ALTIMIUM 587 Avenue Blaise Pascal 77550 MOISSY-CRAMAYEL Tél : 01.64.13.31.00 Fax: 01.60.29.62.70 Mail: contact@tesca-audio.com Web: www.altimium.com...
